CMNDM7001
SURFACE MOUNT
N-CHANNEL
ENHANCEMENT-MODE
SILICON MOSFET
w w w. c e n t r a l s e m i . c o m
DESCRIPTION:
The CENTRAL SEMICONDUCTOR CMNDM7001 is
an N-Channel Enhancement-mode Silicon MOSFET,
manufactured by the N-Channel DMOS Process,
designed for high speed pulsed amplifier and driver
applications. This MOSFET offers Low rDS(ON) and
Low Threshold Voltage.
MARKING CODE: AC
SOT-953 CASE
• Device is
Halogen Free
by design
FEATURES:
• Low 0.5mm Package Profile
• Low rDS(ON)
• Low Threshold Voltage
• Logic Level Compatible
• Small, FEMTOmini™ 1.0 x 0.8mm, SOT-953
Surface Mount Package
SYMBOL
VDS
VGS
ID
ID
PD
TJ, Tstg
UNITS
V
V
mA
mA
mW
°C
UNITS
μA
μA
V
V
Ω
Ω
Ω
nC
nC
nC
mS
pF
pF
pF
ns
ns
APPLICATIONS:
• Load/Power Switches
• Power Supply Converter Circuits
• Battery Powered Portable Equipment
MAXIMUM RATINGS:
(TA=25°C)
Drain-Source Voltage
Gate-Source Voltage
Continuous Drain Current (Steady State)
Continuous Drain Current
Power Dissipation
Operating and Storage Junction Temperature
20
10
100
200
250
-65 to +150
MAX
1.0
1.0
0.9
3.0
4.0
15
ELECTRICAL CHARACTERISTICS:
(TA=25°C unless otherwise noted)
SYMBOL
TEST CONDITIONS
MIN
TYP
IGSSF, IGSSR VGS=10V, VDS=0
IDSS
VDS=20V, VGS=0
BVDSS
VGS=0, ID=100μA
20
VGS(th)
VDS=VGS, ID=250μA
0.6
rDS(ON)
VGS=4.0V, ID=10mA
0.9
rDS(ON)
VGS=2.5V, ID=10mA
1.3
rDS(ON)
Qg(tot)
Qgs
Qgd
gFS
Crss
Ciss
Coss
ton
toff
VGS=1.5V, ID=1.0mA
VDS=10V, VGS=4.5V,
VDS=10V, VGS=4.5V,
ID=100mA
ID=100mA
100
4.0
9.0
9.5
50
75
0.566
0.16
0.08
VDS=10V, VGS=4.5V, ID=100mA
VDS =10V, ID=100mA
VDS=3.0V, VGS=0, f=1.0MHz
VDS=3.0V, VGS=0, f=1.0MHz
VDS=3.0V, VGS=0, f=1.0MHz
VDD=3.0V, VGS=2.5V, ID=10mA
VDD=3.0V, VGS=2.5V, ID=10mA
