PRA 100, 135, 182 (CNW)
Vishay Sfernice
High Precision Resistor Arrays
FEATURES
•
High stability passivated nichrome resistive
layer 0.02 % on ratio, 1000 h at Pn at + 70 °C
•
Tight TCR (10 ppm/°C) and TCR tracking
(to 1 ppm/°C)
•
Very low noise < 35 dB and voltage coefficient
< 0.01 ppm/V
•
Ratio tolerance to 0.01 % (R
≥
200R)
•
Pre-tinned terminations over nickel barrier
•
Lead (Pb)-free available
PRA arrays can be used in most applications requiring a
matched pair (or set) of resistor elements. The networks
provide 1 ppm/°C TCR tracking, a ratio tolerance as tight as
0.01 % and outstanding stability. They are available in 1 mm,
1.35 mm and 1.82 mm pitch.
Pb-free
Available
RoHS*
COMPLIANT
TYPICAL PERFORMANCE
TCR
TOL
ABS
10 ppm/°C
ABS
0.1 %
TRACKING
2 ppm/°C
RATIO
0.05 %
DIMENSIONS
Land Pattern
R
S
R
P
Q
F
A
I: Independent resistors
E
Termination
Electrical diagram
R1
R2
R7
R8
PRA100
DIM.
mm
A
B
C
D
E
(1)
F
G
P
Q
R
S
0.38
1.6
0.4
0.65
+ 0.2
- 0.1
+ 0.2
- 0.2
+ 0.15
- 0.15
PRA 135
mil
63
16
25.5
10
mm
1.85
0.4
1.05
+ 0.2
- 0.1
+ 0.2
- 0.2
+ 0.15
- 0.15
PRA 182
mil
72
16
41
10
mm
3.0
0.4
1.3
+ 0.2
- 0.1
+ 0.2
- 0.2
+ 0.35
- 0.15
B
D
C
F
G
mil
118
16
51
10
Number
of resistors:
2 to
8
R1 = R2 = ... R8
0.25
0.25
0.25
C: One common point
N
resistors
R1
E
E = (N F) ± 0.2 mm
1
+ 0.2
-0
E = (N x F) ± 8 mil
53.1
15
41.3
12
40
31.5
1.82
0.38
+ 0.2
-0
R2
R7
R8
40
15
27.5
12
40
23.5
1.35
0.38
+ 0.2
-0
72
15
59.8
12
40
70.8
B
C
D
A
0.7
0.3
1
0.6
1.05
0.3
1
0.8
1.52
0.3
1
1.8
F
G
Number
of resistors:
2 to
8
R1 = R2 = ... R8
Notes:
(1)
E depends on number of resistors
* Pb containing terminations are not RoHS compliant, exemptions may apply
www.vishay.com
66
For technical questions, contact: sfer@vishay.com
Document Number: 53033
Revision: 23-Jan-07
PRA 100, 135, 182 (CNW)
High Precision Resistor Arrays
Vishay Sfernice
GLOBAL PART NUMBER INFORMATION
New Global Part Numbering: P0505Y1003BBT0933
P
R
A
1
0
0
I
4
-
5
K
6
2
B
W
B
T
2
8
GLOBAL
MODEL
PRA100
PRA135
PRA182
CONFIG.
I: Independent
C: Common
NUMBERS OF
RESISTORS
2 to 8
VALUE
Decimal
R or K
ABS. TOL.
B
= 0.1 %
D
= 0.5 %
RATIO TOL.
B
= 0.1 %
W
= 0.05 %
P
= 0.02 %
L
= 0.01 %
TERMINATION
B:
SnPb over
nickel barrier
N:
SnAg over
nickel barrier
G:
Gold over
nickel barrier
PACKAGING
Blank
=
Waffle Pack
T
(1)
= Tape
and Reel
OPTION
Leave
blank if no
option
Historical Part Number example: P 0505 Y 1003 B B TR R0933 e2
CNW
GLOBAL
MODEL
1368
REFERENCE
B:
Lead bearing version
N
and
G:
Lead (Pb)-free/
RoHS version
Historical Part Number example: P 0505 Y 1003 B B TR R0933 e2
PRA100
HISTORICAL
MODEL
I
CONFIG.
4
NUMBERS OF
RESISTORS
5K62
OHMIC VALUE
0.1 %
ABS. TOL.
0.05 %
RATIO TOL.
TR
PACKAGING
R0028
OPTION
Note:
(1)
Tape and Reel only available for maximum 5 resistors in the network
STANDARD ELECTRICAL SPECIFICATIONS
TEST
PRA 100
Resistance range:
PRA 135
PRA 182
Absolute
Tolerance:
Ratio
Absolute
TCR:
Ratio
PRA 100
Power rating:
PRA 135
PRA 182
Operating temperature range
(2)
Noise
Voltage coefficient
PRA 100
Limiting voltage:
PRA 135
PRA 182
(2)
SPECIFICATIONS
100
Ω
to 200 kΩ
100
Ω
to 300 kΩ
100
Ω
to 1 MΩ
± 0.5 % to ± 0.1 %
0.1 %, 0.05 %, 0.02 %, 0.01 % (R
≥
200 R)
± 10 ppm/°C
2 ppm/°C (1 ppm/°C on request)
100 mW per resistor
100 mW per resistor
100 mW per resistor
- 55 °C to + 155 °C
≤
- 35 dB
≤
0.01 ppm/V
35 V
75 V
100 V
CONDITION
- 40 °C + 125 °C
- 40 °C + 125 °C
at + 70 °C
at + 70 °C
at + 70 °C
Note:
For temperature up to 200 °C, please consult factory
For technical questions, contact: sfer@vishay.com
www.vishay.com
67
Document Number: 53033
Revision: 23-Jan-07
PRA 100, 135, 182 (CNW)
Vishay Sfernice
High Precision Resistor Arrays
MECHANICAL SPECIFICATIONS
Substrate
Technology
Film
Alumina
Thin film
Nickel chromium with mineral passivation
B type:
SnPb over nickel barrier
Terminations
N type:
SnAg over nickel barrier
G type:
Gold over nickel barrier
POWER RATING
Rated Power (%)
100
80
60
40
20
SPECIAL FEATURES
Resistance values can be different on a given network
(R max./R min. as high as 300). Tooling charges might
be required depending on the ohmic values in the
same network. Please, consult VISHAY SFERNICE for
ohmic values, tolerances and also temperature coefficient
(e.g. ± 1 ppm/°C) outside the standard range.
0
0
20
40
60 70
80
100
120
140 155
Ambient Temperature in °C
MARKING
On the primary package, printed information includes
VISHAY S.A. trademark series and model, schematic
number of resistors, ohmic value, absolute tolerance, ratio
tolerance, type of termination: B tinned over nickel barrier.
PACKAGING
Several types of packaging are available: waffle-pack and
tape and reel.
PERFORMANCE
DRIFTS
TESTS
CONDITIONS
CECC REQUIREMENTS
2.5 Un/2 s
- 55 °C + 155 °C/5 moisture cycles
- 55 °C + 155 °C/5 cycles 30'
1000 h/Pn at + 70 °C
260 °C/10 s
0.01 Pn at + 40 °C 93 % RH
1000 h/no load at + 155 °C
ABSOLUTE PER
(Typical Values)
0.05 % Rn + 0.05
Ω
0.1 % Rn + 0.05
Ω
0.05 % Rn + 0.05
Ω
0.1 % Rn + 0.05
Ω
0.05 % Rn + 0.05
Ω
0.1 % Rn + 0.05
Ω
0.1 % Rn + 0.05
Ω
RATIO
0.01 % Rn
0.01 % Rn
0.01 % Rn
0.02 % Rn
0.01 % Rn
0.01 % Rn
0.02 % Rn
Overload
Climatic sequences
Thermal shock
Load life
Resistance to solder heat
Moisture resistance
High temperature storage
Note:
Rn: nominal resistance
www.vishay.com
68
For technical questions, contact: sfer@vishay.com
Document Number: 53033
Revision: 23-Jan-07
