NTE30135 thru NTE30139

Super Bright LED Indicators

5mm, Bullet Head Type

Features:

Low Power Consumption

High Efficiency

General Purpose Leads

High Intensity

All 5mm Bullet Head Super Bright Types

/Water Clear Lens:

NTE30135 (Yellow Green, AIGalnP)

NTE30136 (Yellow, AlGalnP)

NTE30137 (Red, AlGalnP)

NTE30138 (Blue, InGaN)

NTE30139 (White, InGaN)

Absolute Maximum Ratings:

= +25C unless otherwise specified)

Power Dissipation, P

NTE30135, NTE30136, NTE30137 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 75mW

NTE30138, NTE30139 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 90mW

Peak Forward Current (1/10th Duty Cycle, 0.1ms Pulse Width), I

. . . . . . . . . . . . . . . . . . . . 100mA

Continuous Forward Current, I

NTE30135, NTE30136, NTE30137 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30mA

NTE30138, NTE30139 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25mA

Derating Linear from +50C . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 0.4mA/C

Reverse Voltage, V

. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5V

Operating Temperature Range, T

opr

. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

−40

to +85C

Storage Temperature Range, T

stg

. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

−40

to +100C

Lead Temperature (During Soldering, 4mm from Body, 5sec Max), T

. . . . . . . . . . . . . . . . . . +260C

Electrical Optical Characteristics:

= +25C unless otherwise specified)

Parameter

Luminous Intensity

NTE30135

NTE30136

NTE30137

NTE30138

NTE30139

View Angle of Half Power

Chromaticity Coordinates

(NTE30139

ONLY)

Color Temperature (NTE30139

ONLY)

1/2

CCT

= 20mA

Symbol

Test Conditions

= 20mA

Min

600

−

Typ

1000

5000

4000

12000

40000

0.29

9500

Max

−

Unit

mcd

deg
