DBR30-09K1100

Description
D Type Connector, 9 Contact(s), Male, 0.109 inch Pitch, Solder Terminal, #4-40, Receptacle
CategoryThe connector    The connector
File Size105KB,1 Pages
ManufacturerAdvanced-Connectek Inc
Download Datasheet Parametric Compare View All

DBR30-09K1100 Overview

D Type Connector, 9 Contact(s), Male, 0.109 inch Pitch, Solder Terminal, #4-40, Receptacle

DBR30-09K1100 Parametric

Parameter NameAttribute value
Reach Compliance Codeunknown
ECCN codeEAR99
body width0.492 inch
subject depth0.492 inch
body length1.213 inch
Body/casing typeRECEPTACLE
Contact to complete cooperationAU ON NI
Contact completed and terminatedTIN/LEAD OVER NICKEL
Contact point genderMALE
Contact materialCOPPER ALLOY
contact modeSTAGGERED
Contact resistance15 mΩ
Contact styleRND PIN-SKT
Dielectric withstand voltage1000VAC V
maximum insertion force3.336 N
Insulation resistance5000000000 Ω
Insulator colorBLACK
insulator materialGLASS FILLED THERMOPLASTIC
Manufacturer's serial numberDBR30
Plug contact pitch0.109 inch
Match contact row spacing0.112 inch
Installation option 1#4-40
Installation option 2LOCKING
Installation methodRIGHT ANGLE
Installation typeBOARD
PCB row number2
Number of rows loaded2
Maximum operating temperature125 °C
Minimum operating temperature-55 °C
PCB contact patternSTAGGERED
PCB contact row spacing2.8448 mm
Rated current (signal)5 A
GuidelineUL, CSA
reliabilityCOMMERCIAL
Shell surfaceTIN OVER COPPER
Shell materialSTEEL
Terminal length0.122 inch
Terminal pitch2.7686 mm
Termination typeSOLDER
Total number of contacts9
Evacuation force-minimum value.278 N

DBR30-09K1100 Related Products

DBR30-09K1100 DBR30-25K5100
Description D Type Connector, 9 Contact(s), Male, 0.109 inch Pitch, Solder Terminal, #4-40, Receptacle D Type Connector, 25 Contact(s), Male, 0.109 inch Pitch, Solder Terminal, #4-40, Receptacle
Reach Compliance Code unknown unknown
ECCN code EAR99 EAR99
body width 0.492 inch 0.492 inch
subject depth 0.492 inch 0.492 inch
body length 1.213 inch 2.091 inch
Body/casing type RECEPTACLE RECEPTACLE
Contact to complete cooperation AU ON NI AU ON NI
Contact completed and terminated TIN/LEAD OVER NICKEL TIN/LEAD OVER NICKEL
Contact point gender MALE MALE
Contact material COPPER ALLOY COPPER ALLOY
contact mode STAGGERED STAGGERED
Contact resistance 15 mΩ 15 mΩ
Contact style RND PIN-SKT RND PIN-SKT
Dielectric withstand voltage 1000VAC V 1000VAC V
maximum insertion force 3.336 N 3.336 N
Insulation resistance 5000000000 Ω 5000000000 Ω
Insulator color BLACK BLACK
insulator material GLASS FILLED THERMOPLASTIC GLASS FILLED THERMOPLASTIC
Manufacturer's serial number DBR30 DBR30
Plug contact pitch 0.109 inch 0.109 inch
Match contact row spacing 0.112 inch 0.112 inch
Installation option 1 #4-40 #4-40
Installation option 2 LOCKING LOCKING
Installation method RIGHT ANGLE RIGHT ANGLE
Installation type BOARD BOARD
PCB row number 2 2
Number of rows loaded 2 2
Maximum operating temperature 125 °C 125 °C
Minimum operating temperature -55 °C -55 °C
PCB contact pattern STAGGERED STAGGERED
PCB contact row spacing 2.8448 mm 2.8448 mm
Rated current (signal) 5 A 5 A
Guideline UL, CSA UL, CSA
reliability COMMERCIAL COMMERCIAL
Shell surface TIN OVER COPPER TIN OVER COPPER
Shell material STEEL STEEL
Terminal length 0.122 inch 0.122 inch
Terminal pitch 2.7686 mm 2.7686 mm
Termination type SOLDER SOLDER
Total number of contacts 9 25
Evacuation force-minimum value .278 N .278 N
