15A (2C), 10A (4C) COMPACT POWER RELAYS WITH HIGH SENSITIVITY

Preview

Download Datasheet

View All

15A (2C), 10A (4C) COMPACT

POWER RELAYS WITH HIGH

SENSITIVITY

FEATURES

.866

SP-RELAYS

1.969

inch

25.6

1.008

36.8

1.449

• High Vibration/Shock Resistance

Vibration resistance: 18 G, amplitude 3 mm (10 to 55 Hz)

Shock resistance: 40 G (11 ms)

• Latching types available

• High Sensitivity in Small Size 150 mW pick-up, 300 mW

nominal operating power

• Wide Switching Range

From 1 mA to 15 A (2C) and 10 A (4C)

SPECIFICATIONS

Contacts

Arrangement

Initial contact resistance, max.

(By voltage drop 6 V DC 1 A)

Initial contact pressure

2 Form C, 4 Form C

30 m

Ω

Characteristics (at 25

50% Relative humidity)

Max. operating speed (at rated load)

Initial insulation resistance*

Between open contacts

Initial

breakdown Between contact sets

voltage*

Between contact and coil

Operate time*

(at nominal voltage)

Release time(without diode)*

(at nominal voltage)

Temperature rise

(at nominal voltage)

Functional*

Shock resistance

Destructive*

Functional*

Vibration resistance

Destructive

Conditions for operation,

transport and storage*

(Not freezing and condens-

ing at low temperature)

2C: Approx. 0.392 N (40 g

1.41 oz

)

4C: Approx. 0.196 N (20 g

0.71 oz

)

Stationary contact:

Gold ﬂashed silver alloy

Contact material

Movable contact: Silver alloy

2C: 15 A 250 V AC

Nominal switching

10 A 30 V DC

capacity

4C: 10 A 250 V AC

Rating

10 A 30 V DC

(resistive

2C: 3,750 VA, 300 W

Max. switching power

load)

4C: 2,500 VA, 300 W

Max. switching voltage

2C, 4C: 250 V AC, 30 V DC

2C: 15 A (AC) 10 A (DC), 4C: 10 A

Max. switching current

Mechanical (at 180 cpm)

Expected

Electrical 2C 15 A 250 V AC

10 A 30 V DC

life (min.

(at 20 cpm)

operations)

(resistive

10 A 250 V AC

load)

10 A 30 V DC

20 cpm

1,000 M

Ω

at 500 V DC

1,500 Vrms

3,000 Vrms

Max. 30 ms (Approx. 25 ms)

Max. 20 ms (Approx. 15 ms)

Ambient

temp.

Humidity

Max. 40

C with nominal coil voltage

and at nominal switching capacity

Min. 392 m/s

{40 G}

Min. 980 m/s

{100 G}

176.4 m/s

{18 G}, 10 to 55 Hz

at double amplitude of 3 mm

176.4 m/s

{18 G}, 10 to 55 Hz

at double amplitude of 3 mm

–50

C to +60

–58

F to +140

5 to 85% R.H.

Unit weight

Remarks

2C: 50 g

1.76 oz

; 4C: 65 g

2.29 oz

Coil (polarized) at 20

Single side stable

Latching

Nominal operating power

Minimum set and reset power

Nominal set and reset power

300 mW

150 mW

300 mW

* Speciﬁcations will vary with foreign standards certiﬁcation ratings.

Measurement at same location as "Initial breakdown voltage" section

Detection current: 10 mA

Excluding contact bounce time

Half-wave pulse of sine wave: 11ms; detection time: 10

Half-wave pulse of sine wave: 6ms

Detection time: 10

Refer to 5. Conditions for operation, transport and storage mentioned in

AMBIENT ENVIRONMENT (Page 61).

TYPICAL APPLICATIONS

NC machines, remote control panels,

sophisticated business equipment.

ORDERING INFORMATION

Ex.

Contact arrangement

2: 2 Form C

4: 4 Form C

Operating function

Nil: Single side stable

L2: 2 coil latching

DC24V

Coil voltage

DC 3, 5, 6, 12,

24, 48 V

(Notes) 1. PC board terminal types available as option. Please consult us for details.

2. 2 Form C: Carton: 20 pcs., Case: 200 pcs.

4 Form C: Carton: 10 pcs., Case: 100 pcs.

3. UL/CSA, TÜV approved type is standard.

252
