SS32C THRU SS310C
SURFACE MOUNT SCHOTTKY BARRIER RECTIFIER
Reverse Voltage - 20 to 100 V
Forward Current - 3 A
Features
• Guard ring protection
• Low forward voltage
• High current capability
Mechanical Data
• Case: SMC (DO-214AB) molded plastic body
• Polarity: color band denotes cathode end
• Mounting Position: Any
Maximum Ratings and Electrical Characteristics
Ratings at 25
O
C ambient temperature unless otherwise specified.
Parameter
Maximum Repetitive Peak Reverse Voltage
Maximum RMS Voltage
Maximum DC Blocking Voltage
Maximum Average Forward Rectified Current
at T
L
= 90
O
C
Peak Forward Surge Current, 8.3 ms Single Half
Sine Wave Superimposed on Rated Load (JEDEC
method)
Maximum Forward Voltage at 3 A
Maximum DC Reverse Current
at Rated DC Blocking Voltage
Typical Thermal Resistance
Operating Junction Temperature Range
Storage Temperature Range
1)
1)
Symbols
SS32C SS33C SS34C SS35C SS36C SS38C SS39C SS310C
Units
V
RRM
V
RMS
V
DC
I
F(AV)
20
14
20
30
21
30
40
28
40
50
35
50
3
60
42
60
80
56
80
90
63
90
100
70
100
V
V
V
A
I
FSM
V
F
0.5
100
0.75
0.5
20
17
- 55 to + 125
- 55 to + 150
10
O
A
0.85
V
mA
C/W
O
T
J
= 25
O
C
T
J
= 125
O
C
I
R
R
θJL
T
j
T
stg
C
C
O
Pulse test: 300 µs pulse width, 1% duty cycle
