UCD4015BG-S16-T

Description
CMOS Dual 4-Stage Static Shift Register
Categorylogic    logic
File Size223KB,8 Pages
ManufacturerUNISONIC TECHNOLOGIES CO.,LTD
Websitehttp://www.unisonic.com.tw/
Environmental Compliance
Download Datasheet Parametric Compare View All

UCD4015BG-S16-T Overview

CMOS Dual 4-Stage Static Shift Register

UCD4015BG-S16-T Parametric

Parameter NameAttribute value
Is it Rohs certified?conform to
MakerUNISONIC TECHNOLOGIES CO.,LTD
package instructionSOP,
Reach Compliance Codecompliant
Counting directionRIGHT
series4000/14000/40000
JESD-30 codeR-PDSO-G16
length9.95 mm
Logic integrated circuit typeSERIAL IN PARALLEL OUT
Number of digits4
Number of functions2
Number of terminals16
Maximum operating temperature125 °C
Minimum operating temperature-40 °C
Output polarityTRUE
Package body materialPLASTIC/EPOXY
encapsulated codeSOP
Package shapeRECTANGULAR
Package formSMALL OUTLINE
Peak Reflow Temperature (Celsius)NOT SPECIFIED
propagation delay (tpd)320 ns
Maximum seat height1.75 mm
Maximum supply voltage (Vsup)18 V
Minimum supply voltage (Vsup)3 V
Nominal supply voltage (Vsup)5 V
surface mountYES
technologyCMOS
Temperature levelAUTOMOTIVE
Terminal formGULL WING
Terminal pitch1.27 mm
Terminal locationDUAL
Maximum time at peak reflow temperatureNOT SPECIFIED
Trigger typePOSITIVE EDGE
width3.9 mm
minfmax8.5 MHz
Base Number Matches1
UNISONIC TECHNOLOGIES CO., LTD
UCD4015B
Preliminary
CMOS IC
CMOS Dual 4-Stage Static
Shift Register
DESCRIPTION
UCD4015B
consists of two identical,independent,4-stage
serial-input/parallel-output
registers.
Each
register
has
independent CLOCK and RESET input as well as a single serial
DATA input. ”Q” outputs are available from each of the four
stages on both registers. All registers stages are D-type,
master-slave flip-flops. The logic level present at the DATA input
is transferred into the first register stage and shifted over one
stage at each positive-going clock transition. Resetting of all
stages is accomplished by a high level on the reset line. Register
expansion to 8 stages using one UCD4015 package or to more
than 8 stages using additional UCD4015’s is possible.
SOP-16
TSSOP-16
FEATURES
* 12MHz (typ.) clock rate at 10V
* Maximum input current of 1μA at 18V
* Fully static operation
* 8 master-slave flip-flops plus input and output buffering
APPLICATIONS
* General-purpose register
* Serial-input/parallel-output data queueing
* Serial to parallel data conversion
ORDERING INFORMATION
Ordering Number
Lead Free
Halogen Free
UCD4015BL-S16-T
UCD4015BG-S16-T
UCD4015BL-S16-R
UCD4015BG-S16-R
UCD4015BL-P16-T
UCD4015BG-P16-T
UCD4015BL-P16-R
UCD4015BG-P16-R
Package
SOP-16
SOP-16
TSSOP-16
TSSOP-16
Packing
Tube
Tape Reel
Tube
Tape Reel
www.unisonic.com.tw
Copyright © 2013 Unisonic Technologies Co., Ltd
1 of 8
QW-R502-875.b
