5962-01-197-9514 Amplifier basic information:
5962-01-197-9514 is an OPERATIONAL AMPLIFIER. The commonly used packaging method is CAN8,.2
5962-01-197-9514 amplifier core information:
The minimum operating temperature of 5962-01-197-9514 is 70 °C. Maximum bias current at 25°C: 0.025 µA
How to simply check the efficiency of an amplifier? Looking at its slew rate, the nominal slew rate of 5962-01-197-9514 is 35 V/us. The maximum slew rate of 5962-01-197-9514 given by the manufacturer is 4 mA. Its minimum voltage gain is 70000. When the op amp is used in a closed loop, at a certain closed-loop gain (usually 1 or 2, 10, etc.), the frequency when the 5962-01-197-9514 gain becomes 0.707 times the low-frequency gain is 100000 kHz.
The nominal supply voltage of 5962-01-197-9514 is 15 V, and its corresponding nominal negative supply voltage is -15 V. The power supply range is: +-15 V. The input offset voltage of 5962-01-197-9514 is 7000 µV (Input offset voltage: the compensation voltage added between the two input terminals to make the output terminal of the op amp 0V (or close to 0V).)
Related dimensions for 5962-01-197-9514:
5962-01-197-9514 has 8 terminals. Its terminal position type is: BOTTOM. Total pins: 8
5962-01-197-9514 Amplifier Additional Information:
5962-01-197-9514 adopts the VOLTAGE-FEEDBACK architecture. It does not belong to the low offset class of amplifiers. The frequency compensation status of 5962-01-197-9514 is: YES (AVCL>=5). Its temperature grade is: COMMERCIAL. 5962-01-197-9514 is not Rohs certified.
The corresponding JESD-30 code is: O-MBCY-W8. The material of the 5962-01-197-9514 package is mostly METAL. And its package shape is ROUND. 5962-01-197-9514 package pin formats are: CYLINDRICAL. Its terminal form is: WIRE.
5962-01-197-9514 Amplifier basic information:
5962-01-197-9514 is an OPERATIONAL AMPLIFIER. The commonly used packaging method is CAN8,.2
5962-01-197-9514 amplifier core information:
The minimum operating temperature of 5962-01-197-9514 is 70 °C. Maximum bias current at 25°C: 0.025 µA
How to simply check the efficiency of an amplifier? Looking at its slew rate, the nominal slew rate of 5962-01-197-9514 is 35 V/us. The maximum slew rate of 5962-01-197-9514 given by the manufacturer is 4 mA. Its minimum voltage gain is 70000. When the op amp is used in a closed loop, at a certain closed-loop gain (usually 1 or 2, 10, etc.), the frequency when the 5962-01-197-9514 gain becomes 0.707 times the low-frequency gain is 100000 kHz.
The nominal supply voltage of 5962-01-197-9514 is 15 V, and its corresponding nominal negative supply voltage is -15 V. The power supply range is: +-15 V. The input offset voltage of 5962-01-197-9514 is 7000 µV (Input offset voltage: the compensation voltage added between the two input terminals to make the output terminal of the op amp 0V (or close to 0V).)
Related dimensions for 5962-01-197-9514:
5962-01-197-9514 has 8 terminals. Its terminal position type is: BOTTOM. Total pins: 8
5962-01-197-9514 Amplifier Additional Information:
5962-01-197-9514 adopts the VOLTAGE-FEEDBACK architecture. It does not belong to the low offset class of amplifiers. The frequency compensation status of 5962-01-197-9514 is: YES (AVCL>=5). Its temperature grade is: COMMERCIAL. 5962-01-197-9514 is not Rohs certified.
The corresponding JESD-30 code is: O-MBCY-W8. The material of the 5962-01-197-9514 package is mostly METAL. And its package shape is ROUND. 5962-01-197-9514 package pin formats are: CYLINDRICAL. Its terminal form is: WIRE.
| Parameter Name | Attribute value |
| Is it Rohs certified? | incompatible |
| Maker | Renesas Electronics Corporation |
| Parts packaging code | BCY |
| package instruction | , CAN8,.2 |
| Contacts | 8 |
| Reach Compliance Code | _compli |
| ECCN code | EAR99 |
| Amplifier type | OPERATIONAL AMPLIFIER |
| Architecture | VOLTAGE-FEEDBACK |
| Maximum bias current (IIB) at 25C | 0.025 µA |
| frequency compensation | YES (AVCL>=5) |
| Maximum input offset voltage | 7000 µV |
| JESD-30 code | O-MBCY-W8 |
| low-dissonance | NO |
| Nominal Negative Supply Voltage (Vsup) | -15 V |
| Number of functions | 1 |
| Number of terminals | 8 |
| Maximum operating temperature | 70 °C |
| Minimum operating temperature | |
| Package body material | METAL |
| Encapsulate equivalent code | CAN8,.2 |
| Package shape | ROUND |
| Package form | CYLINDRICAL |
| power supply | +-15 V |
| Certification status | Not Qualified |
| Nominal slew rate | 35 V/us |
| Maximum slew rate | 4 mA |
| Supply voltage upper limit | 22.5 V |
| Nominal supply voltage (Vsup) | 15 V |
| technology | BIPOLAR |
| Temperature level | COMMERCIAL |
| Terminal form | WIRE |
| Terminal location | BOTTOM |
| Nominal Uniform Gain Bandwidth | 100000 kHz |
| Minimum voltage gain | 70000 |
| broadband | YES |
| Base Number Matches | 1 |
| 5962-01-197-9514 | HA2-2625-7 | HA7-2625-7 | HA7-2622-8 | HA2-2622-8 | HA7-2620-8 | |
|---|---|---|---|---|---|---|
| Description | IC,OP-AMP,SINGLE,BIPOLAR,CAN,8PIN,METAL | IC,OP-AMP,SINGLE,BIPOLAR,CAN,8PIN,METAL | IC,OP-AMP,SINGLE,BIPOLAR,DIP,8PIN,CERAMIC | IC,OP-AMP,SINGLE,BIPOLAR,DIP,8PIN,CERAMIC | IC,OP-AMP,SINGLE,BIPOLAR,CAN,8PIN,METAL | HA7-2620-8 |
| Is it Rohs certified? | incompatible | incompatible | incompatible | incompatible | incompatible | incompatible |
| Maker | Renesas Electronics Corporation | Renesas Electronics Corporation | Renesas Electronics Corporation | Renesas Electronics Corporation | Renesas Electronics Corporation | Renesas Electronics Corporation |
| Parts packaging code | BCY | BCY | DIP | DIP | BCY | DIP |
| Contacts | 8 | 8 | 8 | 8 | 8 | 8 |
| Reach Compliance Code | _compli | not_compliant | not_compliant | not_compliant | not_compliant | not_compliant |
| Amplifier type | OPERATIONAL AMPLIFIER | OPERATIONAL AMPLIFIER | OPERATIONAL AMPLIFIER | OPERATIONAL AMPLIFIER | OPERATIONAL AMPLIFIER | OPERATIONAL AMPLIFIER |
| Architecture | VOLTAGE-FEEDBACK | VOLTAGE-FEEDBACK | VOLTAGE-FEEDBACK | VOLTAGE-FEEDBACK | VOLTAGE-FEEDBACK | VOLTAGE-FEEDBACK |
| Maximum bias current (IIB) at 25C | 0.025 µA | 0.025 µA | 0.025 µA | 0.025 µA | 0.025 µA | 0.015 µA |
| frequency compensation | YES (AVCL>=5) | YES (AVCL>=5) | YES (AVCL>=5) | YES (AVCL>=5) | YES (AVCL>=5) | YES (AVCL>=5) |
| Maximum input offset voltage | 7000 µV | 7000 µV | 7000 µV | 7000 µV | 7000 µV | 6000 µV |
| JESD-30 code | O-MBCY-W8 | O-MBCY-W8 | R-XDIP-T8 | R-XDIP-T8 | O-MBCY-W8 | R-XDIP-T8 |
| low-dissonance | NO | NO | NO | NO | NO | NO |
| Nominal Negative Supply Voltage (Vsup) | -15 V | -15 V | -15 V | -15 V | -15 V | -15 V |
| Number of functions | 1 | 1 | 1 | 1 | 1 | 1 |
| Number of terminals | 8 | 8 | 8 | 8 | 8 | 8 |
| Maximum operating temperature | 70 °C | 70 °C | 70 °C | 125 °C | 125 °C | 125 °C |
| Package body material | METAL | METAL | CERAMIC | CERAMIC | METAL | CERAMIC |
| Encapsulate equivalent code | CAN8,.2 | CAN8,.2 | DIP8,.3 | DIP8,.3 | CAN8,.2 | DIP8,.3 |
| Package shape | ROUND | ROUND | RECTANGULAR | RECTANGULAR | ROUND | RECTANGULAR |
| Package form | CYLINDRICAL | CYLINDRICAL | IN-LINE | IN-LINE | CYLINDRICAL | IN-LINE |
| power supply | +-15 V | +-15 V | +-15 V | +-15 V | +-15 V | +-15 V |
| Nominal slew rate | 35 V/us | 35 V/us | 35 V/us | 35 V/us | 35 V/us | 35 V/us |
| Maximum slew rate | 4 mA | 4 mA | 4 mA | 4 mA | 4 mA | 3.7 mA |
| Supply voltage upper limit | 22.5 V | 22.5 V | 22.5 V | 22.5 V | 22.5 V | 22.5 V |
| Nominal supply voltage (Vsup) | 15 V | 15 V | 15 V | 15 V | 15 V | 15 V |
| technology | BIPOLAR | BIPOLAR | BIPOLAR | BIPOLAR | BIPOLAR | BIPOLAR |
| Temperature level | COMMERCIAL | COMMERCIAL | COMMERCIAL | MILITARY | MILITARY | MILITARY |
| Terminal form | WIRE | WIRE | THROUGH-HOLE | THROUGH-HOLE | WIRE | THROUGH-HOLE |
| Terminal location | BOTTOM | BOTTOM | DUAL | DUAL | BOTTOM | DUAL |
| Nominal Uniform Gain Bandwidth | 100000 kHz | 100000 kHz | 100000 kHz | 100000 kHz | 100000 kHz | 100000 kHz |
| Minimum voltage gain | 70000 | 70000 | 70000 | 60000 | 60000 | 70000 |
| broadband | YES | YES | YES | YES | YES | YES |
| package instruction | , CAN8,.2 | , CAN8,.2 | DIP, DIP8,.3 | - | , CAN8,.2 | DIP, DIP8,.3 |
| ECCN code | EAR99 | EAR99 | EAR99 | EAR99 | EAR99 | - |
| Certification status | Not Qualified | - | - | Not Qualified | Not Qualified | Not Qualified |
| JESD-609 code | - | e0 | e0 | e0 | e0 | e0 |
| Terminal surface | - | Tin/Lead (Sn/Pb) | Tin/Lead (Sn/Pb) | Tin/Lead (Sn/Pb) | Tin/Lead (Sn/Pb) | Tin/Lead (Sn/Pb) |
