UNISONIC TECHNOLOGIES CO., LTD
MGBR10V45
MOS GATED BARRIER
RECTIFIER
DESCRIPTION
DIODE
The UTC
MGBR10V45
is a surface mount mos gated barrier
rectifier, it uses UTC’s advanced technology to provide customers
with low forward voltage drop and high switching speed, etc.
FEATURES
* Very low forward voltage drop
* High switching speed
SYMBOL
TO-220-2
TO-220 / TO-220F
TO-252 / TO-277
ORDERING INFORMATION
Package
TO-220-2
TO-220
TO-220F
TO-252
TO-277
Pin Assignment
1
2
3
K
A
-
A
K
A
A
K
A
A
K
A
A
K
A
Packing
Tube
Tape Reel
Tape Reel
Tape Reel
Tape Reel
Ordering Number
Lead Free
Halogen Free
MGBR10V45L-TA2-T
MGBR10V45G-TA2-T
MGBR10V45L-TA3-T
MGBR10V45G-TA3-T
MGBR10V45L-TF3-T
MGBR10V45G-TF3-T
MGBR10V45L-TN3-R
MGBR10V45G-TN3-R
MGBR10V45L-T27-R
MGBR10V45G-T27-R
Note: Pin Assignment: A: Anode K: Common Cathode
MARKING
TO-220-2 / TO-220 / TO-220F / TO252
TO-277
www.unisonic.com.tw
Copyright © 2015 Unisonic Technologies Co., Ltd
1 of 3
QW-R601-119.E
MGBR10V45
ABSOLUTE MAXIMUM RATINGS
(T
A
=25°C, unless otherwise specified)
DIODE
Single phase, half wave, 60Hz, resistive or inductive load.
For capacitance load, derate current by 20%.
PARAMETER
SYMBOL
RATINGS
UNIT
DC Blocking Voltage
V
RM
45
V
Working Peak Reverse Voltage
V
RWM
45
V
Peak Repetitive Reverse Voltage
V
RRM
45
V
RMS Reverse Voltage
V
R(RMS)
32
V
Average Rectified Output Current
T
C
=140°C
I
O
10
A
Non-Repetitive Peak Forward Surge Current 8.3ms
I
FSM
150
A
Single Half Sine-Wave Superimposed on Rated Load
Operating Junction Temperature
T
J
-65~+150
°C
Storage Temperature
T
STG
-65~+150
°C
Note: Absolute maximum ratings are those values beyond which the device could be permanently damaged.
Absolute maximum ratings are stress ratings only and functional device operation is not implied.
THERMAL CHARACTERISTICS
PARAMETER
SYMBOL
TO-220-2/TO-220
TO-220F
TO-252
TO-277
TO-220-2/TO-220
TO-220F
TO-252
TO-277
θ
JA
RATINGS
60
110
73 (Note 3)
2
3.31
2.5
13 (Note 3)
°C/W
UNIT
Junction to Ambient
Junction to Case
θ
JC
°C/W
ELECTRICAL CHARACTERISTICS
(T
A
=25°C,
unless otherwise specified.)
SYMBOL
V
(BR)R
MIN
45
TYP MAX UNIT
V
0.53
V
0.48
V
50
500
μA
12
40
mA
400
pF
TEST CONDITIONS
I
R
=0.5mA
I
F
=10A, T
J
=25°C
Instantaneous Forward Voltage
V
FM
I
F
=10A, T
J
=125°C
V
R
=45V, T
J
=25°C
Leakage Current (Note 1)
I
RM
V
R
=45V, T
J
=125°C
Total Capacitance
C
T
V
R
=5V, f=1MHz, T
J
=25°C
Notes: 1. Short duration pulse test used to minimize self-heating effect.
2. Thermal resistance junction to case mounted on heatsink.
3. Mounted on an FR4 PCB, single-sided copper, with 100cm
2
copper pad area.
PARAMETER
Reverse Breakdown Voltage (Note 1)
UNISONIC TECHNOLOGIES CO., LTD
www.unisonic.com.tw
2 of 3
QW-R601-119.E
MGBR10V45
TYPICAL CHARACTERISTICS
Forward Derating Curve
Typical Forward Characteristics
DIODE
16
Average Rectified Current (A)
14
12
10
8
6
4
2
0
0
25
50
75
100 125 150 175
Instantaneous Forward Current (A)
100
125°C
10
25°C
1.0
IF Pulse
Width=300uS
0.2
0.4
0.6
0.8
1.0
0.1
Case Temperature (°C)
Instantaneous Forward Voltage (V)
Typical Reverse Characteristics
1E-1
Instantaneous Reverse Current (A)
1E-2
1E-3
1E-4
1E-5
1E-6
1E-7
V
R
=45V
25
50
75
100
125
150
Case Temperature (°C)
UTC assumes no responsibility for equipment failures that result from using products at values that
exceed, even momentarily, rated values (such as maximum ratings, operating condition ranges, or
other parameters) listed in products specifications of any and all UTC products described or contained
herein. UTC products are not designed for use in life support appliances, devices or systems where
malfunction of these products can be reasonably expected to result in personal injury. Reproduction in
whole or in part is prohibited without the prior written consent of the copyright owner. The information
presented in this document does not form part of any quotation or contract, is believed to be accurate
and reliable and may be changed without notice.
UNISONIC TECHNOLOGIES CO., LTD
www.unisonic.com.tw
3 of 3
QW-R601-119.E
