EDJ2108BDBG-DJ-F

Description
DDR DRAM, 256MX8, 0.255ns, CMOS, PBGA78,
Categorystorage    storage
File Size434KB,30 Pages
ManufacturerMicron Technology
Websitehttp://www.mdtic.com.tw/
Environmental Compliance
Download Datasheet Parametric View All

EDJ2108BDBG-DJ-F Overview

DDR DRAM, 256MX8, 0.255ns, CMOS, PBGA78,

EDJ2108BDBG-DJ-F Parametric

Parameter NameAttribute value
Is it Rohs certified?conform to
MakerMicron Technology
package instructionFBGA, BGA78,9X13,32
Reach Compliance Codecompli
Maximum access time0.255 ns
Maximum clock frequency (fCLK)667 MHz
I/O typeCOMMON
interleaved burst length8
JESD-30 codeR-PBGA-B78
memory density2147483648 bi
Memory IC TypeDDR DRAM
memory width8
Number of terminals78
word count268435456 words
character code256000000
Maximum operating temperature85 °C
Minimum operating temperature
organize256MX8
Output characteristics3-STATE
Package body materialPLASTIC/EPOXY
encapsulated codeFBGA
Encapsulate equivalent codeBGA78,9X13,32
Package shapeRECTANGULAR
Package formGRID ARRAY, FINE PITCH
power supply1.5 V
Certification statusNot Qualified
refresh cycle8192
Continuous burst length8
Maximum standby current0.012 A
Maximum slew rate0.17 mA
Nominal supply voltage (Vsup)1.5 V
surface mountYES
technologyCMOS
Temperature levelOTHER
Terminal formBALL
Terminal pitch0.8 mm
Terminal locationBOTTOM
Base Number Matches1
COVER
DATA SHEET
2G bits DDR3 SDRAM
EDJ2104BDBG (512M words
×
4 bits)
EDJ2108BDBG (256M words
×
8 bits)
Specifications
• Density: 2G bits
• Organization
— 64M words
×
4 bits
×
8 banks (EDJ2104BDBG)
— 32M words
×
8 bits
×
8 banks (EDJ2108BDBG)
• Package
— 78-ball FBGA (EDJ2104BDBG, EDJ2108BDBG)
— Lead-free (RoHS compliant) and Halogen-free
• Power supply: VDD = 1.5V
±
0.075V
• Data rate
— 1866Mbps/1600Mbps/1333Mbps/1066Mbps/
800Mbps (max)
• 1KB page size
— Row address: A0 to A14
— Column address: A0 to A9, A11 (EDJ2104BDBG)
A0 to A9 (EDJ2108BDBG)
• Eight internal banks for concurrent operation
• Interface: SSTL_15
• Burst length (BL): 8 and 4 with Burst Chop (BC)
• Burst type (BT):
— Sequential (8, 4 with BC)
— Interleave (8, 4 with BC)
• /CAS Latency (CL): 5, 6, 7, 8, 9, 10, 11, 13
• /CAS Write Latency (CWL): 5, 6, 7, 8, 9
• Precharge: auto precharge option for each burst
access
• Driver strength: RZQ/7, RZQ/6 (RZQ = 240Ω)
• Refresh: auto-refresh, self-refresh
• Refresh cycles
— Average refresh period
7.8µs at 0°C
TC
+85°C
3.9µs at +85°C < TC
+95°C
• Operating case temperature range
— TC = 0°C to +95°C
Features
• Double-data-rate architecture: two data transfers per
clock cycle
• The high-speed data transfer is realized by the 8 bits
prefetch pipelined architecture
• Bi-directional differential data strobe (DQS and /DQS)
is transmitted/received with data for capturing data at
the receiver
• DQS is edge-aligned with data for READs; center-
aligned with data for WRITEs
• Differential clock inputs (CK and /CK)
• DLL aligns DQ and DQS transitions with CK transitions
• Commands entered on each positive CK edge; data
and data mask referenced to both edges of DQS
• Data mask (DM) for write data
• Posted /CAS by programmable additive latency for
better command and data bus efficiency
• On-Die Termination (ODT) for better signal quality
— Synchronous ODT
— Dynamic ODT
— Asynchronous ODT
• Multi Purpose Register (MPR) for pre-defined pattern
read out
• ZQ calibration for DQ drive and ODT
• Programmable Partial Array Self-Refresh (PASR)
• /RESET pin for Power-up sequence and reset function
• SRT range:
— Normal/extended
• Programmable Output driver impedance control
Document. No. E1772E40 (Ver. 4.0)
Date Published December 2012 (K) Japan
Printed in Japan
URL: http://www.elpida.com
©
Elpida Memory, Inc. 2011-2012
