BAT42, BAT43
www.vishay.com
Vishay Semiconductors
Small Signal Schottky Diode
FEATURES
• For general purpose applications
• These diodes feature very low turn-on voltage
and fast guard ring against excessive voltage,
such as electrostatic discharges
• These diodes are also available in the SOD-123
case with the type designations BAT42W-V to
BAT43W-V and in MiniMELF SOD-80 case with
the type designations LL42 to LL43
• AEC-Q101 qualified
• Material categorization: for definitions of compliance
please see
www.vishay.com/doc?99912
DESIGN SUPPORT TOOLS
click logo to get started
Models
Available
MECHANICAL DATA
Case:
DO-35 (DO-204AH)
Weight:
approx. 125 mg
Cathode band color:
black
Packaging codes/options:
TR/10K per 13" reel (52 mm tape), 50K/box
TAP/10K per ammo tape (52 mm tape), 50K/box
PARTS TABLE
PART
BAT42
BAT43
ORDERING CODE
BAT42-TR or BAT42-TAP
BAT43-TR or BAT43-TAP
CIRCUIT CONFIGURATION
Single
Single
TYPE MARKING
BAT42
BAT43
REMARKS
Tape and reel/ammopack
Tape and reel/ammopack
ABSOLUTE MAXIMUM RATINGS
(T
amb
= 25 °C, unless otherwise specified)
PARAMETER
Repetitive peak reverse voltage
Forward continuous current
(1)
Repetitive peak forward current
Surge forward current
(1)
Power dissipation
(1)
(1)
TEST CONDITION
SYMBOL
V
RRM
I
F
VALUE
30
200
500
4
200
UNIT
V
mA
mA
A
mW
t
p
< 1 s,
δ
< 0.5
t
p
< 10 ms
T
amb
= 65 °C
I
FRM
I
FSM
P
tot
Note
(1)
Valid provided that leads at a distance of 4 mm from case are kept at ambient temperature
THERMAL CHARACTERISTICS
(T
amb
= 25 °C, unless otherwise specified)
PARAMETER
Thermal resistance junction to ambient air
Junction temperature
Ambient operating temperature range
Storage temperature range
(1)
TEST CONDITION
SYMBOL
R
thJA
T
j
T
amb
T
stg
VALUE
300
125
-65 to +125
-65 to +150
UNIT
K/W
°C
°C
°C
Note
(1)
Valid provided that leads at a distance of 4 mm from case are kept at ambient temperature
Rev. 1.8, 01-Jun-17
Document Number: 85660
1
For technical questions within your region:
DiodesAmericas@vishay.com, DiodesAsia@vishay.com, DiodesEurope@vishay.com
THIS DOCUMENT IS SUBJECT TO CHANGE WITHOUT NOTICE. THE PRODUCTS DESCRIBED HEREIN AND THIS DOCUMENT
ARE SUBJECT TO SPECIFIC DISCLAIMERS, SET FORTH AT
www.vishay.com/doc?91000
BAT42, BAT43
www.vishay.com
Vishay Semiconductors
TEST CONDITION
I
R
= 100 μA (pulsed)
V
R
= 25 V
V
R
= 25 V, T
j
= 100 °C
I
F
= 200 mA
I
F
= 10 mA
BAT42
BAT42
BAT43
BAT43
PART
SYMBOL
V
(BR)
I
R
I
R
V
F
V
F
V
F
V
F
V
F
C
D
t
rr
η
v
80
7
5
260
MIN.
30
0.5
100
1000
400
650
330
450
TYP.
MAX.
UNIT
V
μA
μA
mV
mV
mV
mV
mV
pF
ns
%
ELECTRICAL CHARACTERISTICS
(T
amb
= 25 °C, unless otherwise specified)
PARAMETER
Reverse breakdown voltage
Leakage current
(1)
Forward voltage
(1)
I
F
= 50 mA
I
F
= 2 mA
I
F
= 15 mA
Diode capacitance
Reserve recovery time
Rectification efficieny
Note
(1)
Pulse test; t < 300 μs, t /T < 0.02
p
p
V
R
= 1 V, f = 1 MHz
I
F
= 10 mA, I
R
= 10 mA,
i
R
= 1 mA, R
L
= 100
Ω
R
L
= 15 kΩ, C
L
= 300 pF,
f = 45 MHz, V
RF
= 2 V
TYPICAL CHARACTERISTICS
(T
amb
= 25 °C, unless otherwise specified)
250
1000
I
R
- Reverse Leackage Current (µA)
P
tot
- Power Dissipation (mW)
125 °C
200
150
100
50
0
0
50
100
150
200
100
100 °C
75 °C
10
1
50 °C
25 °C
0.1
0.01
0
10
20
30
40
V
R
- Reverse
Voltage
(V)
50
18444
18442
T
amb
- Ambient Temperature (°C)
Fig. 1 -
Admissible Power Dissipation vs. Ambient Temperature
Fig. 3 -
Typical Reverse Characteristics
1000
14
100
125 °C
- 40 °C
C
D
- Diode Capacitance (pF)
I
F
- Forward Current (mA)
12
10
8
6
4
2
0
10
1
25 °C
0.1
0.01
0
0
5
10
15
20
25
30
18443
200
400
600 800 1000 1200
V
F
- Instantaneous Forward
Voltage
(mV)
18445
V
R
- Reverse
Voltage
(V)
Fig. 2 -
Typical Forward Characteristics
Fig. 4 -
Typical Capacitance vs. Reverse Voltage
Rev. 1.8, 01-Jun-17
Document Number: 85660
2
For technical questions within your region:
DiodesAmericas@vishay.com, DiodesAsia@vishay.com, DiodesEurope@vishay.com
THIS DOCUMENT IS SUBJECT TO CHANGE WITHOUT NOTICE. THE PRODUCTS DESCRIBED HEREIN AND THIS DOCUMENT
ARE SUBJECT TO SPECIFIC DISCLAIMERS, SET FORTH AT
www.vishay.com/doc?91000
BAT42, BAT43
www.vishay.com
PACKAGE DIMENSIONS
in millimeters (inches):
DO-35 (DO-204AH)
Cathode Identification
Vishay Semiconductors
Ø 0.6 max. [0.024]
Ø 0.4 min. [0.015]
1.7 [0.067]
26 min. [1.024]
3.9 max. [0.154]
3.1 min. [0.120]
26 min. [1.024]
Rev. 6 - Date: 19. December 2011
Document no.: SB-V-3906.04-031(4)
94 9366
Rev. 1.8, 01-Jun-17
Document Number: 85660
3
For technical questions within your region:
DiodesAmericas@vishay.com, DiodesAsia@vishay.com, DiodesEurope@vishay.com
THIS DOCUMENT IS SUBJECT TO CHANGE WITHOUT NOTICE. THE PRODUCTS DESCRIBED HEREIN AND THIS DOCUMENT
ARE SUBJECT TO SPECIFIC DISCLAIMERS, SET FORTH AT
www.vishay.com/doc?91000
1.3 [0.050]
