Series AM2D-Z
2 Watt | DC-DC Converte
r
FEATURES:
RoHS Compliant
Low ripple and noise
High efficiency up to 82%
7 pin SIP package
Operating temperature -40
o
C to +85
o
C
With derating above +75C (see chart)
Pin compatible with multiple manufacturers
Input / Output Isolation 1000, 3000, 4000 and 5200VDC
Models
Single output
Model
AM2D-0503SZ
AM2D-0505SZ
AM2D-0507SZ
AM2D-0509SZ
AM2D-0512SZ
AM2D-0515SZ
AM2D-0518SZ
AM2D-0524SZ
AM2D-1203SZ
AM2D-1205SZ
AM2D-1207SZ
AM2D-1209SZ
AM2D-1212SZ
AM2D-1215SZ
AM2D-1218SZ
AM2D-1224SZ
AM2D-2403SZ
AM2D-2405SZ
AM2D-2407SZ
AM2D-2409SZ
AM2D-2412SZ
AM2D-2415SZ
AM2D-2418SZ
AM2D-2424SZ
AM2D-0503SH30Z
AM2D-0505SH30Z
AM2D-0507SH30Z
AM2D-0509SH30Z
AM2D-0512SH30Z
AM2D-0515SH30Z
AM2D-0518SH30Z
AM2D-0524SH30Z
AM2D-1203SH30Z
AM2D-1205SH30Z
AM2D-1207SH30Z
AM2D-1209SH30Z
AM2D-1212SH30Z
AM2D-1215SH30Z
AM2D-1218SH30Z
AM2D-1224SH30Z
AM2D-2403SH30Z
AM2D-2405SH30Z
AM2D-2407SH30Z
AM2D-2409SH30Z
AM2D-2412SH30Z
Input Voltage
(V)
4.5-5.5
4.5-5.5
4.5-5.5
4.5-5.5
4.5-5.5
4.5-5.5
4.5-5.5
4.5-5.5
10.8-13.2
10.8-13.2
10.8-13.2
10.8-13.2
10.8-13.2
10.8-13.2
10.8-13.2
10.8-13.2
21.6-26.4
21.6-26.4
21.6-26.4
21.6-26.4
21.6-26.4
21.6-26.4
21.6-26.4
21.6-26.4
4.5-5.5
4.5-5.5
4.5-5.5
4.5-5.5
4.5-5.5
4.5-5.5
4.5-5.5
4.5-5.5
10.8-13.2
10.8-13.2
10.8-13.2
10.8-13.2
10.8-13.2
10.8-13.2
10.8-13.2
10.8-13.2
21.6-26.4
21.6-26.4
21.6-26.4
21.6-26.4
21.6-26.4
Output Voltage
(V)
3.3
5
7.2
9
12
15
18
24
3.3
5
7.2
9
12
15
18
24
3.3
5
7.2
9
12
15
18
24
3.3
5
7.2
9
12
15
18
24
3.3
5
7.2
9
12
15
18
24
3.3
5
7.2
9
12
Output Current
max (mA)
400
400
278
222
167
134
111
83
400
400
278
222
167
134
111
83
400
400
278
222
167
134
111
83
400
400
278
222
167
134
111
83
400
400
278
222
167
134
111
83
400
400
278
222
167
Isolation
(VDC)
1000
1000
1000
1000
1000
1000
1000
1000
1000
1000
1000
1000
1000
1000
1000
1000
1000
1000
1000
1000
1000
1000
1000
1000
3000
3000
3000
3000
3000
3000
3000
3000
3000
3000
3000
3000
3000
3000
3000
3000
3000
3000
3000
3000
3000
Efficiency
(%)
72
78
80
80
82
82
82
82
65
77
80
80
82
82
80
80
72
79
80
80
80
82
82
82
72
78
80
80
82
82
82
82
65
77
80
80
82
82
80
80
72
79
80
80
80
