ZLED7002
Toggle (Side-Step) Dual-Channel LED Driver
SOP8 Package Dimensions and Pin Assignments
Symbol
A
A1
A2
b
c
D
E
E1
e
L
θ
Dimension
(mm, except
θ
)
Min
1.350
0.100
1.450 Typical
0.350
0.178
4.800
3.800
5.800
1.270 Typical
0.400
0°
1.270
8°
0.490
0.250
5.000
4.000
6.240
Max
1.750
0.250
Typical Applications
Battery-driven LED lighting including
•
•
•
•
Helmet lighting
Bicycle lighting
Miner lamps
Pocket lights
Voltage-level indicators
General purpose low-voltage industrial and
consumer LED applications
Ordering Information
Product Sales Code
ZLED7002-ZI1R
ZLED7002KIT-E1
Description
ZLED7002 – Toggle (Side-Step) Dual-Channel LED Driver
ZLED7002 Evaluation Kit
Kit
Package
SOP8 (Tape & Reel)
