SHEET 1 OF 1
28.20
- .30
.00
+
[
1.110
+.012
- .000
in
]
4.80
[.189 in]
31.60
[1.244 in]
17.00
[.669 in]
PANEL CUTOUT
MAX PANEL THICKNESS 1.5mm
13.30
- .20
.00
+
B
[
.524
+.008
- .000
in
]
21.70
`
.50
[.854
`
.020
in]
FREE POSITION
B
n
8.35
[.329 in]
18.70
`
.80
[.736
`
.031
in]
OPERATING
POSITION
2
1
3
B
C
9.70
[.382 in]
9.50
`
.50
[.374
`
.020
in]
MAX. TRAVEL
POSITION
SPDT
CONTACT CONFIGURATION
2.00
[.079 in]
24.60
2.20
[.969 in]3.55
[.087 in]
[.140 in]
NOTES:
1. ALL DIMENSIONS IN MM
2. GENERAL TOLERANCE: X.X=±0.4
X.XX=±0.25
3. TERM. NOS. FOR REFERENCE ONLY
4. ELECTRICAL LIFE: 6,000 CYCLES
5. OPERATING TEMP: 0°C TO 85°C
6. CONTACT RESISTANCE: 30m MAX. INITIAL
7. 2002/95/EC (ROHS) COMPLIANT
8. DENOTES CRITICAL PARAMETER
9. CONTACT RATING: UL 16A 125VAC, 12A 250VAC, 1HP/250VAC
C
B
A
REV
21089
21034
20592
PCR NO
9.50 WAS 12.10
ADD TOLERANCE TO ACTUATOR POS
New Release
DESCRIPTION
4/2/13
2/14/13
5/7/12
DATE
EBP
EBP
rc
BY
.80
[.031 in]
1
.80
[.032 in]
2 PLS
2
3
4.80
[.189 in]
13.00
[.512 in]
TITLE
PP1 DB7 2A2
DATE
DR
DWG
REV
THE INFORMATION CONTAINED IN THIS DOCUMENT IS PROPRIETARY
TO E-SWITCH AND IS NOT TO BE COPIED OR TRANSFERRED
SCALE
1:1
2/14/2012
rc
34-PP1DB72A2
C
