SB2150~SB2200
Power Schottky Rectifier - 2Amp 150~200Volt
□
Features
-Low forward voltage drop
-High current capability
-High reliability
-High surge current capability
-Epitaxial construction
DO-41
□
Mechanical data
-Case：Molded plastic
-Epoxy：UL 94V-0 rate flame retardant
-Lead：Axial leads, solderable per MIL-STD-202,method 208 guaranteed
-Polarity：Color band denotes cathode end
-Mounting position：Any
-Weight：0.34 grams
.107(2.7)
.080(2.0)
.034(0.9)
.028(0.7)
□
Maximum ratings and Electrical characteristics
TYPE
Maximum Recurrent Peak Reverse Voltage
Maximum RMS Voltage
Maximum DC Blocking Voltage
Maximum Average Forward Rectified Current
Peak Forward Surge Current, 8.3ms single half sine-wave superimposed
on rated load
Maximum Instantaneous Forward Voltage at 2.0A
Maximum DC Reverse Current at Rated DC
Blocking Voltage
Typical Junction Capacitance
Typical Thermal Resistance R
θ
JA
Operating Temperature Range T
J
Storage Temperature Range T
STG
Note: Pulse Test : 380μs pulse width, 2% duty cycle
September 2008 / Rev.6.2
SB2150
150
105
150
2.0
50
0.88
0.01
10
170
30
-50 to +175
-50 to +150
SB2200
200
140
200
1.0(25.4)
.205(5.2)
.166(4.2)
1.0(25.4)
UNIT
V
V
V
A
A
0.90
V
mA
pF
ºC/W
ºC
ºC
Ta = 25ºC
Ta = 100ºC
http:// www.sirectsemi.com
1
SB2150~SB2200
2.8
AVERAGE FORWARD CURRENT
AMPERES
2.4
2.0
1.6
1.2
0.8
0.4
0
0
25
50
75
100
125
150
175
200
100
INSTANTANEOUS FORWARD CURRENT , (A)
10
1
AMBIENT TEMPERATURE ,
℃
Figure 1. Forward Current Derating Curve
0.1
Tj=25℃
Pulse Width 300us
1% Duty Cycle
50
PEAK FORWARD SURGE CURRENT
AMPERES
0.01
40
0.1
0.3
0.5
0.7
0.9
1.1
1.3
1.5
FORWARD VOLTAGE , VOLTS
30
Figure 4. Typical Forward Characteristics
20
10
Single Half-Sine-Wave
(JEDEC METHOD)
100
0
1
2
5
10
20
50
100
NUMBER OF CYCLES AT 60Hz
REVERSE LEAKAGE CURRENT , (mA)
10
Figure 2. Maximum Non-repetitive Surge Current
700
600
1
T
j
= 75℃
CAPACITANCE , (pF)
500
400
300
200
100
0.1
T
j
= 25℃
0.01
0
20
40
60
80
100
120
140
PERCENT OF RATED PEAK REVERSE VOLTAGE , (%)
0
0.01
0.1
1
10
100
Figure 5. Typical Reverse Characteristics
REVERSE VOLTAGE , VOLTS
Figure 3. Typical Junction Capacitance
