SI2319DS

Description
VISHAY SILICONIX - SI2319DS-T1-E3 - P CHANNEL MOSFET; -40V; -3A; TO-236
CategoryDiscrete semiconductor    The transistor
File Size200KB,9 Pages
ManufacturerVishay
Websitehttp://www.vishay.com
Download Datasheet Parametric View All

SI2319DS Overview

VISHAY SILICONIX - SI2319DS-T1-E3 - P CHANNEL MOSFET; -40V; -3A; TO-236

SI2319DS Parametric

Parameter NameAttribute value
Is it lead-free?Contains lead
Is it Rohs certified?incompatible
MakerVishay
Parts packaging codeSOT-23
package instructionSMALL OUTLINE, R-PDSO-G3
Contacts3
Reach Compliance Codeunknow
ECCN codeEAR99
ConfigurationSINGLE WITH BUILT-IN DIODE
Minimum drain-source breakdown voltage40 V
Maximum drain current (ID)2.3 A
Maximum drain-source on-resistance0.082 Ω
FET technologyMETAL-OXIDE SEMICONDUCTOR
JEDEC-95 codeTO-236AB
JESD-30 codeR-PDSO-G3
JESD-609 codee0
Number of components1
Number of terminals3
Operating modeENHANCEMENT MODE
Maximum operating temperature150 °C
Package body materialPLASTIC/EPOXY
Package shapeRECTANGULAR
Package formSMALL OUTLINE
Peak Reflow Temperature (Celsius)240
Polarity/channel typeP-CHANNEL
Certification statusNot Qualified
surface mountYES
Terminal surfaceTIN LEAD
Terminal formGULL WING
Terminal locationDUAL
Maximum time at peak reflow temperature30
transistor applicationsSWITCHING
Transistor component materialsSILICON
Si2319DS
Vishay Siliconix
P-Channel 40-V (D-S) MOSFET
PRODUCT SUMMARY
V
DS
(V)
- 40
R
DS(on)
(Ω)
0.082 at V
GS
= - 10 V
0.130 at V
GS
= - 4.5 V
I
D
(A)
b
- 3.0
- 2.4
FEATURES
Halogen-free According to IEC 61249-2-21
Available
TrenchFET
®
Power MOSFET
APPLICATIONS
• Load Switch
TO-236
(SOT-23)
G
1
3
D
S
2
Top View
Si2319DS (C9)*
*Marking Code
Ordering Information:
Si2319DS-T1-E3 (Lead (Pb)-free)
Si2319DS-T1-GE3 (Lead (Pb)-free and Halogen-free)
ABSOLUTE MAXIMUM RATINGS
T
A
= 25 °C, unless otherwise noted
Parameter
Drain-Source Voltage
Gate-Source Voltage
Continuous Drain Current (T
J
= 150 °C)
b
Pulsed Drain Current
a
Continuous Source Current (Diode Conduction)
b
Power Dissipation
b
Operating Junction and Storage Temperature Range
T
A
= 25 °C
T
A
= 70 °C
T
A
= 25 °C
T
A
= 70 °C
Symbol
V
DS
V
GS
I
D
I
DM
I
S
P
D
T
J
, T
stg
- 1.0
1.25
0.8
- 55 to 150
- 3.0
- 2.4
- 12
- 0.62
0.75
0.48
W
°C
5s
Steady State
- 40
± 20
- 2.3
- 1.85
A
Unit
V
THERMAL RESISTANCE RATINGS
Parameter
Maximum Junction-to-Ambient
b
Maximum Junction-to-Ambient
c
Maximum Junction-to-Foot (Drain)
Notes:
a. Pulse width limited by maximum junction temperature.
b. Surface mounted on FR4 board, t
5 s.
c. Surface Mounted on FR4 board.
For Spice model information via the worldwide web: www.vishay.com/www/product/spice.htm.
Document Number: 72315
S09-0130-Rev. C, 02-Feb-09
www.vishay.com
1
Symbol
R
thJA
R
thJF
Typical
75
120
40
Maximum
100
166
50
°C/W
Unit
