BCR16LM-12LD-A8

Description
Triac
CategoryAnalog mixed-signal IC    Trigger device
File Size89KB,8 Pages
ManufacturerRenesas Electronics Corporation
Websitehttps://www.renesas.com/
Environmental Compliance
Download Datasheet Parametric Compare View All

BCR16LM-12LD-A8 Overview

Triac

BCR16LM-12LD-A8 Parametric

Parameter NameAttribute value
Is it lead-free?Lead free
Is it Rohs certified?conform to
MakerRenesas Electronics Corporation
Parts packaging codeTO-220AB
package instructionFLANGE MOUNT, R-PSFM-T3
Contacts3
Reach Compliance Codecompli
Other featuresUL RECOGNIZED
Shell connectionISOLATED
ConfigurationSINGLE
Critical rise rate of commutation voltage - minimum value10 V/us
Maximum DC gate trigger current50 mA
Maximum DC gate trigger voltage1.5 V
JEDEC-95 codeTO-220AB
JESD-30 codeR-PSFM-T3
Maximum leakage current2 mA
Number of components1
Number of terminals3
Maximum operating temperature150 °C
Minimum operating temperature-40 °C
Package body materialPLASTIC/EPOXY
Package shapeRECTANGULAR
Package formFLANGE MOUNT
Peak Reflow Temperature (Celsius)NOT SPECIFIED
Maximum rms on-state current16 A
Off-state repetitive peak voltage600 V
surface mountNO
Terminal formTHROUGH-HOLE
Terminal locationSINGLE
Maximum time at peak reflow temperatureNOT SPECIFIED
Trigger device typeTRIAC
Preliminary
Datasheet
BCR16LM-12LD
Triac
Medium Power Use
Features
I
T (RMS)
: 16 A
V
DRM
: 600 V
I
FGTI
, I
RGTI
, I
RGTIII
: 50 mA
Viso : 1800 V
The product guaranteed maximum junction
temperature 150°C.
Insulated Type
Planar Type
UL Recognized : File No. E223904
R07DS0070EJ0100
Rev.1.00
Jul 27, 2010
Outline
RENESAS Package code: PRSS0003AF-A)
(Package name: TO-220FL)
2
1. T
1
Terminal
2. T
2
Terminal
3. Gate Terminal
3
1
1
2 3
Applications
Motor control, heater control
Maximum Ratings
Parameter
Repetitive peak off-state voltage
Note1
Non-repetitive peak off-state voltage
Note1
Symbol
V
DRM
V
DSM
Voltage class
12
600
700
Unit
V
V
R07DS0070EJ0100 Rev.1.00
Jul 27, 2010
Page 1 of 7

BCR16LM-12LD-A8 Related Products

BCR16LM-12LD-A8 BCR16LM-12LD
Description Triac Triac
Is it lead-free? Lead free Lead free
Is it Rohs certified? conform to conform to
Maker Renesas Electronics Corporation Renesas Electronics Corporation
Parts packaging code TO-220AB TO-220AB
package instruction FLANGE MOUNT, R-PSFM-T3 FLANGE MOUNT, R-PSFM-T3
Contacts 3 3
Reach Compliance Code compli compli
Other features UL RECOGNIZED UL RECOGNIZED
Shell connection ISOLATED ISOLATED
Configuration SINGLE SINGLE
Critical rise rate of commutation voltage - minimum value 10 V/us 10 V/us
Maximum DC gate trigger current 50 mA 50 mA
Maximum DC gate trigger voltage 1.5 V 1.5 V
JEDEC-95 code TO-220AB TO-220AB
JESD-30 code R-PSFM-T3 R-PSFM-T3
Maximum leakage current 2 mA 2 mA
Number of components 1 1
Number of terminals 3 3
Maximum operating temperature 150 °C 150 °C
Minimum operating temperature -40 °C -40 °C
Package body material PLASTIC/EPOXY PLASTIC/EPOXY
Package shape RECTANGULAR RECTANGULAR
Package form FLANGE MOUNT FLANGE MOUNT
Peak Reflow Temperature (Celsius) NOT SPECIFIED NOT SPECIFIED
Maximum rms on-state current 16 A 16 A
Off-state repetitive peak voltage 600 V 600 V
surface mount NO NO
Terminal form THROUGH-HOLE THROUGH-HOLE
Terminal location SINGLE SINGLE
Maximum time at peak reflow temperature NOT SPECIFIED NOT SPECIFIED
Trigger device type TRIAC TRIAC
