UNISONIC TECHNOLOGIES CO., LTD
MBR10200C
SCHOTTKY BARRIER
RECTIFIER
FEATURES
Preliminary
DIODE
* 10 amps total (20 amps per diode leg)
* Guard ring for transient protection
* Low forward voltage drop
* High surge capability
* Low power loss/High efficiency
SYMBOL
ORDERING INFORMATION
Package
TO-220
TO-220F
Pin Assignment
1
2
3
A
K
A
A
K
A
Packing
Tube
Tube
Ordering Number
Lead Free
Halogen Free
MBR10200CL-TA3-T
MBR10200CG-TA3-T
MBR10200CL-TF3-T
MBR10200CG-TF3-T
Note: Pin Assignment: A: Anode K: Cathode
MARKING INFORMATION
PACKAGE
MARKING
TO-220/TO-220F
www.unisonic.com.tw
Copyright © 2014 Unisonic Technologies Co., Ltd
1 of 3
QW-R601-185.a
MBR10200C
Preliminary
DIODE
ABSOLUTE MAXIMUM RATINGS
(T
A
=25°C, unless otherwise specified)
SYMBOL
V
RRM
V
RM
V
R
I
O
I
FSM
C
J
T
J
T
STG
RATINGS
200
200
200
5
10
150
300
-65 ~ +150
-65 ~ +150
UNIT
V
V
V
A
A
A
pF
°C
°C
PARAMETER
Maximum Repetitive Peak Reverse Voltage
Maximum non-repetitive Peak Reverse Voltage
Maximum DC Blocking Voltage
Per Leg
Average Forward Rectified Output Current
Total
Non-Repetitive Peak Forward Surge Current
8.3ms Single Half-Sine-Wave
Junction Capacitance (Note 4)
Operating Temperature
Storage Temperature
THERMAL DATA
PARAMETER
SYMBOL
θ
JA
TO-220
TO-220F
θ
JC
RATINGS
60
2
4
UNIT
°С/W
°С/W
°С/W
Junction to Ambient
Junction to Case
ELECTRICAL CHARACTERISTICS
PARAMETER
SYMBOL
TEST CONDITIONS
MIN TYP MAX UNIT
I
F
=5A, T
C
=25°C
0.90
V
I
F
=5A, T
C
=125°C
0.85
V
Instantaneous Forward Voltage Drop (Note 3)
V
F
I
F
=10A, T
C
=25°C
1
V
I
F
=10A, T
C
=125°C
0.95
V
Rated DC Voltage, T
C
=25°C
500
μA
Instantaneous Reverse Current (Note 3)
I
R
Rated DC Voltage, T
C
=125°C
20
mA
Notes: 1. Absolute maximum ratings are those values beyond which the device could be permanently damaged.
Absolute maximum ratings are stress ratings only and functional device operation is not implied.
2. 2.0μs Pulse Width, f = 1.0KHz.
3. Pulse Test: Pulse Width=300µs, Duty Cycle≤ 2.0%.
4. Applied V
R
= 4.0V and f = 1.0MHz.
UNISONIC TECHNOLOGIES CO., LTD
www.unisonic.com.tw
2 of 3
QW-R601-185.a
MBR10200C
Preliminary
DIODE
UTC assum es no responsibility for equipm ent failures that result from using products at v alues that
exceed, ev en m om entarily, rated v alues (such as m axim um ratings, operating condition ranges, or
other param eters) listed in products specifications of any and all UTC products described or contained
herein. UTC products are not designed for use in life support appliances, devices or system s where
m alfunction of these products can be reasonably expected to result in personal injury. Reproduction in
whole or in part is prohibited without the prior written consent of the copyright owner. The inform ation
presented in this docum ent does not form part of any quotation or contract, is believ ed to be accurate
and reliable and m ay be changed without notice.
