General Purpose Transistor
Comchip
SMD Diode Specialist
2SC5658-HF
(NPN)
RoHS Device
Halogen Free
Features
-Low Cob.
SOT-723
0.011(0.270)
0.007(0.170)
1
0.049(1.25) 0.031(0.800)
0.045(1.15)
Typ.
2
0.033(0.850)
0.030(0.750)
0.049(1.250)
0.045(1.150)
0.015(0.370)
0.011(0.270)
Mechanical data
-Case: SOT-723, molded plastic.
-Terminals: solderable per MIL-STD-750,
method 2026.
3
Circuit diagram
-1.BASE
-2.EMITTER
-3.COLLECTOR
1
3
0.002(0.050)
Max.
0.006(0.15)
Max.
0.020(0.50)
Max.
2
Absolute Maximum Ratings (at T
A
=25°C )
Parameter
Collector-Base voltage
Collector-Emitter voltage
Emitter-Base voltage
Collector current- continuous
Collector dissipation
Junction temperature
Storage temperature
Symbol
V
CBO
V
CEO
V
EBO
I
C
P
C
T
J
T
STG
Value
60
50
7
150
100
150
-55 ~ +150
Unit
V
V
V
mA
µA
µA
µA
Dimensions in inches and (millimeter)
Electrical Characteristics (at TA=25°C unless otherwise noted)
Parameter
Collector-Base breakdown voltage
Collector-Emitter breakdown voltage
Emitter-Base breakdown voltage
Collector cut-off current
Emitter cut-off current
DC current gain
Collector-Emitter saturation voltage
Transition frequency
Output capacitance
Conditions
I
C
=50μA , I
E
=0
I
C
=1mA , I
B
=0
I
E
=50μA , I
C
=0
V
CB
=60V , I
E
=0
V
EB
=7V , I
C
=0
V
CE
=6V , I
C
=1mA
I
C
=50mA , I
B
=5mA
V
CE
=12V , I
C
=2mA
f=100MH
Z
V
CB
=12V , I
E
=0
f=1MH
Z
Symbol
V
(BR)CBO
V
(BR)CEO
V
(BR)EBO
I
CBO
I
EBO
h
FE
V
CE
(sat)
f
T
C
ob
Min
60
50
7
Typ
Max
Unit
V
V
V
0.1
0.1
120
560
0.4
180
3.5
µA
µA
V
MH
Z
pF
Rank
Range
Q
120~270
R
180~390
S
270~560
Company reserves the right to improve product design , functions and reliability without notice.
QW-JTR07
REV: A
Page 1
Comchip Technology CO., LTD.
General Purpose Transistor
RATING AND CHARACTERISTIC CURVES (2SC5658-HF)
Fig.1- Static Characteristic
1000
6
20uA
18uA
Comchip
SMD Diode Specialist
Fig.2- H
FE
— I
C
COMMON
EMITTER
Ta=25°C
Collector Current, Ic (mA)
14uA
4
3
2
1
12uA
10uA
8uA
Dc Current Gain, (h
FE
)
5
16uA
100
6uA
4uA
I
B
=2uA
COMMON EMITTER
V
CE
=6V
0
-0
1
2
3
4
5
6
7
8
10
0.1
1
10
100
150
Collector Emitter Voltage V
CE
, (V)
Collecor Current, Ic (mA)
Fig.3- V
BEsat
— I
C
Base-Emitter Saturation Voltage,
V
BEsat
( mV )
Base-Emitter Saturation Voltage,
V
BEsat
( mV )
2000
300
Fig.4 - V
CEsat
— I
C
1000
Ta=25°C
100
Ta=100°C
Ta=100°C
Ta=25°C
ß=10
ß=10
100
0.1
1
10
100 150
10
0.1
1
10
100 150
Collector Current, I
C
(mA)
Collector Current, I
C
(mA)
Fig.5 - I
C
— V
BE
150
1000
Fig.5 - f
T
— I
C
Transition Frequency,F
T
(MH
Z
)
100
Collector Current, I
c
(mA)
Ta=1
0
0°C
Ta=2
5
°C
100
10
COMMON EMITTER
V
CE
=6V
COMMON EMITTER
V
CE
=6V
Ta=25°C
1
0.0
0.3
0.6
0.9
10
1.2
1
10
100
Base-Emmiter Voltage, V
BE
(V)
Collector Current, I
C
(mA)
REV: A
QW-JTR07
Page 2
Comchip Technology CO., LTD.
General Purpose Transistor
RATING AND CHARACTERISTIC CURVES (2S5658-HF)
Fig.7- C
ob
/C
ib
— V
CE
/V
EB
50
10
Comchip
SMD Diode Specialist
Fig.8 - P
C
— T
a
Collector Power Dissipation, P
C
(mW)
f=1MH
Z
I
E
=0/I
C
=0
Ta=25°C
125
100
Capacitance, C (pF)
C
ib
75
C
ob
1
50
25
0.1
0.1
1
10
20
0
0
25
50
75
100
125
150
Reverse Voltage,V (V)
Ambient Temperature,Ta (°C)
REV: A
QW-JTR07
Page 3
Comchip Technology CO., LTD.
General Purpose Transistor
Reel Taping Specification
d
P0
P1
Comchip
SMD Diode Specialist
T
E
F
B
W
C
12
0
o
D
2
D
1
D
W
1
Trailer Tape
100±4 Empty Pockets
End
Components
Leader Tape
200±4 Empty Pockets
Start
SYMBOL
A
1.33
±
0.05
0.052
±
0.002
B
1.45
±
0.05
0.057
±
0.002
C
0.61
±
0.05
0.024
±
0.002
d
1.50
±
0.10
0.059
+
0.004
D
178
±
2.00
7.008
±
0.078
D
1
54.40
±
1.00
2.142
±
0.039
D
2
13.00
±
1.00
0.512
±
0.039
SOT-723
(mm)
(inch)
SYMBOL
E
1.75
±
0.10
0.069
±
0.004
F
3.50
±
0.05
0.138
±
0.002
P
2.00
±
0.10
0.079
±
0.004
P
0
4.00
±
0.10
0.158
±
0.004
P
1
2.00
±
0.10
W
8.00
+
0.30 /
–0.10
W
1
12.30
±
1.00
SOT-723
(mm)
(inch)
0.079
±
0.004
0.315
+
0.012 /
–0.004
0.484
±
0.039
REV: A
QW-JTR07
Page 4
Comchip Technology CO., LTD.
General Purpose Transistor
Marking Code
Part Number
Rank
Marking Code
Comchip
SMD Diode Specialist
3
Q
2SC5658-HF
R
S
BQ
BR
XX
1
2
BS
xx = Product type marking code
Suggested PAD Layout
A
SOT-723
SIZE
(mm)
A
B
C
D
E
F
G
H
I
0.70
0.65
0.65
0.55
0.30
0.80
0.35
0.90
0.35
(inch)
0.003
H
0.026
0.026
0.022
D
0.012
0.031
0.014
0.035
0.014
E
C
I
G
B
Standard Packaging
Case Type
SOT-723
Qty Per Reel
(Pcs)
8,000
Reel Size
(inch)
7
REV: A
QW-JTR07
Page 5
Comchip Technology CO., LTD.
