PNI-200501500VA001 500VA Pure Sine Wave Inverter
January 2005
-Makes
Life Powerful
PNI-200501500VA001
500VA Pure Sine Wave Inverter
PNI-200501500VA001 series of inverters are innovative product in the power inverter world. This
inverter accepts wide range of the input DC voltage from the battery, and provides 230VAC,
50Hz
clean sine wave
output. This inverter offers relatively
low harmonic distortion
in the output
voltage and
excellent load regulation.
The
inverter efficiency
remains grater then
90%
over the
full output power range and full DC input voltage range.
This
power efficient
and
lightweight
inverter has
inbuilt battery charger,
which charges the fully
discharged battery (12V, 150AH) within 5 hours this charger puts nearly 80% energy in the battery
with in 3 hours. Not only this, the battery charger uses four stage-charging techniques, which
maximize the charging efficiency and battery operational life.
The battery charger takes AC
input power from your home power socket at
≈
0.99
power factor, which again
saves the AC input
power
during charging.
The high efficiency of the inverter allows the power availability for longer
duration (large back-up time >5.0 hours (approx.) under fully charged battery and full output load
conditions. Backup time will be increased in case of lower output load connected to the inverter).
General Description:
Features:
1.
2.
3.
4.
5.
6.
Sine Pulse Width Modulation (SPWM) inverter control technology.
Output Voltage waveform is clean 50Hz Sine Wave.
Low output voltage harmonic distortion.
Accurate Output power limiting (by cycle by cycle output load current limit)
Accepts wide range of the input DC voltage.
Uses very fast, low loss Power MOSFET & smaller magnetic parts, hence provides
comparatively higher power conversion efficiency.
7. Overall inverter weight is less then 1kg, hence offers high power density.
8. Includes very fast and efficient Battery Charger.
9. Battery charger saves a lot power during the battery charging.
10. Battery charger charges your inverter’s fully discharged battery in 5Hours.
11. Battery charger accepts universal input voltage range, which still allows your fully
discharged battery to be charged in same time, even if your home AC input voltage is 85V.
12. Automatic “ON” or “OFF” as per the availability of the AC input power.
13. Under battery voltage protection.
14. Excellent load and line regulation.
©2005 Power Nucleus Inc.
PN200501500VA001
www.powernucleus.com
PNI-200501500VA001
Technical Specifications of PN- 200501500VA001
Input Power Source
: Lead Acid Batteries
Input Voltage Range
: 9.5VDC to 16VDC
Output Power
: 500VA (Max)
Peak Output Power
: 575VA
Output Voltage
: 230VAC, -2%, Sine Wave 50Hz
Output Voltage THD
: <5%
Over load protection
: Yes (output current is limited to 2.5A)
Inverter overall efficiency
:
≅
90%
Control technology
: Sine Pulse Width Modulation
Inverter Control frequency
: 50kHz.
Input Voltage to Battery Charger : 85VAC to 260VAC (48Hz to 62Hz)
Battery Charging Time
:
≤
5.5H for 12V, 150AH Lead Acid Battery
Charger Input power factor
: 0.99
Total Inverter Weight
: 1.0kg. (Approx.) (Without batteries)
©2005 Power Nucleus Inc.
PN200501500VA001
www.powernucleus.com
IMPORTANT NOTE
Power Nucleus reserves the right to make changes to their products or to discontinue any product or service without
notice, and advise customers to obtain the latest version of relevant information to verify, before placing orders, that
information being relied on is current and complete. All products are sold subject to the terms and conditions of sale
supplied at the time of order acknowledgement. Power Nucleus’s products are not authorized for the use as life support
applications/devices or medical system without the written permission of the president of Power Nucleus Inc.
