MX29LV800CBGBI-70G datasheet, PDF

Datasheet> All Categories > storage> storage> MX29LV800CBGBI-70G

MX29LV800CBGBI-70G: DescriptionFlash, 8MX16, 70ns, PBGA48, 6 X 4 MM, 0.50 MM HEIGHT, ROHS COMPLIANT, MO-222, XFLGA-48; Categorystorage storage; File Size3MB，76 Pages; ManufacturerMacronix; Websitehttp://www.macronix.com/en-us/Pages/default.aspx; Environmental Compliance

Download Datasheet Parametric Compare View All

MX29LV800CBGBI-70G Overview

Flash, 8MX16, 70ns, PBGA48, 6 X 4 MM, 0.50 MM HEIGHT, ROHS COMPLIANT, MO-222, XFLGA-48

MX29LV800CBGBI-70G Parametric

Parameter Name	Attribute value
Is it Rohs certified?	conform to
Maker	Macronix
Parts packaging code	BGA
package instruction	VFLGA, BGA48,6X11,20
Contacts	48
Reach Compliance Code	unknow
ECCN code	3A991.B.1.A
Maximum access time	70 ns
Spare memory width	8
startup block	BOTTOM
command user interface	YES
Universal Flash Interface	YES
Data polling	YES
JESD-30 code	R-PBGA-B48
length	6 mm
memory density	134217728 bi
Memory IC Type	FLASH
memory width	16
Number of functions	1
Number of departments/size	1,2,1,15
Number of terminals	48
word count	8388608 words
character code	8000000
Operating mode	ASYNCHRONOUS
Maximum operating temperature	85 °C
Minimum operating temperature	-40 °C
organize	8MX16
Package body material	PLASTIC/EPOXY
encapsulated code	VFLGA
Encapsulate equivalent code	BGA48,6X11,20
Package shape	RECTANGULAR
Package form	GRID ARRAY, VERY THIN PROFILE, FINE PITCH
Parallel/Serial	PARALLEL
Peak Reflow Temperature (Celsius)	NOT SPECIFIED
power supply	3/3.3 V
Programming voltage	3 V
Certification status	Not Qualified
ready/busy	YES
Maximum seat height	0.5 mm
Department size	16K,8K,32K,64K
Maximum standby current	0.000005 A
Maximum slew rate	0.03 mA
Maximum supply voltage (Vsup)	3.6 V
Minimum supply voltage (Vsup)	2.7 V
Nominal supply voltage (Vsup)	3 V
surface mount	YES
technology	CMOS
Temperature level	INDUSTRIAL
Terminal form	BUTT
Terminal pitch	0.5 mm
Terminal location	BOTTOM
Maximum time at peak reflow temperature	NOT SPECIFIED
switch bit	YES
type	NOR TYPE
width	4 mm

Preview

Download Datasheet

View All

MX29LV400C T/B

MX29LV800C T/B

MX29LV160C T/B

MX29LV400C T/B, MX29LV800C T/B,

MX29LV160C T/B

DATASHEET

The MX29LV160C T/B product family has been discontinued. The MX29LV160C T/B

product family is not recommended for new designs. The MX29LV160D T/B family is the

recommended replacement. Please refer to MX29LV160D T/B datasheet for full specifications

and ordering information, or contact your local sales representative for additional support.

P/N:PM1300

REV. 2.6, DEC. 22, 2011

MX29LV800CBGBI-70G Related Products

	MX29LV800CBGBI-70G	MX29LV400CTXHI-70G	MX29LV800CBXGI-70G	MX29LV800CTXGI-70G	MX29LV400CTGBI-70G	MX29LV400CBGBI-70G	MX29LV400CBXHI-70G	MX29LV800CTGBI-70G
Description	Flash, 8MX16, 70ns, PBGA48, 6 X 4 MM, 0.50 MM HEIGHT, ROHS COMPLIANT, MO-222, XFLGA-48	Flash, 4MX16, 70ns, PBGA48, 6 X 4 MM, 0.75 MM HEIGHT, ROHS COMPLIANT, WFBGA-48	IC FLASH 8M PARALLEL 48TFBGA	IC FLASH 8M PARALLEL 48TFBGA	Flash, 4MX16, 70ns, PBGA48, 6 X 4 MM, 0.50 MM HEIGHT, ROHS COMPLIANT, MO-222, XFLGA-48	Flash, 4MX16, 70ns, PBGA48, 6 X 4 MM, 0.50 MM HEIGHT, ROHS COMPLIANT, MO-222, XFLGA-48	Flash, 4MX16, 70ns, PBGA48, 6 X 4 MM, 0.75 MM HEIGHT, ROHS COMPLIANT, WFBGA-48	Flash, 8MX16, 70ns, PBGA48, 6 X 4 MM, 0.50 MM HEIGHT, ROHS COMPLIANT, MO-222, XFLGA-48
Is it Rohs certified?	conform to	conform to	conform to	conform to	conform to	conform to	conform to	conform to
Parts packaging code	BGA	BGA	BGA	BGA	BGA	BGA	BGA	BGA
package instruction	VFLGA, BGA48,6X11,20	VFBGA, BGA48,6X11,20	TFBGA, BGA48,6X8,32	TFBGA, BGA48,6X8,32	VFLGA, BGA48,6X11,20	VFLGA, BGA48,6X11,20	VFBGA, BGA48,6X11,20	VFLGA, BGA48,6X11,20
Contacts	48	48	48	48	48	48	48	48
Reach Compliance Code	unknow	unknow	unknown	unknown	unknown	unknown	unknown	unknown
ECCN code	3A991.B.1.A	EAR99	3A991.B.1.A	3A991.B.1.A	3A991.B.1.A	3A991.B.1.A	3A991.B.1.A	3A991.B.1.A
Maximum access time	70 ns	70 ns	70 ns	70 ns	70 ns	70 ns	70 ns	70 ns
Spare memory width	8	8	8	8	8	8	8	8
startup block	BOTTOM	TOP	BOTTOM	TOP	TOP	BOTTOM	BOTTOM	TOP
command user interface	YES	YES	YES	YES	YES	YES	YES	YES
Universal Flash Interface	YES	YES	YES	YES	YES	YES	YES	YES
Data polling	YES	YES	YES	YES	YES	YES	YES	YES
JESD-30 code	R-PBGA-B48	R-PBGA-B48	R-PBGA-B48	R-PBGA-B48	R-PBGA-B48	R-PBGA-B48	R-PBGA-B48	R-PBGA-B48
length	6 mm	6 mm	8 mm	8 mm	6 mm	6 mm	6 mm	6 mm
memory density	134217728 bi	67108864 bi	134217728 bit	134217728 bit	67108864 bit	67108864 bit	67108864 bit	134217728 bit
Memory IC Type	FLASH	FLASH	FLASH	FLASH	FLASH	FLASH	FLASH	FLASH
memory width	16	16	16	16	16	16	16	16
Number of functions	1	1	1	1	1	1	1	1
Number of departments/size	1,2,1,15	1,2,1,7	1,2,1,15	1,2,1,15	1,2,1,7	1,2,1,7	1,2,1,7	1,2,1,15
Number of terminals	48	48	48	48	48	48	48	48
word count	8388608 words	4194304 words	8388608 words	8388608 words	4194304 words	4194304 words	4194304 words	8388608 words
character code	8000000	4000000	8000000	8000000	4000000	4000000	4000000	8000000
Operating mode	ASYNCHRONOUS	ASYNCHRONOUS	ASYNCHRONOUS	ASYNCHRONOUS	ASYNCHRONOUS	ASYNCHRONOUS	ASYNCHRONOUS	ASYNCHRONOUS
Maximum operating temperature	85 °C	85 °C	85 °C	85 °C	85 °C	85 °C	85 °C	85 °C
Minimum operating temperature	-40 °C	-40 °C	-40 °C	-40 °C	-40 °C	-40 °C	-40 °C	-40 °C
organize	8MX16	4MX16	8MX16	8MX16	4MX16	4MX16	4MX16	8MX16
Package body material	PLASTIC/EPOXY	PLASTIC/EPOXY	PLASTIC/EPOXY	PLASTIC/EPOXY	PLASTIC/EPOXY	PLASTIC/EPOXY	PLASTIC/EPOXY	PLASTIC/EPOXY
encapsulated code	VFLGA	VFBGA	TFBGA	TFBGA	VFLGA	VFLGA	VFBGA	VFLGA
Encapsulate equivalent code	BGA48,6X11,20	BGA48,6X11,20	BGA48,6X8,32	BGA48,6X8,32	BGA48,6X11,20	BGA48,6X11,20	BGA48,6X11,20	BGA48,6X11,20
Package shape	RECTANGULAR	RECTANGULAR	RECTANGULAR	RECTANGULAR	RECTANGULAR	RECTANGULAR	RECTANGULAR	RECTANGULAR
Package form	GRID ARRAY, VERY THIN PROFILE, FINE PITCH	GRID ARRAY, VERY THIN PROFILE, FINE PITCH	GRID ARRAY, THIN PROFILE, FINE PITCH	GRID ARRAY, THIN PROFILE, FINE PITCH	GRID ARRAY, VERY THIN PROFILE, FINE PITCH	GRID ARRAY, VERY THIN PROFILE, FINE PITCH	GRID ARRAY, VERY THIN PROFILE, FINE PITCH	GRID ARRAY, VERY THIN PROFILE, FINE PITCH
Parallel/Serial	PARALLEL	PARALLEL	PARALLEL	PARALLEL	PARALLEL	PARALLEL	PARALLEL	PARALLEL
Peak Reflow Temperature (Celsius)	NOT SPECIFIED	NOT SPECIFIED	NOT SPECIFIED	NOT SPECIFIED	NOT SPECIFIED	NOT SPECIFIED	NOT SPECIFIED	NOT SPECIFIED
power supply	3/3.3 V	3/3.3 V	3/3.3 V	3/3.3 V	3/3.3 V	3/3.3 V	3/3.3 V	3/3.3 V
Programming voltage	3 V	3 V	3 V	3 V	3 V	3 V	3 V	3 V
Certification status	Not Qualified	Not Qualified	Not Qualified	Not Qualified	Not Qualified	Not Qualified	Not Qualified	Not Qualified
Maximum seat height	0.5 mm	0.75 mm	1.2 mm	1.2 mm	0.5 mm	0.5 mm	0.75 mm	0.5 mm
Department size	16K,8K,32K,64K	16K,8K,32K,64K	16K,8K,32K,64K	16K,8K,32K,64K	16K,8K,32K,64K	16K,8K,32K,64K	16K,8K,32K,64K	16K,8K,32K,64K
Maximum standby current	0.000005 A	0.000005 A	0.000005 A	0.000005 A	0.000005 A	0.000005 A	0.000005 A	0.000005 A
Maximum slew rate	0.03 mA	0.03 mA	0.03 mA	0.03 mA	0.03 mA	0.03 mA	0.03 mA	0.03 mA
Maximum supply voltage (Vsup)	3.6 V	3.6 V	3.6 V	3.6 V	3.6 V	3.6 V	3.6 V	3.6 V
Minimum supply voltage (Vsup)	2.7 V	2.7 V	2.7 V	2.7 V	2.7 V	2.7 V	2.7 V	2.7 V
Nominal supply voltage (Vsup)	3 V	3 V	3 V	3 V	3 V	3 V	3 V	3 V
surface mount	YES	YES	YES	YES	YES	YES	YES	YES
technology	CMOS	CMOS	CMOS	CMOS	CMOS	CMOS	CMOS	CMOS
Temperature level	INDUSTRIAL	INDUSTRIAL	INDUSTRIAL	INDUSTRIAL	INDUSTRIAL	INDUSTRIAL	INDUSTRIAL	INDUSTRIAL
Terminal form	BUTT	BALL	BALL	BALL	BUTT	BUTT	BALL	BUTT
Terminal pitch	0.5 mm	0.5 mm	0.8 mm	0.8 mm	0.5 mm	0.5 mm	0.5 mm	0.5 mm
Terminal location	BOTTOM	BOTTOM	BOTTOM	BOTTOM	BOTTOM	BOTTOM	BOTTOM	BOTTOM
Maximum time at peak reflow temperature	NOT SPECIFIED	NOT SPECIFIED	NOT SPECIFIED	NOT SPECIFIED	NOT SPECIFIED	NOT SPECIFIED	NOT SPECIFIED	NOT SPECIFIED
switch bit	YES	YES	YES	YES	YES	YES	YES	YES
type	NOR TYPE	NOR TYPE	NOR TYPE	NOR TYPE	NOR TYPE	NOR TYPE	NOR TYPE	NOR TYPE
width	4 mm	4 mm	6 mm	6 mm	4 mm	4 mm	4 mm	4 mm
Maker	Macronix	Macronix	Macronix	Macronix	Macronix	-	Macronix	Macronix
ready/busy	YES	YES	YES	YES	YES	YES	-	YES
