PP1101SB
&
. . . engineered solutions for the transient environment™
PP1101SC
UNIDIRECTIONAL THYRISTOR SURGE SUPPRESSOR
APPLICA
TIONS
✔
SLIC Line Card
✔
DBX Branch Exchange Switches
✔
FCC Part 68 Customer Premise Equipment
✔
Line Interface Modem
✔
ISDN Architecture Interface
IEC COMPA
TIBILITY
(EN61000-4)
✔
61000-4-2 (ESD): Air - 15kV, Contact - 8kV
✔
61000-4-4 (EFT): 40A - 5/50ns
✔
61000-4-5 (Surge): 8/20µs - 95A, L4(Line-Gnd), 48A, L4(Line-Line) & 83A, L2(Power)
FEA
TURES
✔
Complies with: FCC Part 68, UL 1459, Bellcore 1089, ITU-K.20 & K.21
✔
Peak Off-State Voltage: 80 Volts
✔
Surge Current Capability(See Table 1)
✔
ESD Protection > 40 kilovolts
MECHANICAL CHARACTERISTICS
✔
Molded Plastic DO-214AA Package
✔
Weight 2.5 grams (Approximate)
✔
Flammability Rating UL 94V-0
✔
Device Marking: Logo, Marking Code & Polarity Band or Notch on Top Surface
DO-214AA
DEVICE SYMBOL
(UNIDIRECTIONAL)
TABLE 1 - SURGE RATINGS
SERIES
I
PP
2 X 10µs
AMPS
300
500
I
PP
I
PP
I
PP
10 X 160µs 10 X 560µs 10 X 1000µs
AMPS
AMPS
AMPS
150
200
100
200
80
100
I
TSM
60 Hz
AMPS
32
60
di/dt
dv/dt
AMPS/µs
AMPS/µs
(See Note 1) (See Note 1)
500
500
2000
2000
SB
SC
Note 1:
Critital Rate of Rise for On-State Current (di/dt) and Off-State Voltage (dv/dt).
05171.R1 5/02
1
www.protekdevices.com
PP1101SB
&
PP01101SC
DEVICE CHARACTERISTICS
MAXIMUM RATINGS @ 25°C Unless Otherwise Specified
PARAMETER
Surge Current - 50/60 Hz (SB/SC)
Junction Temperature
Storage Temperature
Thermal Resistance(Junction) - SB Series
Thermal Resistance(Junction) - SC Series
Thermal Resistance(Ambient) - SB Series
Thermal Resistance(Ambient) - SC Series
SYMBOL
I
TSM
T
j
T
STG
R
θjc
R
θjc
R
θja
R
θja
VALUE
60/32
-40 to 150
-55 to 150
28
26
90
85
UNITS
Amps
°C
°C
°C/Watt
°C/Watt
°C/Watt
°C/Watt
ELECTRICAL CHARACTERISTICS PER LINE @ 25°C Unless Otherwise Specified
PART
NUMBER
DEVICE
MARKING
CODE
REPETITIVE
PEAK
OFF-STATE
VOLTAGE
SWITCHING
VOLTAGE
MINIMUM
HOLDING
CURRENT
(See Fig. 4)
di/dt = 1A/ms
I
H
mA
150
150
SWITCHING
CURRENT
MAXIMUM
OFF-STATE
CURRENT
(See Fig. 3)
@V
DRM
I
DRM
µA
5
5
MAXIMUM
ON-STATE
VOLTAGE
(See Fig. 3)
@I
T
V
T
VOLTS
5
5
ON-STATE
CURRENT
TYPICAL
CAPACITANCE
V
DRM
VOLTS
PP1101SB
PP1101SC
JS
JT
95
95
@100V/µs
V
S
VOLTS
130
130
I
S
mA
800
800
I
T
AMPS
1.0
1.0
@50V, 1 MHz
C
pF
80
120
100
I
PP
- Peak Pulse Current - % of I
PP
FIGURE 1
PULSE WAVE FORM
t
f
TEST
WAVEFORM
PARAMETERS
t
f
= 10µs
t
d
= 1,000µs
t
d
= t I /2
PP
FIGURE 2
V-I CHARACTERISTIC CURVE
I
PP
I
TSM
I
T
I
S
I
H
V
S
I
DRM
V
T
V
DRM
Peak Value I
PP
50
e
0
0
1
t - Time - µs
2
-t
3
05171.R1 5/02
2
www.protekdevices.com
PP1101SB
&
PP1101SC
FIGURE 4
TYPICAL PEAK OFF-STATE CURRENT VS JUNCTION TEMPERATURE
FIGURE 5
TYPICAL ON-STATE CURRENT VS ON-STATE VOLTAGE
10
100
I
DRM
- Peak Off-State Current - µA
1
I
T
- On-State Current - A
10
0.1
0.01
-40
0
40
80
t
J
- Temperature - °C
120
1
0
1
2
3
4
V
T
- On-State Voltage - V
5
6
7
1.15
1.1
1.05
Normalized V
S
FIGURE 6
TYPICAL NORMALIZED V
S
VS JUNCTION TEMPERATURE
2.5
FIGURE 7
TYPICAL HOLDING CURRENT VS JUNCTION TEMPERATURE
2
I
H
/I
H
(t
J
25°C)
1
0.95
0.9
1.5
1
0.5
0.85
0.8
-40
0
-40
0
40
80
t
J
- Temperature - °C
120
0
40
80
t
J
- Temperature - °C
120
100
Non-Repetitive On-State Current (I
TSM
) - Amps
FIGURE 7
ON-STATE CURRENT VS SURGE CURRENT DURATION
PPxxxxSC
10
PPxxxxSB
1
1
10
100
Surge Current Duration - Full Cycles
1,000
05171.R1 5/02
3
www.protekdevices.com
