SPECIFICATIONS
Contact material:
Finish:
Insulator material:
Brass
Gold flash plated over nickel.
Nylon 6T
A
B
C
D
Dimensions
Pos. A
B
6 15.24 12.94
8 17.78 15.48
10 20.32 18.02
14 25.40 23.10
16 27.94 25.64
20 33.02 30.72
24 38.10 35.80
26 40.64 38.34
30 45.72 43.42
34 50.80 48.50
40 58.32 56.12
50 71.12 68.82
60 83.82 81.52
64 88.90 86.60
Series
Positions
Mounting
Plating
BHD
XX
XX
XX
Box header See chart ST=Straight
TN=Tin
RA=Right angle GDXX=Gold
SGXX=Selective gold
XX=[Flash if Blank], 15µ”,
30µ”, 50µ” gold
Date
Approved
Drawing
Name
Approved Howard
Checked Lizzy
Drawn Tina
0.0 ± 0.35
1
2
3
4
C
5.08
7.62
10.16
15.24
17.78
22.86
27.94
30.48
35.56
40.64
48.26
60.96
73.66
78.74
B
C
D
E
Latches
XX
[blank]=None
SLC=Short side latch holder
SL=Short latch (3.9mm) LLC=Long side latch holder
LL=Long latch (7.68mm) NLC=Empty side latch holder
NL=Empty latch holder
F
RoHS compliant
Rev.
Description
Options
XX
[blank]=None
SM=Surface mount
SPL=Special pin length
PF=Press Fit
KT=Kinked Terminal
(Retention Feature)
E
F
Date
08/06/07
08/06/07
08/06/07 Part No.:
Central Components Manufacturing
440 Lincoln Blvd., Middlesex, New Jersey 08846
Phone 732 469-5720 888 288-5152 Fax 732 469-1919
BHD-XX-RA-XX-XX-XX
G
7
8
9
G
0.00 ± 0.20 Angles ± 3°
UNIT: mm
5
6
Description: 2.54 Pitch Box Header Right Angle
