NOTE: All specifications noted in this datasheet are measured at an ambient temperature of 25°C, humidity<75%, nominal input voltage and
at rated output load unless otherwise specified.
Safety Specifications
Parameters
Agency Approval
CE
EN55022 Class A, EN55024
IEC61000-4-2, Perf. Criteria B
IEC61000-4-3, Perf. Criteria A
IEC61000-4-4, Perf. Criteria B (external 220uF/100V cap required)
IEC61000-4-5, Perf. Criteria B (external 220uF/100V cap required)
IEC61000-4-6, Perf. Criteria A
IEC61000-4-8, Perf. Criteria A
NOTE: Also designed to meet IEC60950-1:2001
Standards
Pin Out Specifications
Pin
Single
1
2
3
9
10
11
12/13
14
15
16
22
23
24
+V Input
N. C.
N. C.
Omitted
-V Output
+V Output
-V Input
+V Output
-V Output
Omitted
N. C.
N. C.
+V Input
1500VDC
Dual
+V Input
-V Output
Common
Omitted
Common
+V Output
-V Input
+V Output
Common
Omitted
Common
-V Output
+V Input
3500VDC
Single
Omitted
-V Input
-V Input
Omitted
Omitted
N.C.
Omitted
+V Output
Omitted
-V Output
+V Input
+V Input
Omitted
Dual
Omitted
-V Input
-V Input
Common
Omitted
-V Output
Omitted
+V Output
Omitted
Common
+V Input
+V Input
Omitted
www.aimtec.com
F 051e R12.F
Tel: +1 514 620 2722
3 of 6
Toll free: + 1 888 9 AIMTEC
(924 6832)
North America only
Series AM5TW-Z
5 Watt | DC-DC Converter
Dimensions
Conducted Emissions:
Dual Output
12uH
L
C1
220uF
100V
-V input
C2
1000pF
2KV
Single Output
+V output
12uH
L
C1
+V output
+V input
DC/DC
Converter
-V output
-V input
Load
Load
+V input
DC/DC
Converter
Load
220uF
100V
Common
C2
-V output
1000pF
2KV
www.aimtec.com
F 051e R12.F
Tel: +1 514 620 2722
4 of 6
Toll free: + 1 888 9 AIMTEC
(924 6832)
North America only
Series AM5TW-Z
5 Watt | DC-DC Converter
Surge:
Dual Output
+V output
Load
DC/DC
Converter
+V input
C1
220uF
100V
-V input
-V output
Load
Common
NOTE: 1.
Datasheets are updated as needed and as such, specifications are subject to change without notice. Once printed or downloaded, datasheets are no longer controlled
by Aimtec; refer to www.aimtec.com for the most current product specifications.
2.
Product labels shown, including safety agency certifications on labels, may vary based on the
date manufactured.
3.
Mechanical drawings and specifications are for reference only.
4.
All specifications are measured at an ambient temperature of 25°C, humidity<75%,
nominal input voltage and at rated output load unless otherwise specified.
5.
Aimtec may not have conducted destructive testing or chemical analysis on all internal components
and chemicals at the time of publishing this document. CAS numbers and other limited information are considered proprietary and may not be available for release.
6.
This
product is not designed for use in critical life support systems, equipment used in hazardous environments, nuclear control systems or other such applications which necessitate
specific safety and regulatory standards other the ones listed in this datasheet.
7.
Warranty is in accordance with Aimtec’s standard Terms of Sale available at www.aimtec.com.
