GS1575B / GS9075B HD-LINX® II Multi-Rate SDI Automatic Reclocker
Features
GS1575B
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
SMPTE 292M, 259M and 344M compliant
Supports data rates of 143, 177, 270, 360, 540, 1483.5, 1485
Mb/s
Supports DVB-ASI at 270Mb/s
Pb-free and RoHS Compliant
Auto and Manual Modes for rate selection
Standards indication in Auto Mode
4:1 input multiplexer
Loss of Signal (LOS) Output
Lock Detect Output
On-chip Input and Output Termination
Differential 50Ω inputs and outputs
Mute, Bypass and Autobypass functions
SD/HD indication output to control GS1528A Dual Slew-Rate
Cable Driver
Single 3.3V power supply
Operating temperature range: 0°C to 70°C
Description
The GS1575B/9075B is a Multi-Rate Serial Digital Reclocker
designed to automatically recover the embedded clock
from a digital video signal and re-time the incoming video
data.
The GS1575B Serial Digital Reclocker will recover the
embedded clock signal and re-time the data from a SMPTE
292M, SMPTE 259M or SMPTE 344M compliant digital
video signal.
The GS9075B Serial Digital Reclocker will recover the
embedded clock signal and re-time the data from a SMPTE
259M or SMPTE 344M compliant digital video signal.
The GS1575B/9075B removes the high frequency jitter
components from the bit-serial stream. Input termination is
on-chip for seamless matching to 50Ω transmission lines.
An LVPECL compliant output interfaces seamlessly to the
GS1578A/GS9078A Cable Driver.
The GS1575B/9075B can operate in either auto or manual
rate selection mode. In Auto mode the device will
automatically detect and lock onto incoming SMPTE SDI
data signals at any supported rate. For single rate data
systems, the GS1575B/9075B can be configured to operate
in Manual mode. In both modes, the device requires only
one external crystal to set the VCO frequency when not
locked and provides adjustment free operation.
In systems which require passing of non-SMPTE data rates,
the GS1575B/9075B can be configured to either
automatically or manually enter a bypass mode in order to
pass the signal without reclocking.
The ASI/177 input pin allows for manual selection of
support of either 177Mb/s or DVB-ASI inputs.
The GS1575B/9075B is Pb-free, and the encapsulation
compound does not contain halogenated flame retardant.
This component and all homogeneous sub-components are
RoHS compliant.
GS9075B
•
•
•
•
•
•
•
•
•
•
•
•
•
•
SMPTE 259M and 344M compliant
Supports data rates of 143, 177, 270, 360, and 540Mb/s
Supports DVB-ASI at 270Mb/s
Pb-free and RoHS Compliant
Auto and Manual Modes for rate selection
Standards indication in Auto Mode
4:1 input multiplexer
Loss of Signal (LOS) Output
Lock Detect Output
On-chip Input and Output Termination
Differential 50Ω inputs and outputs
Mute, Bypass and Autobypass functions
Single 3.3V power supply
Operating temperature range: 0°C to 70°C
Applications
GS1575B
•
SMPTE 292M, SMPTE 259M and SMPTE 344M Serial Digital
Interfaces
GS9075B
•
SMPTE 259M and SMPTE 344M Serial Digital Interfaces.
GS1575B / GS9075B HD-LINX® II Multi-Rate SDI
Automatic Reclocker
Data Sheet
40063 - 1
June 2009
www.gennum.com
1 of 28
Revision History
Version
1
0
ECR
152100
141777
PCN
–
–
Date
June 2009
August 2006
Changes and/or Modifications
Updated document format.
Converting
to Preliminary Data
Sheet.
Removed ‘Proprietary and
Confidential’
footer.
New Document.
A
141210
–
July 2006
Contents
Features.................................................................................................................................................................1
Applications.........................................................................................................................................................1
Description...........................................................................................................................................................1
Revision History .................................................................................................................................................3
1. Pin Out...............................................................................................................................................................5
1.1 GS1575B Pin Assignment ...............................................................................................................5
1.2 GS9075B Pin Assignment ...............................................................................................................6
1.3 Pin Descriptions ................................................................................................................................7
2. Electrical Characteristics ......................................................................................................................... 10
2.1 Absolute Maximum Ratings ....................................................................................................... 10
2.2 DC Electrical Characteristics ..................................................................................................... 10
2.3 AC Electrical Characteristics ..................................................................................................... 11
3. Input / Output Circuits ............................................................................................................................. 13
4. Detailed Description.................................................................................................................................. 16
4.1 Slew Rate Phase Lock Loop (S-PLL) ......................................................................................... 16
4.2 VCO .................................................................................................................................................... 17
4.3 Charge Pump ................................................................................................................................... 17
4.4 Frequency Acquisition Loop — The Phase-Frequency Detector .................................. 18
4.5 Phase Acquisition Loop — The Phase Detector ................................................................... 18
4.6 4:1 Input Mux .................................................................................................................................. 19
4.7 Automatic and Manual Data Rate Selection ......................................................................... 19
4.8 Bypass Mode ................................................................................................................................... 20
4.9 DVB-ASI Operation ....................................................................................................................... 21
4.10 Lock and LOS Indicators ........................................................................................................... 21
4.11 Output Drivers and Serial Clock Outputs ........................................................................... 22
4.12 Output Mute .................................................................................................................................. 22
5. Typical Application Circuits ................................................................................................................... 23
6. Package & Ordering Information .......................................................................................................... 25
6.1 Package Dimensions ..................................................................................................................... 25
6.2 Recommended PCB Footprint ................................................................................................... 26
GS1575B / GS9075B HD-LINX® II Multi-Rate SDI
Automatic Reclocker
Data Sheet
40063 - 1
June 2009
3 of 28
