318B102EP28: DescriptionPower/Signal Relay, SPDT, Latched, 0.047A (Coil), 28VDC (Coil), 1316mW (Coil), 25A (Contact), 28VDC (Contact), DC Input, AC/DC Output, Through Hole-Straight Mount,; CategoryMechanical and electronic products relay; File Size347KB，4 Pages; ManufacturerSTPI Siege Social

Download Datasheet Parametric Compare View All

318B102EP28 Overview

Power/Signal Relay, SPDT, Latched, 0.047A (Coil), 28VDC (Coil), 1316mW (Coil), 25A (Contact), 28VDC (Contact), DC Input, AC/DC Output, Through Hole-Straight Mount,

318B102EP28 Parametric

Parameter Name	Attribute value
Reach Compliance Code	unknow
ECCN code	EAR99
Other features	PANEL MOUNTABLE
body width	13.3 mm
body height	25.7 mm
Body length or diameter	26 mm
Maximum coil current (DC)	0.047 A
Coil operating voltage (DC)	19.8 V
Coil power	1316 mW
Coil release voltage (DC)	19.8 V
Coil resistance	600 Ω
Maximum coil voltage (DC)	28 V
Coil/Input Power Type	DC
Contact (AC) maximum rated R load	25A@115VAC
Maximum contact current (AC)	25 A
Maximum contact current (DC)	25 A
Contact (DC) maximum rated R load	25A@28VDC
Maximum contact voltage (AC)	115 V
Maximum contact voltage (DC)	28 V
Contact/Output Power Type	AC/DC
Electrical life	50000 Cycle(s)
JESD-609 code	e3
Installation features	THROUGH HOLE-STRAIGHT MOUNT
operating hours	11 ms
Maximum operating temperature	125 °C
Minimum operating temperature	-65 °C
physical size	26mm x 13.3mm x 25.7mm
Relay action	LATCHED
Relay function	SPDT
Relay type	POWER/SIGNAL RELAY
seal	HERMETICALLY SEALED
surface mount	NO
Terminal surface	TIN
Termination type	SOLDER
Base Number Matches	1

Preview

Download Datasheet

View All

318 B 1

RT - SPDT

/25

RELAIS HERMETIQUES

BISTABLES

HERMETICALLY SEALED

LATCHING

RELAY

CARACTERISTIQUES GENERALES

Combinaison des contacts

Contact arrangement

GENERAL CHARACTERICS

1 RT

SPDT

Pouvoir de coupure 28 Vcc - 1 5 V/400 Hz

Contact rating 28 Vdc - 115 V/400 Hz

Circuit résistif

Resistive load

25 A

25 Amps

Circuit inductif (L/R = 5 ms)

Inductive load (L/R = 5 ms)

1 A (28 Vcc) / 1 A (15 V - 400 Hz)

12 Amps (28 Vdc) / 15 Amps (115 V - 400 Hz)

Circuit moteur

Motor load

10 A

10 Amps

Circuit lampe

Lamp load

5 Amp

Alimentation

Supply

Courant continu (polarisé)

Direct current (polarised)

Masse

Weight

45 g à 54 g max.

45 g to 54 g max.

Normes applicables en annexe

See appendice for applicable specifications

ENVIRONNEMENT

Température de fonctionnement

Temperature range

ENVIRONMENT

- 65° à + 1

25°C

- 65° to + 125°C

Position de fonctionnement

Operating position

Indifférente

Any

Tenue aux vibrations

Resistance against vibrations

Sinus : 30 g - 10 - 3 000 Hz / Aléatoire : 0,4 g

/Hz - 50 - 2 000 Hz

Sinus : 30 g - 10 - 3 000 Hz / Random : 0,4 g

/Hz - 50 - 2 000 Hz

Tenue aux chocs

Shocks resistance

200 g - 6 ms /100 g - 1 ms

200 g - 6 ms /100 g - 11 ms

Tenue aux secousses

Shake resistance

40 g

Accélération

Acceleration

20 g

Taux de fuite

Leak rate

1.10

-8

/sec

1.10

-8

/sec

58 Av. Claude VELLEFAUX - 75010 PARIS - FRANCE

318 B 1/4

Tel : 33.(0)1.42.03.94.20 - Fax : 33.(0)1.42.03.52.85 - www.stpigroup.com
