ZLED7001
Universal LED Driver with Temperature Compensation
ZLED7001 Block Diagram
SOP-8 Package Dimensions
(mm, except
θ)
A
A1
A2
b
c
D
1.550 ± 0.200
0.175 ± 0.075
1.450 Typical
0.420 ± 0.070
0.214 ± 0.036
4.900 ± 0.100
E
E1
e
L
θ
3.900 ± 0.100
6.020 ± 0.220
1.270 Typical
0.835 ± 0.435
4° ± 4°
Ordering Information
Sales Code
ZLED7001-ZI1R
ZLED7001Kit-E1
ZLED-PCB1
ZLED-PCB2
Description
ZLED7001 – Universal LED Driver with Temperature Compensation
ZLED7001 Evaluation Board up to 24VAC / 40VDC, including 1 ZLED-PCB1
Test PCB with one 3W white HB-LED, cascadable to one multiple LED string
10 unpopulated test PCBs for modular LED string with footprints of 9 common HB-LED types
Kit
Printed Circuit Board
Printed Circuit Board
Package
SOP8 (Tape & Reel)
Sales and Further Information
Zentrum Mikroelektronik
Dresden AG (ZMD AG)
Grenzstrasse 28
01109 Dresden
Germany
Phone +49 (0)351.8822.7.533
Fax
+49(0)351.8822.8.7533
www.zmdi.com
Zentrum Mikroelektronik
Dresden AG, Japan Office
2nd Floor, Shinbashi Tokyu Bldg.
4-21-3, Shinbashi, Minato-ku
Tokyo, 105-0004
Japan
Phone +81.3.6895.7410
Fax
+81.3.6895.7301
LED_Drivers@zmdi.com
ZMD FAR EAST, Ltd.
3F, No. 51, Sec. 2,
Keelung Road
11052 Taipei
Taiwan
Phone +886.2.2377.8189
Fax
+886.2.2377.8199
ZMD America, Inc.
8413 Excelsior Drive
Suite 200
Madison, WI 53717
USA
Phone
Fax
+1 (608) 829-1987
+1 (631) 549-2882
