4U WITH 18 NODES
HIGH DENSITY
SERVER
PLATFORM
FM65-B5531
B5531F65X18-160PV2R
B5531F65X18-160PV2R-HE
Front View
High Density Single-Socket Xeon
Server Platform for CDN/Web
access/Web hosting/Low-end web
server applications
Per-blade single LGA1150 socket supports Intel® Xeon® (1)E3-1200/ E5-1200L
v3 series processors
●
Per-blade single LGA1150 socket supports Inrel® Xeon® (1) E3-12x5 v3 series
(-HE SKU) series processors
●
Per-blade Intel® C222 PCH/ C226 PCH (-HE SKU)
●
Per-blade (4) DIMM slots
Support up to 32GB U-DDR3 VLP ECC 1600/1333/1066
●
Per-blade (2) 2.5" fixed HDD
●
Per-blade (2) GbE (via Intel® X540-AM2)
●
Per-blade Onboard BMC w/ IPMI and iKVM support
Per-blade Onboard BMC w/ IPMI support only(-HE SKU)
●
(2+1) RPSU 80-PLUS Platinum 1,600 Watts
●
Back View
Specifications are subject to change without notice. Items pictured may only be representative.
FM65-B5531
B5531F65X18-160PV2R / B5531F65X18-160PV2R-HE
Specifications
System
Form Factor
Chassis Name
Dimension (H x W x D)
4U Rackmount
FM65
25.6" x 17.32" x 6.93" (651.2 x 440 x 176.3mm)
S5531GM2NR
S5531GP2NR-HE (-HE SKU)
55 kg
(1) PWR
(1) PWR / (1) ID/ (1) HDD
(2) USB ports / (1) D-Sub 15 pin port / (1) RJ45 LAN
2.5" fixed / (2)
height: 15mm / SATA-III 6.0Gb/s
(8) hot-swap 8cm fans
RPSU
100-127V AC/8A
200-240V AC/ 4A
80-PLUS Platinum
1600 Watts
2+1
Intel
®
Xeon
®
E3-1200/ E5-1200L v3 series processors
Inrel
®
Xeon
®
E3-12x5 v3 series processors (-HE SKU)
LGA 1150/ (1)
Graphic
(Per-blade)
Connector type
Resolution
Chipset
(1) D-Sub 15-pin port
Up to 1920x1200
Aspeed AST2300
Intel
®
Xeon
®
E3-12x5 v3 processors (-HE SKU)
(2) USB2.0 ports
N/A
(1) D-Sub 15-pin port
(18) GbE w/ activity LED at rear from pass-through
module
-
Onboard Aspeed AST2300
Onboard Aspeed AST1250 (-HE SKU)
Monitors voltage for CPU, memory, chipset & power
supply
Monitors temperature for CPU & memory & system
environment
Over temperature warning indicator / Fan & PSU fail
LED indicator
Watchdog timer support
Onboard Aspeed AST2300
Onboard Aspeed AST1250 (-HE SKU)
IPMI 2.0 compliant baseboard management controller
(BMC) / Supports storage over IP and remote platform-
flash / USB 2.0 virtual hub
24-bit high quality video compression / 10/100 Mb/s
MAC interface
IPMI 2.0 compliant baseboard management controller
(BMC) / Supports storage over IP and remote platform-
flash / USB 2.0 virtual hub
Motherboard
Gross Weight
Front Panel
(Per-blade)
Buttons
LEDs
I/O Ports
External
Drive Bay
(Per-blade)
System
Cooling
Configuratio
Power
Supply
Type / Q'ty
HDD backplane support
Interface
FAN
Type
Input Range
Efficiency
Output Watts
Redundancy
Processor
(Per-blade)
Supported CPU Series
Input
USB
/Output
COM
(Per-blade)
VGA
RJ-45
SFP+
Chipset
System
Voltage
Monitoring
(Per-blade)
Temperature
LED (On system front
panel)
Others
Server
Onboard Chipset
Management
(Per-blade)
AST2300 IPMI Feature
Socket Type / Q'ty
Thermal Design Power
(TDP) wattage
Max up to 84W
-
Intel
®
C222/ C226 (-HE SKU)
-
(4) DIMM slots
DDR3 VLP ECC 1066/1333/1600 UDIMM
Up to 32GB
2 Channels per CPU
1.5V/ 1.35V
-
-
(2) GbE RJ-45
AST2300 iKVM Feature
AST1250 IPMI Feature
(-HE SKU)
BIOS
(Per-blade)
Operating
System
Regulation
Brand / ROM size
Feature
OS supported list
FCC (DoC)
CE (DoC)
Operating
Operating Temp.
Environment
Non-operating Temp.
In/Non-operating
Humidity
RoHS
RoHS 6/6 Complaint
System Bus
Chipset
(Per-blade)
Memory
(Per-blade)
Chipset
Super I/O
Supported DIMM Qty
DIMM Type / Speed
Capacity
Memory channel
Memory voltage
Expansion
Slots
(Per-blade)
LAN
(Per-blade)
Storage
(Per-blade)
SATA
PCI-E
Pre-install TYAN Riser
Card
Port Q'ty
Controller
Connector
Controller
Speed
RAID
AMI / 16MB
SMBIOS 2.7/PnP/Wake on LAN / ACPI 3.0/PXE boot
Please refer to our Intel OS supported list.
Class A
Yes
10° C ~ 35° C (50° F~ 95° F)
- 40° C ~ 70° C (-40° F ~ 158° F)
90%, non-condensing at 35° C
Yes
Intel
®
X540-AM2
(2) SATA
Intel
®
C222/ C226 (-HE SKU)
6.0 Gb/s
RAID 0/1
(Specifications are subject to change without notice. Items pictured may only be representative.)
