Series 80 Mighty Mouse
Backshells and Accessories
Jam Nuts 809-094
X
How To Order
Sample Part Number
Series (See Table I)
Accessories
Jam nut for Mighty Mouse connectors
Replace lost or damaged jam nuts with these standard replacement parts. Jam nut
fits all Series 80 jam nut receptacles. Use with Glenair tool 600-146
.110/.090
A THREAD
øB
809-094
-M
7
Dash
800
No.
1
2
3
3-3
4
5
5-5
6
6-6
7
8
9
10
11
12
13
14
15
16
18
20
5
6
7
8
9
10
12
14
15
809-094
C
= Aluminum / Black Anodize (Non-
Conductive) RoHS Compliant
804
801 -00 -07
805
style style
5
6
5
7,8
9
10
11
13
6
7,8
7,8
9
10
11
12
14
15
9
10
11
12
14
15
9,10
11
12
13
15
5
6
8
A Thread
Class 2B
.3125-28 UN-2B
.3750-28 UN-2B
.4375-28 UNEF-2B
.4375-32 UN-2B
.5000-32 UN-2B
.5625-28 UN-2B
.5625-32 UN-2B
.6250-28 UN-2B
.6250-32 UN-2B
.6875-28 UN-2B
.7500-28 UN-2B
.8125-28 UN-2B
.8750-28 UN-2B
.9375-28 UN-2B
1.0000-28 UN-2B
1.0625-20 UN-2B
1.1250-28 UN-2B
1.1875-28 UN-2B
1.2500-28 UN-2B
1.3750-28 UN-2B
1.5000-28 UN-2B
B Dia
0.43
0.50
0.56
0.56
0.62
0.68
0.68
0.75
0.75
0.81
0.87
0.93
1.00
1.06
1.12
1.18
1.25
1.31
1.37
1.50
1.62
M
= Aluminum / Electroless Nickel
NF
= Aluminum / Cadmium with
Shell Material and Finish
Olive Drab
ZN
= Aluminum / Zinc-Nickel with
Olive Drab Chromate
Z1
= Stainless Steel / Passivated
See Table I
Dash No.
16
17
19
21
18
19
21
23
Dimensions in Inches (millimeters) are subject to change without notice.
© 2014 Glenair, Inc.
Series 80 Mighty Mouse
U.S. CAGE Code 06324
Printed in U.S.A.
GLENAIR, INC.
•
1211 AIR WAY
•
GLENDALE, CA 91201-2497
•
818-247-6000
•
FAX 818-500-9912
www.glenair.com
