VJ X8R
www.vishay.com
Vishay Vitramon
Surface Mount Multilayer Ceramic Chip Capacitors
for High Temperature Applications
FEATURES
• Specialty: high temperature applications
• High operating temperature dielectric,
up to +150 °C
• Maintains capacitance at high temperature for
frequency stability
• Wet build process
• Reliable Noble Metal Electrode (NME) system
• Material categorization: for definitions of compliance
please see
www.vishay.com/doc?99912
Available
APPLICATIONS
• High temperature modules
ELECTRICAL SPECIFICATIONS
Note
• Electrical characteristics at +25 °C unless otherwise specified.
Operating Temperature:
-55 °C to +150 °C
Capacitance Range:
330 pF to 220 nF
Voltage Range:
25 V
DC
to 100 V
DC
Temperature Coefficient of Capacitance (TCC):
± 15 % from -55 °C to +150 °C
Dissipation Factor (DF):
25 V ratings: 3.5 % maximum at 1.0 V
RMS
and 1 kHz
> 25 V ratings: 2.5 % maximum at 1.0 V
RMS
and 1 kHz
Aging Rate:
1 % maximum per decade
Insulation Resistance (IR):
at +25 °C and rated voltage 100 000 M minimum or
1000
F,
whichever is less
at +125 °C and rated voltage 10 000 M minimum or
100
F,
whichever is less
Dielectric Strength Test:
performed per method 103 of EIA-198-2-E
Applied test voltage:
100 V
DC
-rated: 250 % of rated voltage
Revision: 25-May-2018
Document Number: 45006
1
For technical questions, contact:
mlcc@vishay.com
THIS DOCUMENT IS SUBJECT TO CHANGE WITHOUT NOTICE. THE PRODUCTS DESCRIBED HEREIN AND THIS DOCUMENT
ARE SUBJECT TO SPECIFIC DISCLAIMERS, SET FORTH AT
www.vishay.com/doc?91000
VJ X8R
www.vishay.com
Vishay Vitramon
QUICK REFERENCE DATA
DIELECTRIC
CASE
0402
0603
X8R
0805
1206
1210
Note
• Detail ratings see “Selection Chart”
MAXIMUM VOLTAGE
(V)
100
100
100
50
50
CAPACITANCE
MINIMUM
330 pF
470 pF
470 pF
1.0 nF
10 nF
MAXIMUM
6.8 nF
33 nF
100 nF
220 nF
220 nF
ORDERING INFORMATION
VJ0805
H
102
K
X
A
A
MARKING
(4)
C
PACKAGING
###
(2)
PROCESS
CODE
CASE DIELECTRIC CAPACITANCE CAPACITANCE TERMINATION DC VOLTAGE
CODE
NOMINAL
TOLERANCE
RATING
(1)
CODE
0402
0603
0805
1206
1210
H = X8R
Expressed in
picofarads (pF).
The first two
digits are
significant, the
third is a
multiplier.
Examples:
102 = 1000 pF
J=±5%
K = ± 10 %
M = ± 20 %
X = Ni barrier
100 % tin plated
F, E = AgPd
(3)(5)
X = 25 V
A = 50 V
B = 100 V
A = unmarked
M = marked
Note
Marking is only
available for
0805 and 1206
with termination
code “X”
T = 7" reel / plastic tape
C = 7" reel / paper tape
R = 11 1/4" / 13" reel / plastic tape
P = 11 1/4" / 13" reel / paper tape
O = 7" reel / flamed paper tape
I = 11 1/4" / 13" reel / flamed paper tape
Note
“I” and “O” are used for
“F” termination size 0603 / 0805 and
“E” termination size 0402 / 0603 / 0805
Notes
(1)
DC voltage rating should not be exceeded in application. Other application factors may affect the MLCC performance.
Consult for questions:
mlcc@vishay.com
(2)
Process code may be added with up to three digits, used to control non-standard products and requirements.
(3)
Termination code “E” for conductive epoxy assembly.
(4)
Marking in reference to EIA198, see
www.vishay.com/doc?45028
(5)
Termination code “F” not available for 0402, 0603 - 100 V, 0805 - 100 V.
ENVIRONMENTAL STATUS
TERMINATION CODE
X
E
F
TERMINATION DESCRIPTION
Ni barrier 100 % tin plated matte finish
AgPd
AgPd
RoHS COMPLIANT
Yes
Yes
Yes
VISHAY GREEN
Yes
Yes
No
Revision: 25-May-2018
Document Number: 45006
2
For technical questions, contact:
mlcc@vishay.com
THIS DOCUMENT IS SUBJECT TO CHANGE WITHOUT NOTICE. THE PRODUCTS DESCRIBED HEREIN AND THIS DOCUMENT
ARE SUBJECT TO SPECIFIC DISCLAIMERS, SET FORTH AT
www.vishay.com/doc?91000
VJ X8R
www.vishay.com
Vishay Vitramon
DIMENSIONS
in inches (millimeters)
W
L
T
MAX.
P
CASE
CODE
STYLE
LENGTH
(L)
0.040 + 0.004/- 0.002
(1.00 + 0.10/- 0.05)
0.063 ± 0.006
(1.60 ± 0.15)
0.079 ± 0.008
(2.00 ± 0.20)
0.126 ± 0.010
(3.20 ± 0.25)
0.126 ± 0.010
(3.20 ± 0.25)
WIDTH
(W)
0.020 + 0.004/- 0.002
(0.50 + 0.10/- 0.05)
0.031 ± 0.006
(0.80 ± 0.15)
0.049 ± 0.008
(1.25 ± 0.20)
0.063 ± 0.010
(1.60 ± 0.25)
0.098 ± 0.010
(2.50 ± 0.25)
MAXIMUM THICKNESS
(T)
0.024
(0.60)
0.036
(0.92)
0.057
(1.45)
0.067
(1.70)
0.067
(1.70)
TERMINATION
(P)
MINIMUM
MAXIMUM
0.016
(0.41)
0.022
(0.55)
0.030
(0.76)
0.030
(0.76)
0.030
(0.76)
0402
0603
0805
1206
1210
VJ0402
VJ0603
VJ0805
VJ1206
VJ1210
0.004
(0.10)
0.012
(0.30)
0.010
(0.25)
0.010
(0.25)
0.010
(0.25)
Revision: 25-May-2018
Document Number: 45006
3
For technical questions, contact:
mlcc@vishay.com
THIS DOCUMENT IS SUBJECT TO CHANGE WITHOUT NOTICE. THE PRODUCTS DESCRIBED HEREIN AND THIS DOCUMENT
ARE SUBJECT TO SPECIFIC DISCLAIMERS, SET FORTH AT
www.vishay.com/doc?91000
VJ X8R
www.vishay.com
Vishay Vitramon
X8R
VJ0402
0402
50
A
••
••
••
••
••
••
••
••
••
••
••
VJ0603
0603
50
A
VJ0805
0805
50
A
VJ1206
(1)
1206
25
50
X
A
VJ1210
(1)
1210
25
50
X
A
SELECTION CHART
DIELECTRIC
STYLE
CASE CODE
VOLTAGE (V
DC
)
VOLTAGE CODE
CAP. CODE
331
391
471
561
681
821
102
122
152
182
222
272
332
392
472
562
682
822
103
123
153
183
223
273
333
393
473
563
683
823
104
124
154
184
224
274
334
394
25
X
CAP.
330 pF
390 pF
470 pF
560 pF
680 pF
820 pF
1.0 nF
1.2 nF
1.5 nF
1.8 nF
2.2 nF
2.7 nF
3.3 nF
3.9 nF
4.7 nF
5.6 nF
6.8 nF
8.2 nF
10 nF
12 nF
15 nF
18 nF
22 nF
27 nF
33 nF
39 nF
47 nF
56 nF
68 nF
82 nF
100 nF
120 nF
150 nF
180 nF
220 nF
270 nF
330 nF
390 nF
••
••
••
••
••
••
••
••
••
••
••
••
••
••
••
••
••
100
B
••
••
••
••
••
••
••
••
25
X
100
B
25
X
100
B
••
••
••
••
••
••
••
••
••
••
••
••
••
••
••
••
••
••
••
••
••
••
••
••
••
••
••
••
••
••
••
••
••
••
••
••
••
••
••
••
••
••
••
••
••
••
••
••
••
••
••
••
••
••
••
••
••
••
••
••
••
••
••
••
••
••
••
••
••
••
••
••
••
••
••
••
••
••
•
•
•
•
•
••
••
••
••
••
••
••
••
••
••
••
••
••
••
••
••
••
••
••
••
••
•
•
•
•
•
••
••
••
••
••
••
••
••
••
••
••
••
••
••
••
••
••
••
••
••
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
Notes
(1)
See soldering recommendations within this data book, or visit
www.vishay.com/doc?45034
• Plastic tape, •• Paper tape
RoHS-compliant
X8R PACKAGING QUANTITIES
CASE CODE
0402
0603
0805
(2)
1206
(2)
1210
(2)
TAPE SIZE
8 mm
8 mm
8 mm
8 mm
8 mm
(1)
7" REEL QUANTITIES
PACKAGING CODE
“C” / “O”
“T”
5000
n/a
4000
n/a
3000
3000
n/a
2500 / 3000
n/a
2000 / 2500 / 3000
11 1/4" AND 13" REEL QUANTITIES
PACKAGING CODE
“P” / “I”
“R”
10 000
n/a
10 000
n/a
10 000
10 000
10 000
9000 / 10 000
10 000
9000 / 10 000
Notes
(1)
Reference: EIA standard RS481 - “Taping of Surface Mount Components for Automatic Placement”
(2)
Packaging “C” / “P” / “O” / “I” and “T” / “R” or lower quantities can depend from product thickness
Revision: 25-May-2018
Document Number: 45006
4
For technical questions, contact:
mlcc@vishay.com
THIS DOCUMENT IS SUBJECT TO CHANGE WITHOUT NOTICE. THE PRODUCTS DESCRIBED HEREIN AND THIS DOCUMENT
ARE SUBJECT TO SPECIFIC DISCLAIMERS, SET FORTH AT
www.vishay.com/doc?91000
VJ X8R
www.vishay.com
Vishay Vitramon
STORAGE AND HANDLING CONDITIONS
(1) Store the components at 5 °C to 40 °C ambient temperature and
70 % relative humidity conditions.
(2) The product is recommended to be used within a time-frame of 2 years after shipment.
Check solderability in case extended shelf life beyond the expiry date is needed.
Precautions:
a. Do not store products in an environment containing corrosive elements, especially where chloride gas, sulfide gas, acid, alkali, salt or
the like are present. This may cause corrosion or oxidization of the terminations, which can easily lead to poor soldering.
b. Store products on the shelf and avoid exposure to moisture or dust.
c. Do not expose products to excessive shock, vibration, direct sunlight and so on.
X8R DIELECTRIC - TYPICAL PARAMETERS
TEMPERATURE COEFFICIENT OF CAPACITANCE
15
10
5
0
-5
- 10
- 15
- 20
- 75 - 50 - 25
0
25
50
75 100 125 150 175
TEMPERATURE °C
% CAPACITANCE CHANGE
% CAPACITANCE CHANGE
1.0
0.0
- 1.0
- 2.0
-
3.0
- 4.0
1
10
100
HOURS
1000
10 000
AGING RATE
DISSIPATION FACTOR VS. VOLTAGE
0.025
% DISSIPATION FACTOR
DISSIPATION FACTOR
0.023
0.021
0.019
0.017
0.015
0.013
0
10
20
30
DC VOLTS APPLIED
40
50
5.0
4.5
4.0
3.5
3.0
2.5
2.0
1.5
1.0
0.5
0.0
DISSIPATION FACTOR VS. TEMPERATURE
X8R
- 75 - 50 - 25
0
25
50 75 100 125 150 175
TEMPERATURE °C
VOLTAGE COEFFICIENT OF CAPACITANCE
0.0
CAPACITANCE CHANGE IN %
- 5.0
- 10.0
- 15.0
- 20.0
- 25.0
0
10
20
30
DC VOLTS APPLIED
40
50
10 000
INSULATION RESISTANCE
(ΩF)
INSULATION RESISTANCE VS. TEMPERATURE
1000
100
10
10
25
100
TEMPERATURE °C
150
