SFM11-M THRU SFM18-M
SURFACE MOUNT SUPER FAST RECTIFIER
Reverse Voltage - 50 to 600 Volts
Forward Current - 1.0 Ampere
SOD-123FL
Cathode Band
Top View
FEATURES
Glass passivated device
Ideal for surface mouted applications
Low reverse leakage
Metallurgically bonded construction
High temperature soldering guaranteed:
250 C/10 seconds,0.375
”
(9.5mm) lead length,
5 lbs. (2.3kg) tension
2.8
±
0.1
1.1± 0.15
0.10-0.30
0.6
±
0.25
１．０±
0.2
1.8± 0.1
MECHANICAL DATA
Case:
JEDEC SOD-123FL molded plastic body over passivated chip
Terminals:
Plated axial leads, solderable per MIL-STD-750,
Method 2026
Polarity:
Color band denotes cathode end
Mounting Position:
Any
Weight:0.0007
ounce, 0.02 grams
3.7
±
0.2
Dimensions in millimeters
MAXIMUM RATINGS AND ELECTRICAL CHARACTERISTICS
Ratings at 25 C ambient temperature unless otherwise specified.
Single phase half-wave 60Hz,resistive or inductive load,for capacitive load current derate by 20%.
MDD Catalog Number
Maximum repetitive peak reverse voltage
Maximum RMS voltage
Maximum DC blocking voltage
Maximum average forward rectified current
Peak forward surge current
8.3ms single half sine-wave superimposed on
rated load (JEDEC Method)
Maximum instantaneous forward voltage at1.0A
Maximum DC reverse current
T
A
=25 C
at rated DC blocking voltage
T
A
=100 C
Maximum reverse recovery time (NOTE 1)
Typical junction capacitance (NOTE 2)
Typical thermal resistance (NOTE 3)
Operating junction and storage temperature range
SYMBOLS
SFM11-M SFM12-M SFM13-M SFM14-M SFM15-M SFM16-M SFM18-M
UNITS
VOLTS
VOLTS
VOLTS
Amp
E1A
E1B
E1C
E1D
E1E
E1G
E1J
V
RRM
V
RMS
V
DC
I
(AV)
50
35
50
100
70
100
150
105
150
200
140
200
1.0
300
210
300
400
280
400
600
420
600
I
FSM
V
F
I
R
trr
C
J
R
θ
JA
T
J
,
T
STG
0.95
25.0
1.25
5.0
100.0
35
10
85
-55 to +150
1.7
Amps
Volts
µ
A
ns
pF
°C/W
C
Note:
1.Measured with IF=0.5A, IR=1A, Irr=0.25A.
2.Measured at 1MHz and applied reverse voltage of 4.0V D.C.
3.PCB mounted on 0.2*0.2" (5.0*5.0mm) coppeer pad area.
RATINGS AND CHARACTERISTIC CURVES SFM11-M THRU SFM18-M
FIG. 1- FORWARD CURRENT DERATING CURVE
FIG. 2-MAXIMUM NON-REPETITIVE PEAK FORWARD
SURGE CURRENT
AVERAGE FORWARD RECTIFIED CURRENT,
AMPERES
PEAK FORWARD SURGE CURRENT,
AMPERES
1.0
30
8.3ms SINGLE HALF SINE-WAVE
(JEDEC Method)
25
0.8
20
0.6
15
0.4
Single Phase
Half Wave 60Hz
Resistive or
inductive Load
10
0.2
5.0
0
0
25
50
75
100
125
150
175
0
1
10
100
AMBIENT TEMPERATURE, C
NUMBER OF CYCLES AT 60 Hz
INSTANTANEOUS REVERSE CURRENT,
MICROAMPERES
FIG. 3-TYPICAL INSTANTANEOUS FORWARD
CHARACTERISTICS
FIG. 4-TYPICAL REVERSE CHARACTERISTICS
1,000
INSTANTANEOUS FORWARD
CURRENT,AMPERES
20
10
T
J
=25 C
PULSE WIDTH=300
µs
1%DUTY CYCLE
100
1
10
TJ=100 C
1
0.1
SFM11-SFM14
SFM13-SFM16
SFM18
0.1
TJ=25 C
0.01
0
0.4
0.8
1.2
1.6
1.8
0.01
0
20
40
60
80
100
INSTANTANEOUS FORWARD VOLTAGE,
VOLTS
PERCENT OF PEAK REVERSE VOLTAGE,%
FIG. 5-TYPICAL JUNCTION CAPACITANCE
TRANSIENT THERMAL IMPEDANCE,
C/W
FIG. 6-TYPICAL TRANSIENT THERMAL IMPEDANCE
100
JUNCTION CAPACITANCE, pF
10
1
0.1
0.01
0.1
1
10
100
REVERSE VOLTAGE,VOLTS
t,PULSE DURATION,sec.
The cruve graph is for reference only, can't be the basis for judgment(曲线图仅供参考)!
