TAW Series
Tantalum Solid Electrolytic Fused Capacitors
TAW Fused Tantalum Capacitors offer protection from pos-
sible damaging short circuit failure modes. This is accom-
plished with an internal fuse using thin film technology that
is in series with the capacitor. The AVX fused tantalum
offers lower ESR limits than competitive fused tantalum
capacitors.
CASE DIMENSIONS:
millimeters (inches)
Code
B
C
D
For part marking see page 175
EIA
Code
3528-21
6032-28
7343-31
L±0.20 (0.008)
3.50 (0.138)
6.00 (0.236)
7.30 (0.287)
A+0.30 (0.012)
W+0.20 (0.008) H±0.20 (0.008)
W
1
-0.10 (0.004)
-0.10 (0.004) ±0.20 (0.008)
-0.20 (0.008)
2.80 (0.110)
3.20 (0.126)
4.30 (0.169)
1.90 (0.075)
2.60 (0.102)
2.90 (0.114)
2.20 (0.087)
2.20 (0.087)
2.40 (0.094)
0.80 (0.031)
1.30 (0.051)
1.30 (0.051)
S Min.
1.40 (0.055)
2.90 (0.114)
4.40 (0.173)
W
1
dimension applies to the termination width for A dimensional area only.
Under development
HOW TO ORDER
TAW
D
476
*
Tolerance
K=±10%
M=±20%
010
R
0500
Type
Case Code
See table
above
Capacitance
pF code: 1st two
digits represent
significant figures
3rd digit represents
multiplier (number of
zeros to follow)
Rated DC Voltage
010=10Vdc
016=16Vdc
020=20Vdc
050=50Vdc
Packaging
R = 7" T/R
S = 13" T/R
ESR in mΩ
TECHNICAL SPECIFICATIONS
Technical Data:
Capacitance Range:
Capacitance Tolerance:
Rated Voltage (V
R
)
Category Voltage (V
C
)
Surge Voltage (V
s
)
Fuse Off
Fuse Continuous Current Capability
Temperature Range:
Reliability:
All technical data relate to an ambient temperature of +25°C
10 μF to 100 μF
±10%; ±20%
6.3
10
16
20
25
35
4
7
10
13
17
23
8
13
20
26
32
46
5
8
13
16
20
28
I > 4A in 1s, insulating resistance > 10MΩ
0.75A
-55°C to +125°C
1% per 1000 hours at 85°C, Vr with 0.1Ω/V series impedance,
60% confidence level
+85°C:
+125°C
+85°C
+125°C
50
33
65
40
53
TAW Series
Tantalum Solid Electrolytic Fused Capacitors
CAPACITANCE AND VOLTAGE RANGE (LETTER DENOTES CASE SIZE)
Capacitance
μF
Code
1.0
105
2.2
225
4.7
475
6.8
685
10
106
22
226
33
336
47
476
100
107
6.3V (J)
10V (A)
Rated Voltage DC (V
R
) to 85°C
16V (C)
20V (D)
25V (E)
B
B
B
B
C
C
C
D(600)
D
D
D
D(600)
D
D
35V (V)
B
D
D(700)
50V (T)
C
B
B
B
C
C
C
D(500)
D(500)
Available Ratings, (ESR ratings in mOhms in brackets)
Developmental Ratings - subject to change.
RATINGS & PART NUMBER REFERENCE
AVX
Part No.
Rated
Case Capacitance Voltage
Size
(μF)
(V)
DCL
DF
ESR
(μA)
% Max. (mΩ)
Max. Max. @100kHz
100kHz RMS Current (mA)
25ºC
85ºC
125ºC
100kHz RMS Voltage (mV)
25ºC
85ºC
125ºC
10 Volt @ 85ºC (6.6 Volt @ 125ºC)
TAWD476*010R0500
TAWD107*010R0500
TAWD336*016R0600
TAWD106*025R0600
TAWD685*050R0700
D
D
D
D
D
47
100
33
10
6.8
10
10
16
25
50
4.7
10
5.3
2.5
3.4
6
8
6
6
6
500
500
600
600
700
548
548
500
500
463
493
493
450
450
417
219
219
200
200
185
274
274
300
300
324
246
246
270
270
292
110
110
120
120
130
16 Volt @ 85°C (10 Volt @ 125°C)
25 Volt @ 85°C (17 Volt @ 125°C)
50 Volt @ 85°C (33 Volt @ 125°C)
All technical data relates to an ambient temperature of +25°C. Capacitance and DF are measured
at 120Hz, 0.5 RMS with DC bias of 2.2 volts. DCL is measured at rated voltage after 5 minutes.
NOTE: AVX reserves the right to supply a higher voltage rating
in the same case size, to the same reliability standards.
TYPICAL FUSE ACTUATION
Typical Actuation Time vs Load Current
100.000
10.000
1.000
0.100
0.010
0.001
1
10
Actuation Time [ms]
Note: for a different fuse characteristic
requirements please contact manufacturer
Current [A]
100
