20W Single Output LED Power Supply
Features :
PLN-20
series
Universal AC input / Full range(up to 277VAC)
Protections:Short circuit/Over current/Over voltage/Over temperature
Cooling by free air convection
Built-in constant current limiting circuit with adjustable OCP level
Fully isolated plastic case
Built-in active PFC function
IP64 design for indoor or outdoor installations
Small and compact size
Class
power unit, no FG
100% full load burn-in test
High reliability,low cost
Suitable for Damp / wet locations
Suitable for LED lighting and moving sign applications
2 years warranty
F
110
M
M
SPECIFICATION
MODEL
DC VOLTAGE
PLN-20-12
12V
LED OPERATION VOLTAGE
Note.5
9 ~ 12V
1.6A
RATED CURRENT
CURRENT RANGE
CURRENT ADJ. RANGE
RATED POWER
OUTPUT
VOLTAGE TOLERANCE
Note.3
LINE REGULATION
LOAD REGULATION
SETUP TIME
VOLTAGE RANGE
FREQUENCY RANGE
POWER FACTOR
INPUT
EFFICIENCY(Typ.)
AC CURRENT
INRUSH CURRENT(max.)
LEAKAGE CURRENT
OVER CURRENT
SHORT CIRCUIT
PROTECTION
OVER VOLTAGE
OVER TEMPERATURE
WORKING TEMP.
WORKING HUMIDITY
ENVIRONMENT STORAGE TEMP., HUMIDITY
TEMP. COEFFICIENT
VIBRATION
SAFETY STANDARDS
WITHSTAND VOLTAGE
SAFETY & ISOLATION RESISTANCE
EMC
EMC EMISSION
EMC IMMUNITY
MTBF
OTHERS
DIMENSION
PACKING
NOTE
Note.5
SELV
IP64
PLN-20-36
36V
27 ~ 36V
0.55A
0 ~ 0.55A
19.8W
3.0Vp-p
PLN-20-48
48V
36 ~ 48V
0.42A
0 ~ 0.42A
20.2W
3.8Vp-p
PLN-20-18
18V
13.5 ~ 18V
1.1A
0 ~ 1.1A
19.8W
3.0Vp-p
PLN-20-24
24V
18 ~ 24V
0.8A
0 ~ 0.8A
19.2W
3.0Vp-p
0 ~ 1.6A
75% ~ 100%
19.2W
10%
3.0%
10%
RIPPLE & NOISE (max.)
Note.2
2.5Vp-p
2300ms / 230VAC 3000ms / 115VAC at full load
Note.4
90 ~ 277VAC
127~392VDC
47 ~ 63Hz
PF 0.9 at 75~100% load, 115VAC/230VAC;PF 0.9 at 85~100% load 277VAC (Please refer to "Power Factor Characteristic" curve)
83%
80%
83.5%
82%
81%
0.4A/115VAC
40A/230VAC
0.5mA / 240VAC
95 ~ 110%
Protection type : Constant current limiting, recovers automatically after fault condition is removed
Hiccup mode, recovers automatically after fault condition is removed.
27 ~ 34V
14 ~ 16V
19 ~ 22V
Protection type : Shut off o/p voltage, clamping by zener diode
41 ~ 46V
54 ~ 60V
0.2A/230VAC
0.15A/277VAC
110
10 (TSW1)
Protection type : Shut down o/p voltage, recovers automatically after temperature goes down
-30 ~ +60
(Refer to "Derating Curve")
20 ~ 90% RH non-condensing
-40 ~ +80 , 10 ~ 95% RH
0.06%/ (0 ~ 50 )
10 ~ 500Hz, 2G 10min./1cycle, period for 60min. each along X, Y, Z axes
IEC61347-1, IEC61347-2-13, TUV EN61347-1, EN61347-2-13, UL8750,J61347-1, J61347-2-13, IP64 approved
I/P-O/P:3.75KVAC
I/P-O/P:100M Ohms/500VDC / 25 / 70%RH
Compliance to EN55015,EN61000-3-2 Class C( 75% load);EN61000-3-3
Compliance to EN61000-4-2,3,4,5,6,8,11;EN61547, light industry level, criteria A
643.6Khrs min.
MIL-HDBK-217F (25
)
148.5*38.5*28mm (L*W*H)
0.18Kg; 60pcs/12.8Kg/0.9CUFT
1. All parameters NOT specially mentioned are measured at 230VAC input, rated load and 25 of ambient temperature.
2. Ripple & noise are measured at 20MHz of bandwidth by using a 12" twisted pair-wire terminated with a 0.1uf & 47uf parallel capacitor.
3. Tolerance : includes set up tolerance, line regulation and load regulation.
4. Derating may be needed under low input voltage, please check the static characteristic for more details.
5. Constant current operation region is within 75% ~100% rated output voltage. This is the suitable operation region for LED related applications, but please
reconfirm special electrical requirements for some specific system design.
6. The power supply is considered as a component that will be operated in combination with final equipment. Since EMC performance will be affected by the
complete installation, the final equipment manufacturers must re-qualify EMC Directive on the complete installation again.
7. Direct connecting to LEDs is suggested, but is not suitable for using additional drivers.
File Name:PLN-20-SPEC 2011-08-11
