HIGH-DENSITY
1U SERVER
PLATFORM
B8228Y190X2-045V4H
YR190-B8228-X2
Front View
High-Density 1U dual-socket SMP
server implementation for IPDC
applications
Dual C32 sockets support up to (2) AMD Opteron™ 4100/4200
series processors (Lisbon/Valencia)
Support (2) HyperTransport™ 3.0 link, max. bandwidth up to 25.6
GB/s @ 6.4GT/s per link
AMD SR5650 + SP5100
(12) 240-pin DDR3 DIMM slots support up to 96GB R-DDR3
1333/1066/800MHz w/ ECC memory
(1) HH/HL PCI-E (Gen.2) x16 slot
(3) GbE LAN
(4) Hot-swap 2.5" SATA-II HDDs w/ RAID 0, 1, 10, 5 support
Onboard BMC w/ IPMI and iKVM support
(1) ERP1U high-efficiency 450W PSU w/ PFC, 80-PLUS Silver
Certified
Back View
Specifications are subject to change without notice. Items pictured may only be representative.
B8228Y190X2-045V4H
YR190-B8228-X2
Easy-swap System FANs
(2) 4056 + (1) 4028
M7018-BP
BP4-port SAS/SATA-II
HDD backplane board
M5376-FPB
Integrated front panel board
GOLD
Specifications
ERP1U 450W PSU, 80-PLUS Silver
M7018-R16-1L
Provide (1) low-profile
PCI-E (Gen. 2) x16 slot Rear View
S8228GM3NR
(2) C32 sockets
(6+6) R-DDR3 1333/1066/800MHz
Max.96GB, (3) GbEports,
Legacy-free Rear I/O
Form Factor
Chassis Name
System
Dimension (H x W x D)
Motherboard
Gross Weight
Front Panel
(per blade)
External Drive
Bay (per blade)
Buttons
LEDs
I/O Ports
Type / Q'ty
Supported HDD
Interface
1U Rackmount Frame w/ 2x 1U blades
YR190
1.72" x 17.32" x 28.74" (43.6 x 440 x 730mm)
S8228GM3NR
25 kg (w/ 2 blades installed)
(1) RST / (1) ID / (1) PWR
(1) Power / (1) BMC / (2) LAN / (1) HDD
(2) USB ports
2.5" Hot-Swap / (4)
SAS 3.0Gb/s (via HBA)
SATA-II 3.0Gb/s
(3) 4cm fans
ERP1U cold-swap
Full-range AC(100-240V)
47 - 63 Hertz
450 Watts
PFC / 80-plus Silver
AMD Opteron™ 4100/4200 series
processors
C32 / (2)
Up to 50W
Support (2) HyperTransport™ 3.0 link, max.
bandwidth up to 25.6 GB/s @ 6.4GT/s per
link
AMD SR5650 + SP5100
(6+6) DIMM slots
DDR3 1333/1066/800 RDIMM
Up to
96GB
RDIMM
4 Channels (2 Channels per CPU)
1.5V / 1.35V
(1) Low-Profile PCI-E Gen.2 x16 slot
M7018-R16-1L, PCI-E x16 1U riser card
(right)
(3)
Intel® 82576EB
Intel® 82574L
AMD SP5100
3.0 Gb/s
Graphic
(per blade)
Connector type
Resolution
Chipset
USB
D-Sub 15-pin
1600x1200@60Hz
Aspeed AST2050
(5) USB2.0 ports (2 at rear, 2 at front, 1 type
A onboard)
(1) DB-9 port
(1) D-Sub 15-pin VGA port
(3) GbE ports
Winbond W83795G
Monitors voltage for CPU, memory, chipset &
power supply
Monitors temperature for CPU & system
environment
Input / Output
(per blade)
COM
VGA
RJ-45
Chipset
System Cooling
FAN
Configuration
(per blade)
Type
Power Supply
(per blade)
System
Monitoring
(per blade)
Voltage
Temperature
LED
Fan fail LED indicator
(On system front panel)
Over temperature warning indicator
Others
Onboard Chipset
Watchdog timer support
Onboard Aspeed AST2050
IPMI 2.0 compliant baseboard management
controller (BMC)
BIOS update
USB 2.0 virtual hub
24-bit high quality video compression
Dual 10/100 Mb/s MAC interfaces
AMI / 4MB
Plug and Play (PnP)
PCI2.3 /WfM2.0 /SMBIOS2.3 /PXE boot
ACPI 2.0 power management
Power on mode after power recovery
User-configurable H/W monitoring
Auto-configurable of hard disk types
Multiple boot options
Please refer to our OS supported list.
Class A
Yes
10° C ~ 35° C (50° F~ 95° F)
- 40° C ~ 70° C (-40° F ~ 158° F)
90%, non-condensing at 35° C
Yes
Input Range
Frequency
Output Watts
Efficiency
Supported CPU Series
Socket Type / Q'ty
Server
Management
(per blade)
AST2050 IPMI Feature
AST2050 iKVM Feature
Brand / ROM size
Processor
(per blade)
Average CPU Power
(ACP) wattage
System Bus
BIOS
(per blade)
Feature
Chipset (per blade)
Chipset
Supported DIMM Qty
Memory
(per blade)
DIMM Type / Speed
Capacity
Memory channel
Memory voltage
Expansion Slots
Pre-installed TYAN
(per blade)
Riser Card
LAN
(per blade)
Storage
(per blade)
Port Q'ty
Controller
SATA
Controller
Speed
PCI-E
Operating
System
Regulation
OS supported list
FCC (DoC)
CE (DoC)
Operating Temp.
Non-operating Temp.
In/Non-operating
Humidity
RoHS 6/6 Complaint
Operating
Environment
RoHS
(Specifications are subject to change without notice. Items pictured may only be representative.)
