UNISONIC TECHNOLOGIES CO., LTD
2SA1300
PNP EPITAXIAL SILICON TRANSISTOR
SILICON PNP EPITAXAL TYPE
DESCRIPTION
* Strobo Flash Applications.
* Medium Power Amplifier Applications.
FEATURES
* High DC Current Gain and Excellent h
FE
Linearity.
* h
FE(1)
=140-600, (V
CE
= -1V,I
C
= -0.5A)
* h
FE(2)
=60(Min.),120(Typ.),(V
CE
= -1V,I
C
= -4A)
* Low Saturation Voltage
* V
CE (SAT)
= -0.5V(Max.), (I
C
= -2A,I
E
= -50mA)
ORDERING INFORMATION
Ordering Number
Lead Free
Halogen Free
2SA1300L-xx-AB3-R
2SA1300G-xx-AB3-R
2SA1300L-xx-T92-B
2SA1300G-xx-T92-B
2SA1300L-xx-T92-K
2SA1300G-xx-T92-K
2SA1300L-xx-T92-R
2SA1300G-xx-T92-R
Note: Pin Assignment: E: Emitter C: Collector B: Base
Package
SOT-89
TO-92
TO-92
TO-92
Pin Assignment
1
2
3
B
C
E
E
C
B
E
C
B
E
C
B
Packing
Tape Reel
Tape Box
Bulk
Tape Reel
www.unisonic.com.tw
Copyright © 2011 Unisonic Technologies Co., LTD
1 of 2
QW-R208-012.Ba
2SA1300
ABSOLUTE MAXIMUM RATING
(T
A
=25℃)
PARAMETER
Collector-Base Voltage
Collector-Emitter Voltage
Emitter-Base Voltage
DC
Collector Current
Pulsed (Note 1)
Base Current
Collector Power Dissipation
SYMBOL
V
CBO
V
CES
V
CEO
V
EBO
I
C
I
CP
I
B
P
C
PNP EPITAXIAL SILICON TRANSISTOR
RATINGS
-20
-20
-10
-6
-2
-5
-2
750
UNIT
V
V
V
A
A
mW
℃
℃
Junction Temperature
T
J
150
Storage Temperature
T
STG
-40 ~ +150
Note 1. Pulse Width= 10ms(Max.), Duty Cycle=30%(Max.)
2. Absolute maximum ratings are those values beyond which the device could be permanently damaged.
Absolute maximum ratings are stress ratings only and functional device operation is not implied.
3. The device is guaranteed to meet performance specification within 0℃~70
℃
operating temperature range
and assured by design from –20℃~85℃.
ELECTRICAL CHARACTERISTICS
(T
A
=25℃)
PARAMETER
Collector-emitter breakdown voltage
Emitter-collector breakdown voltage
Collector cut-off current
Emitter cut-off current
DC current Gain
Collector-emitter saturation voltage
Base-emitter voltage
Current gain bandwidth product
Output capacitance
SYMBOL
V
(BR)CEO
V
(BR)EBO
I
CBO
I
EBO
h
FE1
h
FE2
V
CE(SAT)
V
BE
f
T
C
OB
TEST CONDITIONS
I
C
=10mA, I
B
=0
I
E
= -1mA, I
C
=0
V
CE
= -20V, I
E
=0
V
BE
= -6V, I
C
=0
V
CE
= -1V, I
C
=0.5A
V
CE
= -1V, I
C
= -4A
I
C
= -2A, I
B
= -50mA
V
CE
= -1V, I
C
= -2A
V
CE
= -1V,I
C
= -0.5A
V
CE
= -10V, I
E
=0, f=1MHz
MIN
-10
-6
TYP
MAX
UNIT
V
V
nA
nA
140
60
-100
-100
600
120
-0.2
-0.83
140
50
-0.5
-1.5
V
V
MHz
pF
CLASSIFICATIONS OF h
FE1
RANK
RANGE
Y
140-280
GR
200-400
BL
300-600
UTC assumes no responsibility for equipment failures that result from using products at values that
exceed, even momentarily, rated values (such as maximum ratings, operating condition ranges, or
other parameters) listed in products specifications of any and all UTC products described or contained
herein. UTC products are not designed for use in life support appliances, devices or systems where
malfunction of these products can be reasonably expected to result in personal injury. Reproduction in
whole or in part is prohibited without the prior written consent of the copyright owner. The information
presented in this document does not form part of any quotation or contract, is believed to be accurate
and reliable and may be changed without notice.
UNISONIC TECHNOLOGIES CO., LTD
www.unisonic.com.tw
2 of 2
QW-R208-012.Ba
