PEH 532
•
•
•
•
•
snap-in
long life grade
pCb mounting
low esr and esl
high ripple current
appliCation
105°c
RoHS
Compliant
basiC design
PEH 532 is a Long Life electrolytic capacitor The low ESR together with the TDC thermal
designed to offer high ripple current concept gives the PEH 532 a high ripple
capability and low mounting cost. The low current capability.
ESR is a result of very low resistive paper/
electrolyte system.
Typical applications for PEH 532 would be
SMPS, drives, welding equipment, UPS and
other power electronic applications where
high current ratings and compact size are
important.
speCifiCation
standards
Capacitance range
Capacitance tolerance
rated voltage
temperature range
leakage current, i
rl
(µa)
operational life time
shelf life
diameter range
IEC 60384-4 Long Life Grade 40/105/56,
in accordance with CECC 30 301-809
68–27000 µF
–20 to +20%
35–450 VDC
–40 to +105°C
0.003 (µA) x C
R
(µF) x U
R
(V)
2000 hours at +105°C
4 years at 0 Volt and +40°C
22–35 mm
Negative
2 Pin
Negative
3 Pin
Negative
4 Pin
Sleeve
Sleeve
Sleeve
pin configuration
Diameter range
22-35 mm: 2-3 pins
dimensions table peh 532 (mm)
dxl
22 x 25
22 x 30
22 x 35
22 x 40
22 x 45
22 x 50
25 x 25
25 x 30
25 x 35
25 x 40
25 x 45
25 x 50
30 x 25
30 x 30
30 x 35
30 x 40
30 x 45
30 x 50
35 x 25
Case
code
AB
AC
AD
AE
AF
AG
BB
BC
BD
BE
BF
BG
CB
CC
CD
DE
CF
CG
DB
d1
±0.5
22.5
22.5
22.5
22.5
22.5
22.5
25.5
25.5
25.5
25.5
25.5
25.5
30.5
30.5
30.5
30.5
30.5
30.5
35.5
l1
±1.0
26
31
36
41
46
51
26
31
36
41
46
51
26
31
36
41
46
51
26
weight
approx (g)
13
14
15
17
19
21
19
21
24
27
30
33
24
29
34
39
45
51
32
dxl
35 x 30
35 x 35
35 x 40
35 x 45
35 x 50
35 x 55
Case
code
DC
DD
DE
DF
DG
DH
d1
±0.5
35.5
35.5
35.5
35.5
35.5
35.5
l1
±1.0
31
36
41
46
51
56
weight
approx (g)
40
48
56
64
72
85
pin Configuration
description
2 pin
pin length
6.3±1
Code
2
dia. mm -0+1
2 pin
4.0±1
2s
3 pin
4.0±1
3
4 pin
6.3±1
4
4 pin
4.0±1
4s
22
25
30
35
•
•
•
•
•
•
•
•
•
•
•
•
•
•
110
