BFP420 BOARD

Description
Trans RF BJT NPN 4.5V 0.06A Automotive 4-Pin(3+Tab) SOT-343 T/R
File Size550KB,9 Pages
ManufacturerInfineon
Websitehttp://www.infineon.com/
Download Datasheet Parametric Compare View All

BFP420 BOARD Overview

Trans RF BJT NPN 4.5V 0.06A Automotive 4-Pin(3+Tab) SOT-343 T/R

BFP420 BOARD Parametric

Parameter NameAttribute value
EU restricts the use of certain hazardous substancesCompliant
ECCN (US)EAR99
Part StatusActive
TypeNPN
MaterialSi
ConfigurationSingle Dual Emitter
Number of Elements per Chip1
Maximum Collector Base Voltage (V)15
Maximum Collector-Emitter Voltage (V)4.5
Maximum Collector-Emitter Voltage Range (V)<20
Maximum Emitter Base Voltage (V)1.5
Maximum DC Collector Current (A)0.06
Maximum DC Collector Current Range (A)0.06 to 0.12
Maximum Emitter Cut-Off Current (nA)3000
Maximum Collector Cut-Off Current (nA)100
Operational Bias Conditions2V/20mA
Minimum DC Current Gain60@20mA@4V
Minimum DC Current Gain Range50 to 120
Typical Output Capacitance (pF)0.15
Maximum Power Dissipation (mW)210
Maximum Power 1dB Compression (dBm)12(Typ)
Typical Power Gain (dB)21
Maximum 3rd Order Intercept Point (dBm)22(Typ)
Maximum Transition Frequency (MHz)25000(Typ)
Maximum Noise Figure (dB)1.1(Typ)
Minimum Operating Temperature (°C)-65
Maximum Operating Temperature (°C)150
PackagingTape and Reel
Pin Count4
Standard Package NameSOT-343
Supplier PackageSOT-343
MountingSurface Mount
Package Height0.9(Max)
Package Length2
Package Width1.25
PCB changed3
TabTab
Lead ShapeGull-wing
BFP420
Low Noise Silicon Bipolar RF Transistor
For high gain and low noise amplifiers
Minimum noise figure
NF
min
= 1.1 dB at 1.8 GHz
Outstanding
G
ms
= 21 dB at 1.8 GHz
For oscillators up to 10 GHz
Transition frequency
f
T
= 25 GHz
Pb-free (RoHS compliant) and halogen-free package
with visible leads
Qualification report according to AEC-Q101 available
3
4
1
2
ESD
(
E
lectro
s
tatic
d
ischarge) sensitive device, observe handling precaution!
Type
BFP420
Marking
AMs
1=B
Pin Configuration
2=E
3=C
4=E
-
-
Package
SOT343
Maximum Ratings
at
T
A
= 25 °C, unless otherwise specified
Parameter
Symbol
V
CEO
Value
Unit
Collector-emitter voltage
T
A
= 25 °C
T
A
= -55 °C
V
4.5
4.1
Collector-emitter voltage
Collector-base voltage
Emitter-base voltage
Collector current
Base current
Total power dissipation
1)
T
S
98 °C
V
CES
V
CBO
V
EBO
I
C
I
B
P
tot
T
J
T
Stg
15
15
1.5
60
9
210
150
-55 ... 150
mW
°C
mA
Junction temperature
Storage temperature
1
T
S
is
measured on the emitter lead at the soldering point to the pcb
Thermal Resistance
Parameter
Symbol
R
thJS
1
Value
Unit
Junction - soldering point
1)
250
K/W
2013-09-19
