UNISONIC TECHNOLOGIES CO., LTD

BAT54ADW

Preliminary

DIODE

SCHOTTKY BARRIER (DUAL)

DIODES

DESCRIPTION

Planar Schottky barrier diodes are encapsulated in the SOT-363

small plastic SMD package. Single diodes and dual diodes with

different pin configuration are available.

FEATURES

* Low forward voltage

* Guard ring protected

* Small plastic SMD package

SOT-363

SYMBOL

ORDERING INFORMATION

Ordering Number

Lead Free

Halogen Free

BAT54ADWL-AL6-R

BAT54ADWG-AL6-R

Note: Pin Assignment: A: Anode K: Cathode

Package

SOT-363

Pin Assignment

K1 A2 K2 K2

Packing

Tape Reel

MARKING

www.unisonic.com.tw

1 of 2

VER.a
