TM
Application Specific Crystal Oscillator 7.0 x 5.0mm
3.3V HCSL Low Jitter 100MHz PCIe
®
2.0 XO
SHPCIE100
7.0 x 5.0mm Ceramic SMD
ASSP XO™ for Networking
Package:
Product Features
• Provides 100 MHz HCSL output for
interfacing to standard PCIe
®
devices
• Very low PCIe 2.0 jitter - 1.8ps RMS (typ.)
• Thicker crystal for improved reliability
• Pb-free & RoHS compliant
• Industrial temperature range
Recommended Land Pattern:
Product Description
The SHPCIE100 3.3V crystal clock oscillator
achieves superb jitter for PCIe
®
1.0 &
2.0 applications. The output clock signal,
generated internally with a patented
oscillator design, is compatible with HCSL
logic levels. The device, available on tape
and reel, is contained in a 7.0 x 5.0mm
surface-mount ceramic package.
Pin Functions:
Pin
Function
1
2
3
4
5
6
OE Function
N/C
Ground
OUT
OUT
V
CC
Applications
• Server
• Network Switch/Router
• Telecom Switch
• Media Box
• Graphics Card
• Host Bus Adapter
*Extended high frequency power decoupling is recommended (see test circuit for minimum
recommendation). To ensure optimal performance, do not route RF traces beneath the
package.
Part Ordering Information:
SHPCIE100
SaRonix-eCera™ is a Pericom® Semiconductor company
•
US: +1-408-435-0800 TW: +886-3-4518888
•
www.pericom.com
04/07/10
B
All specifications are subject to change without notice.
SHPCIE100
Rev C
3.3V HCSL Low Jitter 100 MHz PCIe
®
2.0 XO
SHPCIE100
TM
Application Specific Crystal Oscillator 7.0 x 5.0mm
Electrical Performance
Parameter
Min.
Typ.
Max.
Units
Notes
Output Frequency
Supply Voltage
Supply Current, Output Enabled
Supply Current, Output Disabled
Frequency Stability
Operating Temperature Range
Output Logic 0, V
OL
Output Logic 1, V
OH
Output Load
Duty Cycle
Rise and Fall Time
Jitter, Phase RMS (1-σ)
Jitter, pk–pk
45
-40
-0.15
0.66
2.97
100
3.30
3.63
40
10
±50
+85
0.9
R
s
= 33Ω, R
p
= 50Ω, C
L
= 2pF
55
0.7
1.8
27
2.5
40
MHz
V
mA
mA
ppm
°C
V
V
output requires termination
%
ns
ps
ps
Measured 50% of waveform
Maximum measured from
V
OL
= 0.175V to V
OH
= 0.525V
As defined by PCI-SIG for PCIe
®
2.0
reference clock
100,000 random periods
See Note 1 below
Industrial
Notes:
1. Stability includes all combinations of operating temperature, load changes, rated input (supply) voltage changes, initial calibration tolerance (25°C),
aging (5 year at 40°C average effective ambient temperature), shock and vibration.
2. For specifications othere than those listed, please contact sales.
Output Enable / Disable Function
Parameter
Min.
Typ.
Max.
Units
Notes
Input Voltage (pin 1), Output Enable
Input Voltage (pin 1), Output Disable (low power standby)
Output Disable Delay
Output Enable Delay
2.2
0.8
200
10
V
V
ns
ms
or open
Outputs disabled to Hi-Z
Absolute Maximum Ratings
Parameter
Min.
Typ.
Max.
Units
Notes
Storage Temperature
-55
+125
°C
For the latest product information visit:
http://www.pericom.com/products/asspxo/SHPCIE100
For test circuit go to:
http://www.pericom.com/pdf/sre/tc_hcsl.pdf
For soldering reflow profile and reliability test ratings go to:
http://www.pericom.com/pdf/sre/reflow.pdf
For typical phase noise go to:
http://www.pericom.com/pdf/sre/pn_SHPCIE100.pdf
For tape and reel information go to:
http://www.pericom.com/pdf/sre/tr_7050.pdf
SaRonix-eCera™ is a Pericom® Semiconductor company
•
US: +1-408-435-0800 TW: +886-3-4518888
•
www.pericom.com
04/07/10
B
All specifications are subject to change without notice.
SHPCIE100
Rev C
