NOTE: All specifications in this datasheet are measured at an ambient temperature of 25°C, humidity<75%, nominal input voltage and at
rated output load unless otherwise specified.
Output Current
max
(A)
Efficiency
(%)
Input Specifications
Parameters
Current
Inrush current <2ms
Leakage current
External fuse
Input dissipation
Start-up time
Conditions
115 VAC
230 VAC
115 VAC
230 VAC
Typical
Maximum
1000
530
25
50
150
Units
mA
A
µA
A
W
ms
Recommended slow blow type
No load; 115VAC
No load; 264VAC
3.15
<0.5
<0.8
117
Output Specifications
Voltage accuracy
Line regulation
Load regulation
Cross regulation
Maximum Capacitive load
Transient response deviation
Ripple & Noise*
Hold-up time (min)
Minimum Load Current
www.aimtec.com
F 052e R7.N
Parameters
Conditions
(LL-HL)
0-100% load single
0-100% load dual
25% load - 1
st
out, 100% load – 2
nd
out
Depending of the model
25% load Step
20MHz bandwidth
115VAC
*Ripple
& Noise measured with 0.1μF M/C and 1μF E/C
±2
±0.5
±1
±2
±5
470-23 000
±2
50
29
0
Typical
Maximum
Units
%
%
%
%
µF
% of Vout
mV p-p
ms
% of Max
Tel: +1 514 620 2722
1 of 4
Toll free: + 1 888 9 AIMTEC
(924 6832)
North America only
40 Watt | AC-DC / DC-DC Converter
Isolation Specifications
Tested I/O voltage
Isolation Resistance
Series AMEC40-MAZ
Rated
4000
Parameters
Conditions
3 sec
Typical
>1000
Units
VAC
MΩ
General Specifications
Switching frequency
Over current protection
Over voltage protection
Short circuit protection
Short Circuit restart
Operating temperature
Maximum case temperature
Storage temperature
Temperature coefficient
Cooling
Humidity
Case material
Weight
Dimensions
(L X H X W)
MTBF
Parameters
Conditions
Auto recovery
With derating above 50ºC
47
110
Zener diode clamp
Hiccup mode, indefinite
Auto recovery
-40 - +85
-40 to +100
0.02
Free air convection
Typical
Maximum
140
110
Units
KHz
%
%
o
o
100
C
C
o
C
% /
o
C
% RH
g
Non condensing
270
4.92 x 2.56 x 1.38 inches / 125.00 x 65.00 x 35.00 mm
> 800 000 hrs (MIL-HDBK -217F, t=+25
o
C)
Metal
95
Environment Approval
Test
Shock
Vibration
Parameters
Wave form
Acceleration amplitude
Bump duration
Converter operation
Number of bumps
Test mode
Displacement
Acceleration
Converter operation
Conditions
Half sine wave
5gn
30 ms
Before and after test, body mounted (on chassis)
18 (3 in each direction for every axis)
Sweep sine, 10-100Hz, speed 0.05Hz/s
1 mm
3g,
3 loops 30min one cycle, 3h total, every axis tested
Before and after test, body mounted (on chassis)
Safety Specifications
Parameters
Agency approvals
cULus, CE, CB Scheme
Medical Electrical Equipment
Information technology Equipment
EMI - Conducted and radiated emission
Harmonic Current Emissions
Voltage fluctuations and flicker
Electrostatic Discharge Immunity
RF, Electromagnetic Field Immunity
Electrical Fast Transient/Burst Immunity
Surge Immunity
RF, Conducted Disturbance Immunity
Power frequency Magnetic Field Immunity
Voltage dips, Short Interruptions Immunity
IEC\EN\UL 60601-1, CSA-C22.2 No. 601.1-M90
EN 60950-1:2006+A11:2009
EN55011, class B
IEC/EN 61000-3-2, (EN60555-2)
IEC/EN 61000-3-3, (EN60555-3)
IEC 61000-4-2
IEC 61000-4-3
IEC 61000-4-4
IEC 61000-4-5
IEC 61000-4-6
IEC 61000-4-8
IEC 61000-4-11
Standards
www.aimtec.com
F 052e R7.N
Tel: +1 514 620 2722
2 of 4
Toll free: + 1 888 9 AIMTEC
(924 6832)
North America only
Pin Out Specifications
Pin
1
2
3
4
5
6
AC Input (L)
AC Input (N)
+V Output
-V Output
N.C.
N.C.
40 Watt | AC-DC / DC-DC Converter
Series AMEC40-MAZ
Single
N.C.: Not Connected
AC Input (L)
AC Input (N)
+V Output
Common
Common
-V Output
Dual
Dimensions
2.56
(65.00)
2.56
(65.00)
Mounting
Holes
(including
DIN rail
bracket)
(M3)
1
AC Input
Connector
0.81
(20.50)
0.88
(22.25)
2
4.90
(125.00)
2.10
(53.25)
68.63
(2.700)
1.28
(32.50)
3 4 5 6
DC Output
Connector
Bottom View
Top View
Dimensions: inch (mm)
Case Tolerance: ±0.05 (±1.30)
Side View
35.00
(1.38)
PCB Mounting
Screw
PCB
PCB Mounting
Screw
Mylar Film
Bracket
Mounting
Screw
PCB
Mylar Film
2.6 mm Max
Customer Chassis
www.aimtec.com
F 052e R7.N
Tel: +1 514 620 2722
3 of 4
Toll free: + 1 888 9 AIMTEC
(924 6832)
North America only
Optional DIN Rail Bracket
40 Watt | AC-DC / DC-DC Converter
Series AMEC40-MAZ
Derating
Free Air Convection
50º C
100
Output Power (%)
80
60
40
20
0
- 40
- 20
0
20
40
60
80
85
Safe Operating Area
100
Ambient Temperature
º C
NOTE: 1.
Datasheets are updated as needed and as such, specifications are subject to change without notice. Once printed or downloaded, datasheets are no longer controlled
by Aimtec; refer to www.aimtec.com for the most current product specifications.
2.
Product labels shown, including safety agency certifications on labels, may vary based on the
date manufactured.
3.
Mechanical drawings and specifications are for reference only.
4.
All specifications are measured at an ambient temperature of 25°C, humidity<75%,
nominal input voltage and at rated output load unless otherwise specified.
5.
Aimtec may not have conducted destructive testing or chemical analysis on all internal components
and chemicals at the time of publishing this document. CAS numbers and other limited information are considered proprietary and may not be available for release.
6.
This
product is not designed for use in critical life support systems, equipment used in hazardous environments, nuclear control systems or other such applications which necessitate
specific safety and regulatory standards other the ones listed in this datasheet.
7.
Warranty is in accordance with Aimtec’s standard Terms of Sale available at www.aimtec.com.
