LTC1560-1IS8 datasheet, PDF - EEWORLD Datasheet

Datasheet> All Categories > Active filter> LTC1560-1IS8

LTC1560-1IS8: DescriptionActive Filter Single Low Pass 5th Order 1.5MHz 8-Pin SOIC N; CategoryActive filter; File Size208KB，8 Pages; ManufacturerADI; Websitehttps://www.analog.com

Download Datasheet Parametric Compare View All

LTC1560-1IS8 Overview

Active Filter Single Low Pass 5th Order 1.5MHz 8-Pin SOIC N

LTC1560-1IS8 Parametric

Parameter Name	Attribute value
EU restricts the use of certain hazardous substances	Not Compliant
ECCN (US)	EAR99
Part Status	Unconfirmed
HTS	8542.39.00.01
SVHC	Yes
SVHC Exceeds Threshold	Yes
Type	Low Pass Filter
Maximum Order	5th
Number of Circuits	1
Cut-Off Frequency Range	100kHz to 4MHz
Cut-Off Frequency	1.5MHz(Max)
Minimum Dual Supply Voltage (V)	±4.5
Maximum Dual Supply Voltage (V)	±5.5
Typical Dual Supply Voltage (V)	±5
Power Supply Type	Dual
Minimum Operating Temperature (°C)	-40
Maximum Operating Temperature (°C)	85
Standard Package Name	SOP
Pin Count	8
Supplier Package	SOIC N
Mounting	Surface Mount
Package Height	1.5(Max)
Package Length	5(Max)
Package Width	3.99(Max)
PCB changed	8
Lead Shape	Gull-wing

Preview

Download Datasheet

View All

LTC1560-1

1MHz/500kHz

Continuous Time,

Low Noise, Lowpass Elliptic Filter

FEATURES

5th Order, 1MHz Elliptic Filter in SO-8 Package

Pin Selectable 1MHz/500kHz Cutoff Frequency

Signal-to-Noise Ratio (SNR): 75dB

Signal-to-Noise Ratio with – 63dB THD: 69dB

Passband Ripple (f

CUTOFF

= 1MHz):

±0.3dB

Stopband Attenuation Better Than 60dB

No External Components Required

either 500kHz (Pin 5 to V

) or 1MHz (Pin 5 to V

–

). When

programmed for 1MHz, the passband ripple is typically

±0.2dB

up to 0.55f

CUTOFF

and

±0.3dB

to 0.9f

CUTOFF

. The

transition band gain is – 24dB at 1.4f

CUTOFF

and – 51dB at

CUTOFF

. Stopband attenuation is 63dB at 2.43f

CUTOFF

and

above, remaining at least 60dB to 10MHz with proper

board layout. When the LTC1560-1 is programmed for

CUTOFF

= 500kHz, the filter response closely follows the

1MHz case with the exception of passband flatness near

the cutoff frequency; the gain at f

CUTOFF

is – 1.3dB.

The LTC1560-1, unlike other high frequency filters, is

designed for low noise and low distortion. With a 1V

RMS

input signal, the signal-to-noise ratio is 69dB and the THD

is – 63dB. The maximum SNR of 75dB is obtained with a

2.1V

RMS

input signal. This results in – 46dB THD.

The LTC1560-1 operates with

±5V

supplies, has a power

saving mode and is available in an SO-8 surface mount

package.

Other cutoff frequencies from 450kHz to 1.5MHz can be

obtained. Demo board DC135A is available for the

LTC1560-1. For more information please contact LTC

Marketing.

, LTC and LT are registered trademarks of Linear Technology Corporation.

APPLICATIONS

Antialiasing Filters

Smoothing or Reconstruction Filters

Communication Filters

DESCRIPTION

The LTC

1560-1 is a 5th order, continuous-time, lowpass

filter.

The elliptic transfer function of the LTC1560-1 was

carefully chosen to reach a compromise between selectiv-

ity, for antialiasing applications, and transient response.

The filter cutoff frequency, f

CUTOFF

, is pin selectable to

TYPICAL APPLICATION

Frequency Response

1MHz/500kHz Elliptic Lowpass Filter

0.01µF

– 5V

1MHz

500kHz

1560-1 TA01

GND

OUT

SHDN

LTC1560-1

GND

–

0.5f

GAIN (dB)

– 5V

0.1µF

OUT

(OR – 5V)

0.1µF

0.01µF

–10

–20

–30

–40

–50

– 60

–70

CUTOFF

= 1MHz/500kHz

– 90

0.1

FREQUENCY (MHz)

– 80

1560-1 TA02

sn15601 15601fs

LTC1560-1IS8 Related Products

	LTC1560-1IS8	LTC1560-1CS8#PBF	LTC1560-1CS8#TRPBF	LTC1560-1CS8	LTC1560-1IS8#PBF	LTC1560-1IS8#TRPBF
Description	Active Filter Single Low Pass 5th Order 1.5MHz 8-Pin SOIC N	Active Filter Single Low Pass 5th Order 1.5MHz 8-Pin SOIC N Tube	Active Filter Single Low Pass 5th Order 1.5MHz 8-Pin SOIC N T/R	Active Filter Single Low Pass 5th Order 1.5MHz 8-Pin SOIC N	Active Filter Single Low Pass 5th Order 1.5MHz 8-Pin SOIC N Tube	Active Filter Single Low Pass 5th Order 1.5MHz 8-Pin SOIC N T/R
EU restricts the use of certain hazardous substances	Not Compliant	Compliant	Compliant	Not Compliant	Compliant	Compliant
ECCN (US)	EAR99	EAR99	EAR99	EAR99	EAR99	EAR99
Part Status	Unconfirmed	Active	Active	Unconfirmed	Active	Active
Type	Low Pass Filter	Low Pass Filter	Low Pass Filter	Low Pass Filter	Low Pass Filter	Low Pass Filter
Maximum Order	5th	5th	5th	5th	5th	5th
Number of Circuits	1	1	1	1	1	1
Cut-Off Frequency Range	100kHz to 4MHz	100kHz to 4MHz	100kHz to 4MHz	100kHz to 4MHz	100kHz to 4MHz	100kHz to 4MHz
Cut-Off Frequency	1.5MHz(Max)	1.5MHz(Max)	1.5MHz(Max)	1.5MHz(Max)	1.5MHz(Max)	1.5MHz(Max)
Minimum Dual Supply Voltage (V)	±4.5	±4.5	±4.5	±4.5	±4.5	±4.5
Maximum Dual Supply Voltage (V)	±5.5	±5.5	±5.5	±5.5	±5.5	±5.5
Typical Dual Supply Voltage (V)	±5	±5	±5	±5	±5	±5
Power Supply Type	Dual	Dual	Dual	Dual	Dual	Dual
Maximum Operating Temperature (°C)	85	70	70	70	85	85
Standard Package Name	SOP	SOP	SOP	SOP	SOP	SOP
Pin Count	8	8	8	8	8	8
Supplier Package	SOIC N	SOIC N	SOIC N	SOIC N	SOIC N	SOIC N
Mounting	Surface Mount	Surface Mount	Surface Mount	Surface Mount	Surface Mount	Surface Mount
Package Height	1.5(Max)	1.5(Max)	1.5(Max)	1.5(Max)	1.5(Max)	1.5(Max)
Package Length	5(Max)	5(Max)	5(Max)	5(Max)	5(Max)	5(Max)
Package Width	3.99(Max)	3.99(Max)	3.99(Max)	3.99(Max)	3.99(Max)	3.99(Max)
PCB changed	8	8	8	8	8	8
Lead Shape	Gull-wing	Gull-wing	Gull-wing	Gull-wing	Gull-wing	Gull-wing
Packaging	-	Tube	Tape and Reel	-	Tube	Tape and Reel
