SHEET 1 OF 1
.50
[.020 in]
26.60
[1.047 in]
13.30
[.524 in]
R2.00
[.079 in]
R9.50
[.374 in]
R8.00
[.315 in]
8.03
[.316 in]
6.80
[.268 in]
ISOMETRIC
6.72
[.265 in]
29.50
[1.161 in]
9.50
[.374 in]
R45.00
[1.772 in]
R3.00
[.118 in]
NOTES:
1. ALL DIMENSIONS IN MM [INCH]
2. GENERAL TOLERANCE: 0.0 = +/-0.4
0.00 = +/-0.25
3. DENOTES CRITICAL PARAMETER
R1.00
[.039 in]
15.89
[.626 in]
16.20
[.638 in]
B
3.00
[.118 in]
B
A
REV
14956
14945
PCR NO
CHANGED DIMENSION
RELEASED FOR PRODUCTION
DESCRIPTION
5/26/05
5/24/05
DATE
JB
JB
BY
TITLE
SCALE
KO SERIES CLIP
2:1
DATE
DR
DWG
REV
THE INFORMATION CONTAINED IN THIS DOCUMENT IS PROPRIETARY
TO E-SWITCH AND IS NOT TO BE COPIED OR TRANSFERRED
5/24/2005
JB
K900003
B
