5 - 208869 - 1 Product Details
Subminiature D Pin/Socket Connectors for
MIL - C- 24308 and MIL
- C- 39029
Always EU RoHS/ELV Compliant
Quick Links
)
Check Pricing &
Availability
Search for Tooling
Product Feature
Selector
Contact Us About
This Product
(
Statement of Compliance
5 - 208869
TE Part Number: 5
-1
- 208869 - 1
Active
Add to Part List
Product Highlights:
?
Connector
?
Product Series = 90
?
Density = High
?
Terminate To Printed Circuit Board
?
Number of Positions = 62
View all Features
|
Find Similar
Products
Documentation & Additional Information
Product Drawings:
?
None Available
Catalog Pages/Data Sheets:
?
None Available
Product Specifications:
?
None Available
Application Specifications:
?
None Available
Instruction Sheets:
?
None Available
CAD Files:
?
None Available
Additional Information:
?
Product Line Information
Additional Product Images:
?
Insert Arrangement
Related Products:
?
Tooling
Product Features
(Please use the Product Drawing for all design activity)
Product Type Features:
?
Product Type
= Connector
?
Product Series
= 90
?
Number of Positions
= 62
?
Gender
= Plug
?
PCB Mount Angle
= Vertical
?
Shell Size
= 4
?
Shell Material
= Steel
?
Mounting Hole Diameter (mm [in]) = 3.05
[.120]
?
Comment = Replacement pin contact Part
Number 207683 - 8.
Termination Related Features:
?
Termination (Solder) Post Length (mm [in])
6.99 [0.275]
Body Related Features:
?
Blindmate
= No
?
Non - Magnetic
= No
?
Pins
= With
?
Rear Grommet
= No
?
Power/Signal/Coax Combination
= No
?
Shell Plating
= Zinc
?
Mount Style = Mounting Holes
?
Retention Clip Material = Stainless Steel
Contact Related Features:
?
Contact Size
= 22
?
Contact Style
= Posted
Configuration Related Features:
?
Density
= High
Industry Standards:
?
Government/Industry Qualification = No
?
RoHS/ELV Compliance
= RoHS compliant, ELV
compliant
?
Lead Free Solder Processes
= Wave solder
capable to 240°C, Wave solder capable to 260°
C, Wave solder capable to 265°C, Reflow
solder capable to 245°C, Reflow solder capable
to 260°C, Pin - in - Paste capable to 245°C, Pin
in - Paste capable to 260°C
?
RoHS/ELV Compliance History = Always was
RoHS compliant
?
NASA Qualification = No
Conditions for Usage:
?
Terminate To = Printed Circuit Board
Other:
?
Brand = AMP
=
-
