POLYPROPYLENE FILM CAPACITORS
PPS Series: High Voltage Radial Dipped, Film Foil
INTRODUCTION
PPS Series are non-inductively wound with a
polypropylene dielectric in series with aluminum foil
for electrodes using copperclad steel leads and
epoxy resin coating. They are ideal for high
frequency and high pulse rise time circuits.
These capacitors are suitable for snubber
applications, power supplies and electronic lighting
ballast.
FEATURES
•High corona starting voltage
•High current rating and high dv/dt
•Series electrode construction
•Flame retardant epoxy resin coating.
(compliant to UL 94V-0)
LEAD DIAMETER
Lead Space Lead Diameter
d
P
< 15.0 mm
0.6 mm
> 15.0 mm
0.8 mm
SPECIFICATIONS
Type
Operating Temperature Range
Capacitance Range
Capacitance Tolerance
Rated Voltage
Dissipation Factor
Insulation Resistance
Performance
-55°C ~ +105°C
0.001 ~ 0.033 F
±5% (J), ±10% (K)
1000VDC, 1600VDC
2000VDC
10% max
200,000M × F
400,000M min
PULSE CAPABILITY
Rated
Volts
1000
1600
2000
Body Length
25mm
32mm
8400
6400
16000
12000
16800
12800
DIMENSIONS
W.V.
F
0.0010
0.0012
0.0015
0.0018
0.0022
0.0027
0.0033
0.0039
0.0047
0.0056
0.0068
0.0082
0.0100
0.0120
0.0150
0.0180
0.0220
0.0270
0.0330
Code
102
122
152
182
222
272
332
392
472
562
682
822
103
123
153
183
223
273
333
W
25.0
25.0
25.0
25.0
25.0
25.0
25.0
25.0
25.0
25.0
25.0
25.0
25.0
25.0
25.0
32.0
32.0
32.0
32.0
1000VDC
(3A)
H
T
P±1.5
13.0 8.0
21.0
13.0 8.0
21.0
13.0 8.0
21.0
13.0 8.0
21.0
14.0 8.5
21.0
14.0 8.5
21.0
15.0 9.0
21.0
15.0 9.0
21.0
16.0 9.5
21.0
17.0 10.5 21.0
18.0 11.5 21.0
19.0 12.5 21.0
20.0 13.0 21.0
22.0 13.0 21.0
23.0 13.0 21.0
24.5 14.0 26.0
26.5 15.5 26.0
27.5 17.0 28.0
30.0 19.0 28.0
1600VDC
(3C)
H
T
P±1.5
13.0 9.0
21.0
13.0 9.0
21.0
14.0 9.0
21.0
14.0 9.0
21.0
15.0 9.0
21.0
16.0 9.5
21.0
17.0 10.0 21.0
18.0 11.0 21.0
19.0 12.0 21.0
21.0 12.0 26.5
21.0 12.0 26.5
22.0 13.0 26.5
23.0 15.0 26.5
24.0 16.0 26.5
26.0 18.0 26.5
28.0 20.0 28.0
30.0 20.0 28.0
2000VDC
(3D)
H
T
P±1.5
15.0 10.0 21.0
15.0 10.0 21.0
15.0 10.0 21.0
16.0 11.0 21.0
17.0 12.0 21.0
18.0 13.0 21.0
20.0 14.0 21.0
22.0 15.0 21.0
22.0 14.0 26.5
23.0 15.0 26.5
24.0 16.0 26.5
25.0 17.0 26.5
26.0 18.0 26.5
28.5 20.0 28.0
31.0 21.0 28.0
W
25.0
25.0
25.0
25.0
25.0
25.0
25.0
25.0
25.0
32.0
32.0
32.0
32.0
32.0
32.0
33.0
33.0
W
25.0
25.0
25.0
25.0
25.0
25.0
25.0
25.0
32.0
32.0
32.0
32.0
32.0
33.0
33.0
PART NUMBER EXAMPLE
PPS 222 J 3A
RFE International
• Tel:(949) 833-1988 • Fax:(949) 833-1788 • E-Mail Sales@rfeinc.com
C1DD06
REV 2001.10.16
