SPECIFICATION FOR APPROVAL
REF :
PROD.
NAME
PAGE: 1
SHIELDED SMD
POWER INDUCTOR
ABC'S DWG NO.
ABC'S ITEM NO.
SS0804□□□□L□-□□□
Ⅰ﹒CONFIGURATION
& DIMENSIONS：
A : 8.0±0.3
B : 10.5±0.3
C : 3.7±0.3
D : 2.1±0.2
E :
2.0±0.2
F :
6.0±0.3
G : 5.7 ref.
H : 2.2 ref.
I :
2.4 ref.
m/m
m/m
m/m
m/m
m/m
m/m
m/m
m/m
m/m
101
Marking
Inductance code
B
C
D
F
D
H
E
A
I
G
I
( PCB Pattern )
Ⅱ﹒SCHEMATIC
DIAGRAM：
Ⅲ﹒MATERIALS：
a﹒Core：Ferrite DR core
b﹒Core：Ferrite RI core
c﹒Wire
：Enamelled
copper wire
（class
F）
d﹒Base：LCP E4008
e﹒Terminal： Cu/Ni/Sn
f﹒Adhesive：Epoxy resin
g﹒Remark：Products comply with RoHS'
requirements
f
Peak Temp：260℃ max.
Max time above 230℃
：50sec
max.
Max time above 200℃
：70sec
max.
Temperature
Rising Area
+4.0
℃
/ sec max.
Preheat Area
150 ~ 200
℃
/ 60 ~ 120sec
Reflow Area
+2.0 ~ 4.0
℃
/ sec max.
a
b
c
d
e
Forced Cooling Area
-(1.0 ~ 5.0)
℃
/ sec max.
P eak Temperature:
260
℃
Ⅳ﹒GENERAL
SPECIFICATION：
b﹒Rated current：Base on temp. rise
&
△
L / LOA=10% max.
c﹒Storage temp.：-40℃ ----+125℃
d﹒Operating temp.：-40℃----+105℃
e﹒Resistance to solderl heat：260℃.10 secs.
AE-001A
Temperature (
℃
)
250
50sec max.
a﹒Temp. rise
：40℃
max.
230
℃
200
150
70sec max.
100
50
0
50
100
150
Time ( seconds )
200
250
SPECIFICATION FOR APPROVAL
REF :
PROD.
NAME
PAGE: 2
SHIELDED SMD
POWER INDUCTOR
ABC'S DWG NO.
ABC'S ITEM NO.
SS0804□□□□L□-□□□
Ⅴ﹒ELECTRICAL
CHARACTERISTICS
：
DWG No.
SS08045R0ML□-□□□
SS08047R5ML□-□□□
SS0804100ML□-□□□
SS0804120ML□-□□□
SS0804150ML□-□□□
SS0804180YL□-□□□
SS0804220YL□-□□□
SS0804270YL□-□□□
SS0804330YL□-□□□
SS0804390YL□-□□□
SS0804470KL□-□□□
SS0804560KL□-□□□
SS0804680KL□-□□□
SS0804820KL□-□□□
SS0804101KL□-□□□
SS0804121KL□-□□□
SS0804151KL□-□□□
SS0804181KL□-□□□
SS0804221KL□-□□□
SS0804271KL□-□□□
SS0804331KL□-□□□
SS0804391KL□-□□□
SS0804471KL□-□□□
Inductance
( µH )
5.0±20%
7.5±20%
10.0±20%
12.0±20%
15.0±20%
18.0±15%
22.0±15%
27.0±15%
33.0±15%
39.0±15%
47.0±10%
56.0±10%
68.0±10%
82.0±10%
100.0±10%
120.0±10%
150.0±10%
180.0±10%
220.0±10%
270.0±10%
330.0±10%
390.0±10%
470.0±10%
Q
ref.
20
20
38
38
38
35
30
28
26
26
24
24
22
20
50
50
53
53
55
50
60
55
50
Test Freq. ( Hz )
Q
L
1K
1K
1K
1K
1K
1K
1K
1K
1K
1K
1K
1K
1K
1K
1K
1K
1K
1K
1K
1K
1K
1K
1K
7.960M
7.960M
2.520M
2.520M
2.520M
2.520M
2.520M
2.520M
2.520M
2.520M
2.520M
2.520M
2.520M
2.520M
796K
796K
796K
796K
796K
796K
796K
796K
796K
SRF
( MHz )
nom.
45.0
40.0
32.0
28.0
25.0
23.0
22.0
18.0
17.0
16.0
14.0
12.0
11.0
10.0
9.0
8.5
7.0
6.0
5.5
5.5
5.0
4.5
4.0
RDC
(
Ω
)
max.
0.080
0.100
0.120
0.150
0.170
0.190
0.250
0.270
0.300
0.380
0.460
0.600
0.700
0.800
0.950
1.000
1.300
1.450
1.900
2.150
2.800
3.300
3.600
IDC
(A)
max.
1.70
1.40
1.20
1.10
1.00
0.90
0.80
0.70
0.65
0.60
0.55
0.50
0.45
0.40
0.37
0.35
0.30
0.28
0.24
0.22
0.19
0.17
0.16
1).
□：Packaging
information… A：Bulk B：Taping Reel
2)."-
":Reference code
□□□
AE-001A
SPECIFICATION FOR APPROVAL
REF :
PROD.
NAME
PAGE: 3
SHIELDED SMD
POWER INDUCTOR
ABC'S DWG NO.
ABC'S ITEM NO.
SS0804□□□□L□-□□□
Ⅵ﹒INDUCTANCE
VS. DC CURRENT CURVE：
10 3
7
5
3
2
331
Inductance（uH）
10 2
7
5
3
2
10 1
7
5
3
2
10 0
10 1
101
330
100
5R0
2
3
5 7 10 2
2
3
5 7 10 3
2
3
5 7 10 4
DC Current (mA)
AE-001A
SPECIFICATION FOR APPROVAL
REF :
PROD.
NAME
PAGE: 4
SHIELDED SMD
POWER INDUCTOR
ABC'S DWG NO.
ABC'S ITEM NO.
SS0804□□□□L□-□□□
Ⅶ﹒PACKAGING
INFORMATION：
( 1 ) Configuration
T
Cover tape
2.0±0.5
A
∮
C
∮
C
N
B
G
D
Embossed carrier
※
Carrier tape width : D
P:12 m/m
End
4 m/m
Start
101
101
101
101
101
Leader
no component
200 m/m Min.
Components
User direction of feed
Trailer
no component
400 m/m Min.
( 2 ) Dimensions
Style
13 - 16
A
330
B
21±0.8
C
13
D
16
G
18
+0
N
50
-0
Unit:m/m
T
22.4
( 3 ) Q'TY & G.W. Per package
Inner : Reel
Series
SS0804
Q'TY (pcs)
G.W. (gw)
Style
Q'TY (pcs)
Outer : Carton
G.W. (Kg)
Size (cm)
1,000
1,100
13 - 16
6,000
7.5
40 x 40 x 24
AE-001A
SPECIFICATION FOR APPROVAL
REF :
PROD.
NAME
PAGE: 5
SHIELDED SMD
POWER INDUCTOR
ABC'S DWG NO.
ABC'S ITEM NO.
SS0804□□□□L□-□□□
Ⅷ﹒DWGING
NUMBER EXPRESSION：
S
S
0
8
0
4
Reference code
Appendix code 2 : Package
Appendix code 1 : Classification
Tolerance code
Electrical code
Dimension code
Type code
Appendix code 1：Product Classification
L：Lead Free Standard products comply with RoHS' requirements
1 ~ 9：Lead Free Special products comply with RoHS' requirements
Appendix code 2：Package Information
Code
A
B
Inner package
T.B.D.
T / R ( Reel package )
Inner package Q'TY
T.B.D.
1000
pcs
Remark
AE-001A
