SB280A-G Overview

Leaded Schottky Barrier Rectifiers

Preview

Download Datasheet

View All

Leaded Schottky Barrier Rectifiers

Comchip

SMD Diode Specialist

SB220-G Thru. SB2100-G

Voltage: 20 to 100 V

Current: 2.0 A

RoHS Device

DO-41

Features

-Low

drop down voltage.

-Metal-Semiconductor junction with guard ring

-High

surge current capability

-Silicon

epitaxial planar chips.

-For use in low voltage, high efficiency inverters,

free wheeling, and polarity protection applications

-Lead-free

part, meet RoHS requirements.

.205(5.2)

.160(4.1)

1.0(25.4) Min.

.107(2.7)

.080(2.0)

Mechanical data

-Epoxy:

UL94-V0 rated flame retardant

-Case:

Molded plastic body DO-41

-Terminals:

Solderable per MIL-STD-750 Method 2026

-Polarity:

Color band denotes cathode end

-Mounting

Position: Any

-Weight:

0.4 grams

.034(0.86)

.028(0.70)

1.0(25.4) Min.

Dimensions in inches and (millimeter)

Electrical Characteristics (at T

=25°C unless otherwise noted)

Ratings at 25°C ambient temperature unless otherwise specified.

Parameter

Maximum recurrent peak reverse voltage

Maximum RMS voltage

Maximum DC blocking voltage

Maximum average forward rectified current

0.375” (9.5mm) lead length at TA=75°C, See Figure 1

Symbol

RRM

RMS

(AV)

220-G

240-G

245-G

250-G

2.0

260-G

280-G

2100-G

100

Unit

Peak forward surge current

8.3ms single half sine-wave superimposed on rated load

(JEDEC method)

TL=110°C

FSM

0.50

0.70

0.85

Maximum forward voltage at 2.0A

Maximum DC reverse current

At rated DC blocking voltage

=25°C

=100°C

0.5

θJA

θJL

STG

-55 to +125

-55 to +150

150

35.0

20.0

-55 to +150

250

°C/W

°C

Typical junction capacitance (Note 1)

Typical t

hermal resistance

(Note 2)

Operating junction temperature range

Storage temperature range

NOTES:

Measured at 1.0MHz and applied reverse voltage of 4.0 Volts

2. Thermal resistance junction to ambient and junction to lead.

REV:A

QW-BB041

Page 1

Comchip Technology CO., LTD.
