Type 500R 85 °C High Ripple Current, Inverter Grade, Aluminum
New Higher Ripple Current than Type 500C Screw Terminal Type
The Type 500R is a higher ripple-current version of CDE’s long-life Type
500C specifically designed to provide the ripple current capability
and long life required for high reliability inverter applications. Like
the 500C, the 500R has an endurance rating of 5,000 hours at +85 °C
with the rated ripple current applied, and it is offered in the 350 V to
500 V ratings appropriate for use as dc-link bus capacitors in inverter
applications.
click here to see hardware and mounting options
Highlights
- Large can sizes
- Screw terminals, english and metric
- 5000 hour rated ripple current life
- Higher ripple current than 500C
- 350 to 500 Vdc ratings
- RoHS compliant
–40 °C to +85 °C
350 Vdc to 500 Vdc
1,100 uF to 18,000 µF
±20%
≤3 √CV µA,5 mA max, 5 minutes
Ambient Temperature
45 °C 55 °C 65 °C 75 °C 85 °C
2.00 1.82
1.59
1.33
1.00
Specifications
Temperature Range
Rated Voltage Range
Capacitance Range
Capacitance Tolerance
Leakage Current
Ripple Current Multipliers
Frequency
50 Hz 60 Hz 120 Hz 360 Hz 1 kHz 5 kHz 10 kHz & up
2 & 2½" diameters
350 V
400–500 V
350 V
400–500 V
Low Temperature Characteristics
Endurance Life Test
0.78
0.77
0.84
0.79
0.83
0.82
0.88
0.84
1.00
1.00
1.00
1.00
1.20
1.22
1.12
1.18
1.29
1.33
1.17
1.26
1.34
1.39
1.20
1.31
1.35
1.40
1.20
1.32
3 & 3½" diameters
Impedance ratio: Z
–20⁰C
∕ Z
+25⁰C
≤ 3 (350–500 Vdc)
5000 h at full load at 85 °C
∆ Capacitance ±20%
ESR 200% of limit
DCL 100% of limit
500 h at 85 °C
Capacitance 100% of limit
ESR 100% of limit
DCL 100% of limit
10 to 55 Hz, 0.06” and 10 g max, 1.5 h each of 2 axes
RoHS Compliant
Shelf Life Test
Vibration
CDM Cornell Dubilier • 140 Technology Place • Liberty, SC 29657 • Phone: (864)843-2277 • Fax: (864)843-3800
Type 500R 85 °C High Ripple Current, Inverter Grade, Aluminum
New Higher Ripple Current than Type 500C Screw Terminal Type
Part Numbering System
500R
103
M
350
DN
2
E
S
Type
Capacitance
472
= 4700 µF
103=
10,000 µF
Tolerance
M
= ±20%
U
= –10%+75%
T
= –10%+50%
Voltage
Case Code
350
= 350 Vdc
500
= 500 Vdc
Insulation
0=
None
1=
Polyester
2=
PVC
Outline Drawing
D
Terminal
A
= Low Post
B
= High Post
D
= High Current,
Low Post
E
= High Current,
High Post
F or M
= M5 Post
G
= M6 Low Post
H
= M6 High Post
Can Style
Blank=
Standard
Can
S=
Stud
Bottom
P=
Stud
with
Thermal
Pad
+
S
H
+0 -.062
(+0 -1.57)
Standard insulation is 0.008-in PVC sleeve
with 0.01-in polypropylene end disk.
Polyester insulation is not available for 3.5
inch diameter units.
L
Optional Stud
Stud (Optional)
M12
0.630” (16.0)
P
NOTE: With the stud-mount feature, a thermally-conduc-
tive disk can be inserted in the bottom flush with the
outer insulating sleeve.This reduces the thermal resistance
through the can bottom by 0.3 °C/W. Can Style P.
Terminal Dimensions
For Case
Terminal Style
Low Post
High Post
High Current, Low
High Current, High
M5 Post, Small
M5 Post
M6 Low Post
M6 High Post
Diameters
2 to 3
2 to 3
2½ to 3½
2½ to 3½
1
⅜
to 2
2½ & 3
2½ to 3½
2½ to 3½
Code
A
B
D
E
M
F
G
H
Post Diameter
in
0.314
0.314
0.684
0.684
0.314
0.512
0.684
0.684
mm
8.0
8.0
17.4
17.4
8.0
13.0
17.4
17.4
H max
in
0.094
0.281
0.125
0.281
0.281
0.230
0.125
0.281
mm
2.4
7.1
3.2
7.1
7.1
5.8
3.2
7.1
Thread
10–32
10–32
¼–28
¼–28
M5
M5
M6
M6
min Full Thread
in
0.218
0.375
0.344
0.469
0.375
0.344
0.344
0.469
mm
5.5
9.5
8.7
11.9
9.5
8.7
8.7
11.9
Torque
in∙lb
25
25
50
60
25
25
50
60
N∙m
2.82
2.82
5.65
6.78
2.82
2.82
5.65
6.78
CDM Cornell Dubilier • 140 Technology Place • Liberty, SC 29657 • Phone: (864)843-2277 • Fax: (864)843-3800
Type 500R 85 °C High Ripple Current, Inverter Grade, Aluminum
New Higher Ripple Current than Type 500C Screw Terminal Type
Uninsulated Case Dimensions
Case
Code
BC
BD
BE
BF
CH
CJ
CC
CD
CE
CF
DB
DJ
DC
DD
DE
DF
DM
DP
DN
DG
FC
FD
FE
FF
FP
FN
FG
FM
Diameter (D)
±0.031 in
2.000
2.000
2.000
2.000
2.500
2.500
2.500
2.500
2.500
2.500
3.000
3.000
3.000
3.000
3.000
3.000
3.000
3.000
3.000
3.000
3.500
3.500
3.500
3.500
3.500
3.500
3.500
3.500
±0.78 mm
50.80
50.80
50.80
50.80
63.50
63.50
63.50
63.50
63.50
63.50
76.20
76.20
76.20
76.20
76.20
76.20
76.20
76.20
76.20
76.20
88.90
88.90
88.90
88.90
88.90
88.90
88.90
88.90
Length (L)
±0.062 in
4.125
4.625
5.125
5.625
2.625
3.625
4.125
4.625
5.125
5.625
3.125
3.625
4.125
4.625
5.125
5.625
6.625
5.875
7.625
8.625
4.125
4.625
5.125
5.625
5.875
7.625
8.625
6.625
±1.57 mm
104.78
117.48
130.18
142.88
66.68
92.08
104.78
117.48
130.18
142.88
79.38
92.08
104.78
117.48
130.18
142.88
168.28
149.23
193.68
219.08
104.78
117.48
130.18
142.88
149.23
193.68
219.08
168.28
For insulated case, add 0.024”(0.610 mm) to “D”and 0.030”(0.762 mm) to length.
Terminals (S)
±0.015 in
0.88
0.88
0.88
0.88
1.13
1.13
1.13
1.13
1.13
1.13
1.25
1.25
1.25
1.25
1.25
1.25
1.25
1.25
1.25
1.25
1.25
1.25
1.25
1.25
1.25
1.25
1.25
1.25
±0.38 mm
22.23
22.23
22.23
22.23
28.58
28.58
28.58
28.58
28.58
28.58
31.75
31.75
31.75
31.75
31.75
31.75
31.75
31.75
31.75
31.75
31.75
31.75
31.75
31.75
31.75
31.75
31.75
31.75
Typical Weight
oz
9.5
10.3
10.7
13.0
9.2
12.7
15.0
17.2
19.3
21.4
16.7
20.0
22.2
25.5
30.0
31.9
34.4
32.8
39.5
43.3
30.0
34.4
40.5
43.1
44.3
53.3
58.5
46.4
g
269
292
303
369
261
361
425
488
547
607
473
567
629
723
850
904
933.5
931
1119
1227
850
976
1148
1221
1257
1512
1658
1315.4
