NOISE SUPPRESSION CAPACITORS
RE-L
SERIES
RE SERIES
・Wide temperature range
・Best price/size/performance series
UL :
CSA :
VDE :
SEV :
Safety Approvals
UL-1414, UL-1283
C22.2, No. 0,1 C22.2 No. 8
IEC60384-14Ⅱ/EN132400
IEC60384-14Ⅱ/EN132400
File No .
E47474, E78644
LR68886,
LR104926
10529-4670-7025
97,1 10224, 02
9717020/01
195312-01
306582
P97101052
T±0.5
MECHANICAL SPECIFICATIONS
Standoffs provided for improved cleanability
Polybutylene Terephthalate（FR-PBT）
UL-94 Flame Class V-O
Potting Material： UL-94 Flame Class V-O
Leads：
Tinned Copper Clad Steel
Capacitor：
Metallized Polypropylene Film
Case：
Case material：
SEMKO : IEC60384-14Ⅱ/EN132400
FIMKO : IEC60384-14Ⅱ/EN132400
DEMKO : IEC60384-14Ⅱ/EN132400
NEMKO : IEC60384-14Ⅱ/EN132400
Circuit diagram
W±0.5
H±0.5
d±0.05
F±1.0
Unit：mm
Rated voltage
Safety
Approvals
275V
AC（UL，CSA：250V）
Model
Capacitance
（μF ±10％）
0.01
0.012
0.015
0.018
0.022
0.027
0.033
0.039
0.047
0.056
0.068
0.082
0.1
0.12
0.15
0.18
0.22
0.27
0.33
0.39
0.47
0.56
0.68
0.82
1.0
1.2
1.5
1.8
2.2
External dimensions
W
H
T
F
d
Dissipation
factor
Test Voltage
Insulation Resistance
Class
symbol
RE103-L
*RE123-L
RE153-L
*RE183-L
RE223-L
*RE273-L
RE333-L
*RE393-L
RE473-L
*RE563-L
RE683-L
*RE823-L
RE104-L
*RE124-L
RE154-L
X2
*RE184-L
RE224-L
*RE274-L
RE334-L
*RE394-L
RE474-L
*RE564-L
RE684-L
*RE824-L
RE105-L
*RE125-L
RE155-L
*RE185-L
RE225-L
*Non-Stock: Consult Factory
10.5
12.0
11.5
4.5
10.0
5.5
0.6
Between line
C≦1μF
terminals
0.003max
1250Vrms
（f=10kHz） 50/60Hz
60sec
C＞1μF
0.002max
（f=1kHz）
Both line
terminals
to case
2000Vrms
50/60Hz
60sec
0.8
27.5
Between line
terminals
103∼334
15000MΩmin.
474∼225
5000Ω・F min.
Both line terminals
to case
100,000MΩmin.
（at 500V
DC
）
11.0
5.0
17.0
12.0
15.0
16.0
17.5
6.0
8.0
9.0
8.0
15.0
25.5
19.0
21.0
23.0
30.5
27.5
30.5
17.0
20.5
9.5
10.5
12.5
22.5
Operating temperature：−55∼＋100℃
