SPECIFICATION FOR APPROVAL
REF :
PROD.
NAME
PAGE: 1
SHIELDED SMD
POWER INDUCTOR
ABC'S DWG NO.
ABC'S ITEM NO.
SS1206□□□□L□-□□□
Ⅰ﹒CONFIGURATION
& DIMENSIONS：
A
B
C
E
F
G
H
I
F
E
Marking
Inductance code
A
C
: 12.7±0.3
: 12.7±0.3
:
6.0±0.5
:
2.3±0.2
:
5.0±0.2
:
6.0 ref.
:
7.0 ref.
:
4.0 ref.
m/m
m/m
m/m
m/m
m/m
m/m
m/m
m/m
101
B
I
G
I
( PCB Pattern )
Ⅱ﹒SCHEMATIC
DIAGRAM：
Ⅲ﹒MATERIALS：
a﹒Core：Ferrite DR core
b﹒Core：Ferrite RI core
c﹒Wire
：Enamelled
copper wire
（class
F）
d﹒Base：LCP
e﹒Terminal：Cu/Ni/Sn
f﹒Adhesive：Epoxy resin
g﹒Remark：Products comply with RoHS'
requirements
Peak Temp：260℃ max.
Max time above 230℃
：50sec
max.
Max time above 200℃
：70sec
max.
Temperature
Rising Area
+4.0
℃
/ sec max.
Preheat Area
150 ~ 200
℃
/ 60 ~ 120sec
a
b
c
d
e
f
Reflow Area Forced Cooling Area
+2.0 ~ 4.0
℃
-(1.0 ~ 5.0)
℃
/ sec max.
/ sec max.
Peak Temperature:
260℃
50sec max.
230℃
Ⅳ﹒GENERAL
SPECIFICATION：
b﹒Rated current
：Base
on t emp. rise
&
△
L / LOA=10% max.
c﹒Storage temp.：-40℃ ----+125℃
d﹒Operating temp.：-40℃----+105℃
e﹒Resisance to solder heat：260℃ . 10 secs.
AE-001A
Temperature (
℃
)
250
200
150
7 0sec max.
a﹒Temp. rise
：40℃
max.
100
50
0
50
100
150
Time ( seconds )
H
200
250
SPECIFICATION FOR APPROVAL
REF :
PROD.
NAME
PAGE: 2
SHIELDED SMD
POWER INDUCTOR
ABC'S DWG NO.
ABC'S ITEM NO.
SS1206□□□□L□-□□□
Ⅴ﹒ELECTRICAL
CHARACTERISTICS
：
DWG No.
SS12062R5ML□-□□□
SS12065R0ML□-□□□
SS12067R5ML□-□□□
SS1206100ML□-□□□
SS1206120ML□-□□□
SS1206150ML□-□□□
SS1206180ML□-□□□
SS1206220ML□-□□□
SS1206270ML□-□□□
SS1206330YL□-□□□
SS1206390YL□-□□□
SS1206470YL□-□□□
SS1206560YL□-□□□
SS1206680YL□-□□□
SS1206820YL□-□□□
SS1206101YL□-□□□
SS1206121YL□-□□□
SS1206151KL□-□□□
SS1206181KL□-□□□
SS1206221KL□-□□□
SS1206271KL□-□□□
SS1206331KL□-□□□
SS1206391KL□-□□□
SS1206471KL□-□□□
SS1206561KL□-□□□
SS1206681KL□-□□□
SS1206821KL□-□□□
SS1206102KL□-□□□
SS1206122KL□-□□□
SS1206152KL□-□□□
Inductance
( µH )
2.5±20%
5.0±20%
7.5±20%
10.0±20%
12.0±20%
15.0±20%
18.0±20%
22.0±20%
27.0±20%
33.0±15%
39.0±15%
47.0±15%
56.0±15%
68.0±15%
82.0±15%
100.0±15%
120.0±15%
150.0±10%
180.0±10%
220.0±10%
270.0±10%
330.0±10%
390.0±10%
470.0±10%
560.0±10%
680.0±10%
820.0±10%
1000.0±10%
1200.0±10%
1500.0±10%
Test Freq.
( Hz )
1K
1K
1K
1K
1K
1K
1K
1K
1K
1K
1K
1K
1K
1K
1K
1K
1K
1K
1K
1K
1K
1K
1K
1K
1K
1K
1K
1K
1K
1K
B：Taping Reel
RDC
( mΩ )
max
16.0
22.0
25.0
35.0
38.0
42.0
50.0
62.0
68.0
90.0
100.0
130.0
155.0
170.0
185.0
220.0
260.0
320.0
380.0
460.0
520.0
660.0
870.0
970.0
1320.0
1500.0
1700.0
2300.0
2650.0
3500.0
IDC
(A)
max
6.20
4.70
3.80
3.30
3.00
2.80
2.50
2.30
2.00
1.90
1.75
1.60
1.45
1.30
1.20
1.10
1.00
0.90
0.80
0.70
0.65
0.60
0.55
0.50
0.45
0.40
0.35
0.30
0.25
0.20
1).
□：Packaging
information… A：Bulk
2)."-
":Reference code
□□□
AE-001A
SPECIFICATION FOR APPROVAL
REF :
PROD.
NAME
PAGE: 3
SHIELDED SMD
POWER INDUCTOR
ABC'S DWG NO.
ABC'S ITEM NO.
SS1206□□□□L□-□□□
Ⅵ﹒CURVE：
@ Inductance VS. DC Current Curve
102
331
10 3
7
5
3
2
Inductance（uH）
10 2
7
5
3
2
10 1
7
5
3
2
10
0
101
101
100
2R5
2 3
5 7 10 2 2 3
5 7 10 3 2 3
5 7 104
DC Current (mA)
@ DC Current VS. Temp. Rise Curve
10 3
7
5
3
2
10 2
7
5
3
2
10 1
7
5
3
2
10
0
10 1
102K
（℃）
331K
101Y
100M
2R5M
2 3
5 7 102 2 3
5 7 10 3 2 3
5 7 10 4
DC Current (mA)
AE-001A
SPECIFICATION FOR APPROVAL
REF :
PROD.
NAME
PAGE: 4
SHIELDED SMD
POWER INDUCTOR
( 1 ) Configuration
T
ABC'S DWG NO.
ABC'S ITEM NO.
SS1206□□□□L□-□□□
Ⅶ﹒PACKAGING
INFORMATION：
Cover tape
2.0±0.5
A
B
∮
C
∮
C
N
G
D
Embossed carrier
※
Carrier tape width : D
P:16 m/m
4 m/m
End
Start
101
Leader
no component
200 m/m Min.
101
101
101
101
Trailer
no compoment
400 m/m Min.
Components
User direction of feed
( 2 ) Dimensions
Style
13 - 24
A
330
B
21±0.8
C
13
D
24
G
26
+0
N
50
-0
Unit:m/m
T
30.4
( 3 ) Q'TY & G.W. Per package
Inner : Reel
Series
SS1206
AE-001A
Q'TY (pcs)
G.W. (gw)
Style
Q'TY (pcs)
Outer : Carton
G.W. (Kg)
Size (cm)
600
2,200
13 - 24
2,400
11.0
40 x 40 x 24
SPECIFICATION FOR APPROVAL
REF :
PROD.
NAME
PAGE: 5
SHIELDED SMD
POWER INDUCTOR
ABC'S DWG NO.
ABC'S ITEM NO.
SS1206□□□□L□-□□□
Ⅷ﹒DWGING
NUMBER EXPRESSION：
S
S
1
2
0
6
Reference code
Appendix code 2 : Package
Appendix code 1 : Classification
Tolerance code
Electrical code
Dimension code
Type code
Appendix code 1：Product Classification
L：Lead Free Standard products comply with RoHS' requirements
1 ~ 9：Lead Free Special products comply with RoHS' requirements
Appendix code 2：Package Information
Code
A
B
T.B.D.
T /R (Reel package)
Inner package
Inner package Q'TY
T.B.D.
600 pcs
Remark
AE-001A
