RMKD, RMKQ 48
Vishay Thin Film
Hermetic, Dual-In-Line or TO Package Resistor Networks
FEATURES
• High Stability: < 300ppm Max., 2000 hrs., Pn + 70°C
• Hermetic Cases: Dual-In-Line and TO99
Actual Size
TYPICAL PERFORMANCE
THROUGH HOLE
The superstable RMK nickel-chromium integrated networks
are available in a range of standard designs which bring a
completely new “state-of-the-art” to precision network
performance criteria.
Circuit designers can now incorporate into their circuitry the
ultimate in today’s performance characteristics as
“standards”, without needing to call out specially engineered
designs at premium prices.
v
TCR
TOL
ABS
10
ABS
0.05
TRACKING
1
RATIO
0.02
SCHEMATIC
Standard Configuration, Hermetic Case TO99
RMKQ48
7
8
1
R3
R1 R2
R4
6
5
4 Equal and Independent Resistors
4
2
3
Standard Configuration, 8 Leads Hermetic DIL
RMKD 408
RMKD 508
8
7
6
5
8
R2
R1
R2
R3
R1
1
2
3
4
1
2
3
R3
4
7
6
R4
R5
5
Standard Configuration, 16 Leads Hermetic DIL
RMKD86
16
15
14
13
12
11
10
9
R1
R2
R3
R4
R5
R6
R7
R8
4 Equal and Independent
Resistors
Dual Divider Feedback Network
with Equal Value Resistors
1
2
3
4
5
6
7
8
8 Equal and Independent Resistors
Standard Configuration, 14 Leads Hermetic DIL
RMKD714
14
13
12
11
10
9
8
RMKD914
14
R2
13
R4
12
11
R6
10
9
R8
R9
R1
R3
2
3
4
R5
5
6
R7
7
8
R1
R2
R3
R4
R5
R6
R7
1
2
3
4
5
6
7
1
7 Equal and Independent
Resistors
Quad Divider Feedback Network
with Equal Value Resistors
VISHAY THIN FILM • FRANCE +33.4.93.37.28.24 FAX: +33.4.93.37.27.31 • GERMANY +49.9287.710 FAX: +49 9287.70435 • ISRAEL +972.3.557.0945 FAX: +972.3.558.9121
• ITALY + 39.2.300.11919 FAX: +39.2.300.11999 • JAPAN +81.42.729.0661 FAX: +81.42.729.3400 • SINGAPORE +65.788.6668 FAX: +65.788.0988
• SWEDEN +46.8.594.70590 FAX: +46.8.594.70581 • UK +44 191 514 8237 FAX: +44 1953 457 722 • USA: (610) 407-4800 FAX: (610) 640-9081
www.vishay.com
114
Document Number: 60049
Revision 27-Apr-01
RMKD, RMKQ 48
Hermetic, Dual-In-Line or TO Package Resistor Networks
Vishay Thin Film
STANDARD ELECTRICAL SPECIFICATIONS
TEST
CONFIGURATION
Resistance Range
TCR:
Tracking
Absolute
Ratio
Absolute
Package
125mW
SPECIFICATIONS
RMK Q48, RMK D408, RMK D508, RMK D714, RMK D816, RMK D914
500Ω < R < 200KΩ
±
1ppm/°C Typical
±
2ppm/°C Max.
±
5ppm/°C typical
±
10ppm/°C Max.
±
0.05%
±
0.02%
±
0.01%
±
0.1%
±
0.05%
±
0.05%
250mW
250mW
250mW
250mW
250mW
@ + 70°C
2000 hrs., at + 70°C
- 55°C to + 125°C
0°C to + 70°C
- 55°C to + 125°C
CONDITIONS
Tolerance
Power Rating:
Stability (
∆
R Ratio)
Working Voltage
Operating Temperature Range
Storage Temperature Range
Noise
Thermal EMF
< 300ppm Max.
100Vcc on R
- 55°C to + 125°C
- 55°C to + 155°C
THROUGH HOLE
- 35dB typical
< 0.1µV/°C
MIL-STD-202, Md. 308
RMKQ 48
A
C
3
2
4
5
6
7
DIMENSIONS
in inches and millimeters
DIMENSION
A
ØH
B
C
øD
øE
øF
G
ØJ
K
øH
øJ
K
L
0.027
INCHES
Min.
Max.
0.500
0.164
—
0.016
0.315
0.346
0.029
—
0.137
45°
0.033
0.71
—
0.194
0.040
0.019
0.335
0.370
0.043
0.229
0.159
MILLIMETERS
Min.
Max.
12.70
4.19
—
0.41
8.00
8.89
0.74
—
3.05
45°
0.86
—
4.95
1.02
0.48
8.51
9.40
1.14
5.84
4.06
B
ØD
ØE ØF
1
G
8
L
RMKQ 408 and RMKD 508
DIMENSIONS
in inches and millimeters
DIMENSION
INCHES
0.401
0.046
0.035
0.086
0.129 Min.
0.018
0.100
0.050
0.290
0.009
0.300
MILLIMETERS
10.2
±
0.10
1.19
0.89
±
0.25
2.2
±
0.20
3.3 Min.
0.46
±
0.05
2.54
±
0.10
1.27
±
0.50
7.37
±
0.20
0.25
±
0.05
7.62
±
0.20
D
B1
A1
A
L
D
B1
A1
L
A
B
e1
S
C
eA
E
Index mark
B
e1
S
E
C
eA
VISHAY THIN FILM • FRANCE +33.4.93.37.28.24 FAX: +33.4.93.37.27.31 • GERMANY +49.9287.710 FAX: +49 9287.70435 • ISRAEL +972.3.557.0945 FAX: +972.3.558.9121
• ITALY + 39.2.300.11919 FAX: +39.2.300.11999 • JAPAN +81.42.729.0661 FAX: +81.42.729.3400 • SINGAPORE +65.788.6668 FAX: +65.788.0988
• SWEDEN +46.8.594.70590 FAX: +46.8.594.70581 • UK +44 191 514 8237 FAX: +44 1953 457 722 • USA: (610) 407-4800 FAX: (610) 640-9081
Document Number: 60049
Revision 27-Apr-01
www.vishay.com
115
RMKD, RMKQ 48
Vishay Thin Film
Hermetic, Dual-In-Line or TO Package Resistor Networks
DIMENSIONS
in inches and millimeters
RMKD 714 and RMKD 914
A
K
D
E
F
H
G
J
L
M
B
C
1
2
6 7
DIMENSION
A
B
C
D
E
F
G
H
J
K
L
M
INCHES
0.700
0.046
0.086
0.035
0.129
0.018
0.100
0.600
0.050
0.290
0.009
0.300
MILLIMETERS
17.78
±
0.20
1.19
2.20
±
0.20
0.89
±
0.25
3.30
0.46
±
0.05
2.54
±
0.10
15.24
±
0.10
1.27
±
0.50
7.37
±
0.20
0.25
±
0.05
7.62
±
0.20
Index mark
THROUGH HOLE
RMKD 816
DIMENSIONS
in inches and millimeters
A
K
B
D
C
E
F
G
L
H
J
M
1
2
7 8
DIMENSION
A
B
C
D
E
F
G
H
J
K
L
M
Index mark
INCHES
0.799
0.046
0.092
0.035
0.129
0.018
0.011
0.7
0.05
0.29
0.009
0.3
MILLIMETERS
20.30
±
0.20
1.19
2.35
±
0.20
0.89
±
0.25
3.3
0.46
±
0.05
2.54
±
0.1
17.78
±
0.1
1.27
±
0.5
7.37
±
0.2
0.25
±
0.05
7.62
±
0.2
MECHANICAL SPECIFICATIONS
Resistive Material
Passivation
Nichrome
Mineral Passivation Si
3
N
4
How to Order
Series
Style
Number of
Resistors
Number of
Pins
Ohmic
Value
100K
Ω
Absolute
Tolerance
±0.05%
Tolerance
Ratio
RMK
D
Q
= Quad
D
= Dual
7
14
0.02%
Custom packages available; please consult factory for additional configurations.
